Description
The Alemlube Automotive AA48020 Battery Operated Wheel Lift makes light work of lifting and guiding a heavy wheel
& tyre from the workshop floor into position on the vehicle being serviced. An absolute must in addressing workplace
health & safety concerns, the AA48020 24V Battery Operated Wheel Lift can potentially operate 150-200 times
from a fully charged battery.
Housing a long life DC motor, the AA48020 has been manufactured with a light weight aluminium alloy body allowing
ease of mobility utilising its ergonomic handle and multi-directional 4" rear wheels along with universal front locking
wheels facilitate accurate positioning and stability. The wheel bracket complete with safety hook and angle adjustment
that moves up and down the primary shaft ensure safe & secure wheel handling and the AA48020 control panel
with emergency stop button provides the user with total control.
Technical Specifications
Charging Voltage
Working Voltage
Power
Charging Time
Maximum Load
Maximum Lifting Height
Net Weight
NSW/ACT
QLD/PNG
TEL: (02) 9677 1555
TEL: (07) 3204 9166
FAX: (02) 9675 1155
FAX: (07) 3204 1224
OWNER'S TECHNICAL MANUAL
Battery Operated Wheel Lift
AC230V 50Hz/60HZ
DC24V
200W
4-5h
80Kg
1.2m
65Kg
VIC/TAS
TEL: (03) 8787 8288
FAX: (03) 8787 8266
Visit our website at
www.alemlube.com.au
WA
SA/NT
TEL: (08) 9302 4199
TEL: (08) 8241 7111
FAX: (08) 9303 2095
FAX: (08) 8241 7011
or
www.alemlube.co.nz
AA48020
July 2019
NZ
TEL: (09) 447 1007
FAX: (09) 447 1008
1
Advertisement
Table of Contents
Related Manuals for Alemlube AA48020
Summary of Contents for Alemlube AA48020
- Page 1 Housing a long life DC motor, the AA48020 has been manufactured with a light weight aluminium alloy body allowing ease of mobility utilising its ergonomic handle and multi-directional 4" rear wheels along with universal front locking wheels facilitate accurate positioning and stability.
-
Page 2: Safety Warning And Precautions
OWNER’S TECHNICAL MANUAL AA48020 Battery Operated Wheel Lift Safety Warning and Precautions WARNING: When using tools, basic safety precautions should always be followed to reduce the risk of personal injury and damage to equipment. 1. Keep work area clean. Cluttered areas invite injuries. -
Page 3: Control Panel And Functions
OWNER’S TECHNICAL MANUAL AA48020 Battery Operated Wheel Lift Control Panel and Functions 1. Foot protection indicator 2. Upper limit indicator 3. Lower limit indicator 4. Up 5. Down 6. Charging indicator 7. Battery level indicator 8. Running indicator Overall Appearance 1. -
Page 4: Troubleshooting
OWNER’S TECHNICAL MANUAL AA48020 Battery Operated Wheel Lift Operating Instructions 1. Turn on the power switch, the running indicator on the control panel flashes and the lifter starts to work. 2. Lifting the wheel Put the wheel on the front fork of the lifter and secure it. Hold on the button ( until it reaches the required position. -
Page 5: Battery Use And Maintenance
OWNER’S TECHNICAL MANUAL AA48020 Battery Operated Wheel Lift Battery Use and Maintenance 1. The lifter must be parked well according to the regulations before operating the battery. 2. Fire prevention measures Do not smoke or use an open flame near the battery. -
Page 6: Maintenance
2. Safety requirements for maintenance and repair Lifter maintenance and repair can only be carried out by Alemlube’s qualified technicians. Alemlube’s service personnel are specially trained and are able to perform all maintenance and repair of the equipment. 3. Clean operation Do not clean the lifter with flammable liquid. - Page 7 OWNER’S TECHNICAL MANUAL AA48020 Battery Operated Wheel Lift 5. Maintenance and inspection Inspect the wear degree of the lead screw and nut once every 3 months. Shaking the fork with hand, if the space is more than 5mm, it needs to be replaced (Normally there is no space) Check the battery once every 3 months for leakage and appearance expansion.
