Summary of Contents for VXI Technology VM7510

  • Page 1 VMIC VMIVME-3128-000 Scanning 14-Bit A/D Converter Board In Stock Used and in Excellent Condition Open Web Page https://www.artisantg.com/69374-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s . •...
  • Page 2 VM7510 DC R EFERENCE TANDARD ’ ANUAL P/N: 82-0113-000 Released November 7, 2005 VXI Technology, Inc. 2031 Main Street Irvine, CA 92614-6509 (949) 955-1894...
  • Page 4 IEEE 488.2 Common Commands..........................21 *CLS ...................................21 *ESE ...................................22 *ESR? .................................23 *IDN? .................................24 *OPC...................................25 *RST ...................................26 *SRE ...................................27 *STB? .................................28 *TRG ..................................29 *TST? .................................30 *WAI ..................................31 Instrument Specific SCPI Commands........................32 CALibration:SECure:CODE..........................32 CALibration:SECure:STATe..........................33 DOWNLOAD..............................34 SOURce[:ROUTe] / ROUTe ..........................35 VOLTage[:LEVel] / LEVel ..........................36 VM7510 Preface...
  • Page 5 VXI Technology, Inc. Required SCPI Commands ............................37 STATus:OPERation:CONDition? ........................37 STATus:OPERation:ENABle..........................38 STATus:OPERation[:EVENt]? ..........................39 STATus:PRESet ..............................40 STATus:QUEStionable:CONDition? .........................41 STATus:QUEStionable:ENABle........................42 STATus:QUEStionable[:EVENt] ........................43 SYSTem:ERRor? ..............................44 SYSTem:VERSion?............................45 Error Messages ..............................46 4.................................47 ECTION Calibration ................................47 Required Equipment ............................47 Procedure ................................47 ..................................49 NDEX VM7510 Preface...
  • Page 6 VXI Technology, Inc. shall not be liable for injury to property other than the goods themselves. Other than the limited warranty stated above, VXI Technology, Inc. makes no other warranties, express or implied, with respect to the quality of product beyond the description of the goods on the face of the contract.
  • Page 7 RODUCT ONFIGURATIONS VXI Technology, Inc. declares that the aforementioned product conforms to the requirements of the Low Voltage Directive 73/23/EEC and the EMC Directive 89/366/EEC (inclusive 93/68/EEC) and carries the “CE” mark accordingly. The product has been designed and manufactured...
  • Page 8 To avoid electrical overload, electric shock or fire hazard, do not Use Proper Power Source use a power source that applies other than the specified voltage. To avoid fire hazard, only use the type and rating fuse specified for Use Proper Fuse this product. VM7510 Preface...
  • Page 9 VXI Technology, Inc. ARNINGS To avoid electric shock or fire hazard, do not operate this product Avoid Electric Shock with the covers removed. Do not connect or disconnect any cable, probes, test leads, etc. while they are connected to a voltage source.
  • Page 10 UPPORT ESOURCES Support resources for this product are available on the Internet and at VXI Technology customer support centers. VXI Technology World Headquarters VXI Technology, Inc. 2031 Main Street Irvine, CA 92614-6509 Phone: (949) 955-1894 Fax: (949) 955-3041 VXI Technology...
  • Page 11 VXI Technology, Inc. VM7510 Preface...
  • Page 12 NTRODUCTION VERVIEW The VM7510 is a precision dc voltage standard which is designed to be used in conjunction with the VM2601 digitizer. The VM7510 provides a precision ±0.5 V signal which can be used to calibrate the VM2601 beyond its native accuracy specification. Additionally, the VM7510 provides signal-routing capabilities which allows the user to select either the measurement input, the internal precision dc source, or an external ac calibration source.
  • Page 13 VXI Technology, Inc. ACC/ERR FAIL J111 J112 VM2601 J113 (see the VM2601 User's J114 Manual for front panel connector information.) J115 J116 ACC/ ERR FAIL AC Reference In VM7510 Signal Input ZERO Output The multi-turn potentiometers at R3, R7, and R10 are used to adjust the signal from the output connector, J3.
  • Page 14 50 Ω UTPUT RIVE > 100 mA UTPUT CCURACY ±100 µV all output settings, into high impedance UTPUT DJUSTMENT ±5.0 mV all output settings, into high impedance. Front panel accessible multi-turn potentiometer. EMPERATURE TABILITY 25 ppm/°C TABILITY 50 ppm/yr VM7510 Introduction...
  • Page 15 VXI Technology, Inc. VM7510 Introduction...
  • Page 16 VM7510’s installation. After the chassis is assessed to be in good condition, it may be installed into an appropriate C-size or D-size VXIbus chassis in any slot other than slot zero.
  • Page 17 OGICAL DDRESS The logical address of the VM7510 is set by a single 8-position DIP switch located near the module’s backplane connectors (this is the only switch on the module). The switch is labeled with positions 1 through 8 and with an ON position. A switch pushed toward the ON legend will signify a logic 1;...
  • Page 18 ROGRAMMING The VM7510 is a VXIbus message-based device whose command set is compliant with the SCPI programming language. SCPI is a tree-structured language based on IEEE-STD-488.2 specifications. Based on this structure, the IEEE-STD-488.2 standard and device-dependent commands may have multiple branches from a trunk without repeating the trunk.
  • Page 19 OMMAND ISTING The following tables provide an alphabetical listing of each command supported by the VM7510 along with a brief description. If an “X” is found in the column titled *RST, then the value or setting controlled by this command is possibly changed by the execution of the *RST command.
  • Page 20 Query the Questionable Status Condition Register STATus:QUEStionable:ENABle Sets the Questionable Status Enable Register. STATus:QUEStionable[:EVENt] Query the Questionable Status Event Register SYSTem:ERRor? Query the Error Queue Clears queue SYSTem:VERSion? Query the version of the SCPI standard to which module complies. VM7510 Programming...
  • Page 21 VXI Technology, Inc. OMMAND ICTIONARY The remainder of this section is devoted to the actual command dictionary. Each command is fully described on its own page. In defining how each command is used, the following items are described: Describes the purpose of the command.
  • Page 22 Query Parameters Query Response This command clears all event registers, clears the *OPC flag and clears all queues Description (except the output queue). Examples Command / Query Response (Description) *CLS (Clears all status and event registers) None Related Commands VM7510 Programming...
  • Page 23 Bit 0 - Operation Complete Bit 1 - Request Control (not used in the VM7510) Bit 2 - Query Error Bit 3 - Device Dependent Error (not used in the VM7510) Bit 4 - Execution Error Bit 5 - Command Error...
  • Page 24 Bit 6 - User Request (not used in the VM7510, always 0) Bit 7 - Power On The Operation Complete bit is set by the VM7510 when it receives an *OPC command. The Query Error bit is set when data is over-written in the output queue. This could occur if one query is followed by another without reading the data from the first query.
  • Page 25 Query Parameters ASCII character string Query Response The Identification query returns the identification string of the VM7510 module. The Description response is divided into four fields separated by commas. The first field is the manufacturer’s name, the second field is the model number, the third field is an optional serial number, and the fourth field is the firmware revision number.
  • Page 26 Examples Command / Query Response (Description) *OPC (Sets the OPC bit in the Event Status Register) *OPC? 1 (Returns the value of the Event Status Register) *WAI Related Commands VM7510 Programming...
  • Page 27 VXI Technology, Inc. *RST Resets the module’s hardware and software to a known state Purpose IEEE 488.2 Common Command Type *RST Command Syntax None Command Parameters *RST Value None Query Syntax Query Parameters Query Response The Reset command resets the module’s hardware and software to a known state. See...
  • Page 28 Bit 6 - Master Summary Status Bit 7 - Operation Status Summary Examples Command / Query Response (Description) *SRE 4 (Sets the service request enable register) *SRE? 4 (Returns the value of the SRE register) *STB Related Commands VM7510 Programming...
  • Page 29 VXI Technology, Inc. *STB? Queries the Status Byte Register Purpose IEEE 488.2 Common Command Type None – query only Command Syntax Command Parameters *RST Value *STB? Query Syntax None Query Parameters Numeric ASCII value from 0 to 255 Query Response The Read Status Byte query fetches the current contents of the Status Byte Register.
  • Page 30 The Trigger command causes a trigger event to occur. This command is not used for Description this module and is provided for SCPI compliance only. Examples Command / Query Response (Description) *TRG (Triggers an event) None Related Commands VM7510 Programming...
  • Page 31 Query Syntax None Query Parameters Numeric ASCII value Query Response The Self-Test query causes the VM7510 to run its self-test procedures and report on Description the results. A value of 0 indicates that the test passed. Examples Command / Query...
  • Page 32 It provides a way of synchronizing the module with its master. Examples Command / Query Response (Description) *WAI (Pauses the execution of additional commands until the No Operation Pending message is true.) *OPC Related Commands VM7510 Programming...
  • Page 33 The Calibration Security Code command sets the code required to disable calibration Description security. Calibration security must first be disabled before the code can be changed. Before shipping the instrument, the factory code setting is VM7510. Examples Command / Query...
  • Page 34 Changing these values incorrectly can cause the instrument to perform improperly. Examples Command / Query Response (Description) CAL:SEC:STAT OFF,#16VM7510 (Disables calibration security) CAL:SEC:STAT 1 (Turns the calibration security back on) CAL:SEC:STAT? 1 (Indicates that calibration security is enabled) CALibration:SECure:CODE Related Commands VM7510 Programming...
  • Page 35 VXI Technology, Inc. DOWNLOAD Loads firmware updates into a module Purpose Event Type DOWNLOAD <section> Command Syntax <section> = 0 | 1 | 2 | 3 Command Parameters 0 is for the VMIP base code 1 is for the module in the top position...
  • Page 36 ROUTe can also be used to execute this command. Examples Command / Query Response (Description) SOUR SIG (Selects the Signal input to be routed to the Output jack). SOUR? SIG (Indicates the Signal input is routed to the output jack). ROUTe Related Commands VM7510 Programming...
  • Page 37 VXI Technology, Inc. VOLTage[:LEVel] / LEVel Sets the dc reference output voltage level Purpose Setting Type VOLTage[:LEVel] <value> or Command Syntax LEVel <value> <value> = POSitive | NEGative | ZERo Command Parameters *RST Value VOLTage[:LEVel]? or Query Syntax LEVel? Query Parameters <value>...
  • Page 38 Query Parameters Query Response The Operation Status Condition Register query is provided for SCPI compliance only. Description The VM7510 does not alter the state of any of the bits in this register and always reports a 0. Examples Command / Query...
  • Page 39 Query Response The Operation Status Enable Register is included for SCPI compatibility and the Description VM7510 does not alter any of the bits in this register. The register layout is as follows: Bit 0 - Calibrating Bit 1 - Setting...
  • Page 40 Query Parameters Query Response The Status Operation Event Register query is included for SCPI compliance. The Description VM7510 does not alter any of the bits in this register and always reports a 0. Examples Command / Query Response (Description) STAT:OPER?
  • Page 41 VXI Technology, Inc. STATus:PRESet Presets the Status Registers Purpose Required SCPI command Type STATus:PRESet Command Syntax None Command Parameters *RST Value None – command only Query Syntax Query Parameters Query Response The Status Preset command presets the Status Registers. The Operational Status Description Enable Register is set to 0 and the Questionable Status Enable Register is set to 0.
  • Page 42 Query Parameters Query Response The Questionable Status Condition Register query is provided for SCPI compliance Description only. The VM7510 does not alter any of the bits in this register and a query always reports a 0. Examples Command / Query...
  • Page 43 Enable Register. This command is provided only to comply with the SCPI standard. The Status Questionable Enable query reports the contents of the Questionable Status Enable Register. The VM7510 does not alter the bit settings of this register and will report the last programmed value.
  • Page 44 None Query Parameters Query Response The Questionable Status Event Register is provided for SCPI compliance only. The Description VM7510 does not alter the bits in this register and queries always report a 0. Examples Command / Query Response (Description) STAT:QUES?
  • Page 45 VXI Technology, Inc. SYSTem:ERRor? Queries the Error Queue Purpose Required SCPI command Type None – query only Command Syntax Command Parameters *RST Value SYSTem:ERRor? Query Syntax None Query Parameters ASCII string Query Response The System Error query is used to retrieve error messages from the error queue. The Description error queue will maintain the two error messages.
  • Page 46 Command Parameters *RST Value SYSTem:VERSion? Query Syntax None Query Parameters Numeric ASCII value Query Response The System Version query reports version of the SCPI standard to which the VM7510 Description complies. Examples Command / Query Response (Description) SYST:VERS? 1994.0 None...
  • Page 47 VXI Technology, Inc. RROR ESSAGES Should an error occur while commands are being sent to the VM7510, the following error messages may appear. These messages are in compliance with SCPI standards and can be retrieved by using the SYSTem:ERRor? query.
  • Page 48 1) Remove the cables attached to J1, J2, and J3. 2) Install the VM7510 into the VXIbus chassis. 3) Set the DMM to the 2 V dc range and connect the DMM to J3 of the VM7510. 4) Run the resource manager and open the VM7510 soft front panel.
  • Page 49 VXI Technology, Inc. VM7510 Calibration...
