Page 3
Lieferumfang Pos. Beschreibung Anzahl Adapterplatte Pin oben Hülse oben Hülsenadapter Zylinderkopfschraube M8 x 20 Distanzstück Pin unten Sperrzahnmutter M12 Montage der Rahmenhülse und des oberen Pins am Motorrad Montage der Rahmenhülse und des oberen Pins am Motorrad 1. Verkleidung entfernen: Schrauben heraus drehen und die Seitenverkleidung entfernen.
Page 4
4. Distanzstück am Motorrad befestigen: Mit der entfernten Schraube das Distanzstück [6] am Rahmen anschrauben. Dazu die Schraube von der anderen Seite des Rahmens einführen und anziehen. WICHTIG: Anzugsmoment der Schraube beachten. Das Anzugsmoment finden Sie im Werkstatthandbuch des Herstellers. 5.
Page 5
Montage Adapterplatte 7. Adapterplatte vormontieren: 1. Oberen Pin [2] an der Adapterplatte [1] verschrauben. 2. Unteren Pin [7] durch das Langloch stecken und mit der Sperrzahnmutter [8] auf der Rückseite kontern, aber nicht festziehen. 8. Adapterplatte fixieren: 1. Adapterplatte mit dem oberen Pin [2] an das Motorrad stecken und den unteren Pin [7] ausrichten.
Page 6
HINWEISE: 11. Für eine optimale Ausrichtung der Adapterplatte auf der Grundplatte [G1], ist eine erweiterte Grundplatte [G2] erhältlich. Die erweiterte Grundplatte kann jeweils um 180° gedreht werden. 12. Damit das Motorrad mit beiden Rädern gleich Die Anleitung für die Neigungseinstellung finden Sie auf unserer vom Boden abhebt, muss die Neigung Homepage.
Page 7
Adapter Plate Mounting Instructions EVOLIFT Kawasaki Z900 - Model Year.: 2021 - Version 1.0...
Page 8
Scope of delivery Description Quantity Adapter plate Upper pin Upper frame sleeve Sleeve adapter Cylinder head screw M8 x 20 Spacer Lower pin Lock nut M12 Fitting the frame sleeve and the upper pins to the motorcycle Fitting the frame sleeve and the upper pins to the motorcycle 1.
Page 9
4. Attach the spacer to the motorcycle: Use the removed screw to screw the spacer [6] to the frame. To do this, insert the screw from the other side of the frame and tighten. IMPORTANT: Observe the tightening torque of the screw.
Page 10
Mounting the adapter plate 7. Pre-assemble the adapter plate: 1. Screw the upper pin [2] to the adapter plate [1]. 2. Screw the lower pin [7] to the adapter plate using the lock nut [8], but do not tighten. 8. Fixing the adapter plate: 1.
Page 11
HINTS: 11. For optimum alignment of the adapter plate on the base plate [G1], an extended base plate [G2] is available; the extended base plate can be rotated by 180°. 12. The inclination must be adjusted so that both wheels The instructions for adjusting the tilt can be found on our homepage.
