- Page 1 �CRIS It a I Instruction Manual PART I: Generic Version Please read this manual carefully before use the dishwasher Keep this manual for future reference...
- Page 2 CONTENTS SAFETY INFORMATION PRODUCT OVERVIEW USING YOUR DISHWASHER Loading The Salt Into The Softener Basket Using Tips MAINTENANCE AND CLEANING External Care Internal Care Caring For The Dishwasher INSTALLATION INSTRUCTION About Power Connection Water Supply And Drain Connection Of Drain Hoses Position The Appliance Desktop Installation Built-In Installation(for the integrated model)
- Page 3 SAFETY INFORMATION WARNING When using your dishwasher, follow the precautions listed below: Installation and repair can only be carried out by a working environments; This appliance is intended to be used in household and similar applications such as: -staff kitchen areas in shops , offices and other working environments;...
- Page 4 experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. (For IEC60335-1) Packaging material could be dangerous for children! This appliance is for indoor household use only. To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid.
- Page 5 Do not modify the plug provided with the appliance; if it does not fit the outlet. Have a proper outlet installed by a qualified electrician. Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. Do not operate your dishwasher unless all enclosure panels are properly in place.
- Page 6 Do not wash plastic items unless they are marked “dishwasher safe” or the equivalent. For unmarked plastic items, please check the manufacturer's recommendations. Use only detergent and rinse agents recommended for use in an automatic dishwasher. Never use soap, laundry detergent, or hand washing detergent in your dishwasher.
- Page 7 Disposal For disposing of package and the appliance please go to a recycling center. Therefore cut off the power supply cable and make the door closing device unusable. Cardboard packaging is manufactured from recycled paper and should be disposed in the waste paper collection for recycling.
- Page 8 PRODUCT OVERVIEW IMPORTANT: To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Inner pipe Lower spray arm Salt container Filter assembly Dispenser Cup rack Upper spray arm Upper basket Lower basket NOTE: Pictures are only for reference, different models may be different.
- Page 9 USING YOUR DISHWASHER Before using your dishwasher : Inside Outside 1. Set the water softener 2. Load the salt Into the softener 3. Load the basket 4. Fill the dispenser Please check the section 1 “Water Softener” of PART Ⅱ: Special Version, Please check the section 1 “Water Softener”...
- Page 10 Please follow the steps below for adding dishwasher salt: 1. Remove the lower basket and unscrew the reservoir cap. 2. Place the end of the funnel (supplied) into the hole and pour in about 500g of dishwasher salt. 3. Fill the salt container to its maximum limit with water, It is normal for a small amount of water to come out of the salt container.
- Page 11 Basket Using Tips Adjusting the upper basket Type 1: The lower basket should be pushed into the dishwasher along the roller guide groove. The upper basket should be pushed into the dishwasher along the guide rail. Pull out the upper basket, Tilt the bowl basket up at a certain Remove the upper basket.
- Page 12 MAINTENANCE AND CLEANING External Care The door and the door seal Clean the door seals regularly with a soft damp cloth to remove food deposits. When the dishwasher is being loaded, food and drink residues may drip onto the sides of the dishwasher door. Any deposits should be wiped off before the door is closed.
- Page 13 Open Open Hold the coarse filter and rotate The fine filter can be pulled off it anticlockwise to unlock the fiter. the bottom of the filter assembly. Lift the filter upwards and out of The coarse filter can be detached the dishwasher.
- Page 14 Spray arms It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings. To clean the spray arms, follow the instructions below: To remove the upper spray arm, To remove the lower spray arm, pull hold the nut in the center still and out the spray arm upward.
- Page 15 Caring For The Dishwasher Frost precaution Please take frost protection measures on the dishwasher in winter. Every time after washing cycles, please operate as follows: 1. Cut off the electrical power to the dishwasher at the supply source. 2. Turn off the water supply and disconnect the water inlet pipe from the water valve. 3.
- Page 16 INSTALLATION INSTRUCTION WARNING Electrical Shock Hazard Disconnect electrical power before installing dishwasher. Failure to do so could result in death or electrical shock. Attention The installation of the pipes and electrical equipments should be done by professionals. About Power Connection WARNING For personal safety: Do not use an extension cord or an adapter...
- Page 17 Water Supply And Drain Cold water connection Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure ordinary supply hose that the water is clear.
- Page 18 Connection Of Drain Hoses Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making sure to avoid bending or crimping it. The free end of the hose must not be immersed in waterto avoid the back flow of it.You have three installation methods: A, B, and C.
- Page 19 Position The Appliance Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or walls. The dishwasher is equipped with water supply and drain hoses that can be positioned either to the right or the left sides to facilitate proper installation.
- Page 20 90° 90° Electrical, drain and water supply line entrances 610mm 610mm 550mm 550mm Space between cabinet bottom and floor 560 mm 2. If dishwasher is installed at the corner of the cabinet, there should be some space when the door is opened. Cabinet Dishwasher Door of...
- Page 21 TROUBLESHOOTING TIPS Before Calling For Service Reviewing the charts on the following pages may save you from calling for service. Problem Possible Causes What To Do Dishwasher doesn't Fuse blown, or the Replace fuse or reset circuit breaker. start circuit break tripped. Remove any other appliances sharing the same circuit with the dishwasher.
- Page 22 Problem Possible Causes What To Do Spilled rinse-aid. Always wipe up rinse-aid spills immediately. Stained tub interior Detergent with Make sure that the detergent has no colourant may colourant. have been used. Hard water minerals. To clean the interior, use a damp White film on inside surface sponge with dishwasher detergent...
- Page 23 Problem Possible Causes What To Do The dishes Not enough detergent Use more detergent, or change are not clean. was dispensed. your detergent. Items are blocking Rearrange the items so that the spray can rotate freely. the movement of the spray arms. The filter combination Clean the spray arm jets.
- Page 24 Problem Possible Causes What To Do The dishes aren't Wrong program has With a short program, the drying been selected. washing temperature is lower, decreasing cleaning performance. Choose a program with a long washing time. Use of cutlery with a Water drainage is more difficult with low-quality coating.
- Page 25 LOADING THE BASKETS 1.Upper basket: Item Number Rice scoop Rice bowls Condiment dishes Soup spoon Item Number Fish dish Shallow dishes Deep dishes Soup bowl Mug cups Glasses Noodle Bowls Little spoons Cutlery & fork basket...
- Page 26 3.Cutlery rack: Number Item Little spoons Soup spoon Rice scoop Chopsticks Information for comparability Capacity: 8 place settings Program: ECO Softener setting: H3...
- Page 27 �CRIS It a I Instruction Manual PART II: Special Version Please read this manual carefully before use the dishwasher Keep this manual for future reference...
- Page 28 The manufacturer, following a policy of constant development and updating of the product, may make modifications without giving prior notice. DD600 If lost or out-of-date, you can receive a new user manual from the manufacturer or responsible vendor.
- Page 29 QUICK USER GUIDE Please read the corresponding content on the instruction manual for detailed operating method. Install the dishwasher (Please check the section 5 “INSTALLATION INSTRUCTION ” PART Ⅰ: Generic Version.) Inside Outside Loading the baskets Removing the larger residue on the cutlery Filling the dispenser Selecting a program and running...
- Page 30 USING YOUR DISHWASHER Control Panel Operation (Button) Power Press this button to turn on your dishwasher, the screen lights up. press this button to start the selected washing program when the program does not start, and press this button to stop the current Start/Pause washing program at run time.
- Page 31 Display 90 Min For normally soiled loads that need quick wash. This is the standard program suitable for normally soiled loads, such as pots, plates, glasses and lightly soiled pans. Program Glass indicator For lightly soiled crockery and glass. Rapid A shorter wash for lightly soiled loads that do not need drying.
- Page 32 Water Softener The water softener must be set manually, using the water hardness dial. The water softener is designed to remove minerals and salts from the water, which would have a detrimental or adverse effect on the operation of the appliance. The more minerals there are, the harder your water is.
- Page 33 The manufactory setting: H3 Contact your local water board for information on the hardness of your water supply. Please check the section 3 “Loading The Salt Into The Softener” Please check the section 3 “Loading The Salt Into The Softener” of PART Ⅰ: Generic Version, If your dishwasher lacks salt.
- Page 34 Recommendations for loading the dishwasher Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans. It is not necessary to rinse the dishes under running water. For best performance of the dishwasher, follow these loading guidelines. (Features and appearance of baskets and cutlery baskets may vary from your model.) Place objects in the dishwasher in following way:...
- Page 35 Loading the upper basket The upper basket is only suitable for placing small and slender tableware, such as small bowls, dishes, soup spoons, rice spoons and other light heat-resistant plastic tableware. Loading the cutlery basket Cutlery should be placed in the cutlery rack separately from each other in the appropriate positions, and do make sure the utensils do not nest together, this may cause bad performance.
- Page 36 Function Of The Rinse Aid And Detergent The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids.
- Page 37 Filling The Rinse Aid Reservoir Open the lid in the direction of Pour the rinse aid into the dispenser, the arrow. being careful not to overfill. Close the lid in the direction of the arrow. NOTE: Clean up any spilled rinse aid with an absorbent cloth to avoid excessive foaming during the next wash.
- Page 38 Filling The Detergent Dispenser Push the button to the left and the cover will automatically pop down. Add detergent into the larger cavity (A) for the main wash cycle. For better cleaning result, especially if you have very dirt items, pour a small amount of detergent onto the door.
- Page 39 PROGRAMMING THE DISHWASHER Wash Cycle Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. )Means: need to fill rinse into the Rinse-Aid Dispenser. Detergent Energy Water...
- Page 40 NOTE: EN 50242: This program is the test cycle. The information for comparability test in accordance with EN 50242. Starting A Cycle Wash 1. Draw out the lower and upper basket, load the dishes and push them back. It is commended to load the lower basket first, then the upper one. 2.
- Page 41 1.Press the start/pause button to pause the running washing program. 2. Press Start/Pause button more than three seconds the machine will be in standby state. 3. You can change the program to the desired cycle setting. 4. Press the start/pause button. 5.
- Page 42 ERROR CODES If there is a malfunction, the dishwasher will display error codes to identify these: Meanings Codes Possible Causes Too much water has entered or the Overflow. machine is leaking. The faucet is not open, the water pressure is too low, or the water inlet Abnormal water inlet.
- Page 43 TECHNICAL INFORMATION Height (H) 595mm Width (W) 550mm Depth (D1) 500mm (with the door closed) Depth (D2) 980mm (with the door opened 90°)
- Page 44 Sheet of household dishwasher according to EU Directive 1016/2010 & 1059/2010: CRISTAL Model No. DD600 Standard place settings Energy efficiency class Annual energy consumption 201.6 kWh Energy consumption of the standard cleaning cycle 0.72 kWh Power consumption of off-mode 0.45 W Power consumption of left-on mode 0.49W...
- Page 45 總代理 長 富 ( 建 材 ) 有 限 公 司 www.gtgroup.com.hk Service Hotline: (852) 3752 6111...
