- Page 1 MEDIA DECODER Quick Start Guide ®...
- Page 2 Overview ® Welcome to the Nodestream Quad Decoder (NQD) Please read these instructions carefully before using this product and save this quick start guide for future reference. See the User Manual for full details via the QR code on the back page.
- Page 3 Overview ® Rear Connections Power Power Switch Socket USB-A Line In Serial Port Line Out DO NOT USE Mic In PS/2 HDMI DisplayPort USB-A USB-A Mini DisplayPort (output to monitors) IMPORTANT: 100-240VAC 47/63HZ only (UPS recommended). Do not use the Display Port or HDMI for output to monitors. (Use the Mini-Display port only).
- Page 4 Installation ® The NQD is designed to be mounted in a standard 19” Rack and occupies 3U of space Install at 4 mount points Mount points Connect devices as shown Power input Monitor output(s) Speakerphone (USB extension must not exceed 5m) Ensure there is adequate spacing around the NQD device for cooling.
- Page 5 Default password = admin Configure device network settings as provided by your Network Administrator If required, enter your Enterprise Server ID & key on the “System” page Once configuration is complete, your device will show online in the Harvest Control application User Manual Refer to the device User Manual for additional information.
- Page 6 Bentley WA 6102, Australia harvest.technology All rights reserved. This document is the property of Harvest Technology Pty Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, photocopy, recording or otherwise without the written consent of the CEO of ®...
