- Page 1 AVR2 MEDIA ENCODER Quick Start Guide ™ ®...
- Page 2 Overview ® Welcome to the Nodestream AVR2 Please read these instructions carefully before using this product and save this quick start guide for future reference. See the User Manual for full details via the QR code on the back page.
-
Page 3: Rear Connections
Overview ® Rear Connections Power Switch Power Socket IMPORTANT: 100-240VAC 47/63HZ only (UPS Recommended) For further information on connections, refer to AVR2 User Manual. Front Interface RESET the AVR2 unit START streaming video and/or data STOP streaming video and/or data VIEW the preview screen (display) Display... -
Page 4: Installation
Installation ® The AVR2 is designed to be mounted in a standard 19” rack and occupies 2U of space Ensure there is adequate spacing around the AVR2 device for cooling. The cool air travels in the direction as shown by the arrows. No vertical loading on the AVR2 device. - Page 5 Start Up ® Switch on the power (on the rear of the AVR2 unit) The device is configured to auto start when AC power is applied. The LEDs on the interface panel turn on and the display turns on AVR2 MEDIA ENCODER Once the unit has powered up, the status is indicated by the STREAMING LED...
-
Page 6: Troubleshooting
Bentley WA 6102, Australia www.harvest.technology All rights reserved. This document is the property of Harvest Technology Pty Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, photocopy, recording or otherwise without the written consent of the ®...
