Clas Ohlson MF-H05 Manual

Rechargeable Head Torch
Art.no 31-2580 Model MF-H05
Please read the entire instruction manual before using the product and then
save it for future reference. We reserve the right for any errors in text or images
and any necessary changes made to technical data. If you have any questions
concerning technical problems please contact our Customer Services.
Safety
• Do not point the light beam into anyone's eyes.
• Do not let children play with the product.
• Never charge the torch in flammable environments or on flammable
surfaces.
• Only use the rechargeable batteries provided with the product.
• Never use a defective charger cable.
• Never expose the batteries to fire or high temperatures.
• Avoid contact with leaking batteries.
Product description
1 2 3
5
9
6 7
8
1. LED light
2. Magnetic mounts on the headband (for the LED light and battery pack)
3. Mount for bike handlebars or for using as a work light
4. Battery pack
5. USB-C cable
6. 2x 18650 batteries
7. Cover for battery pack
8. Focus adjuster
9. Power switch, LED indicator
10. Magnetic mounts for battery pack and LED light, used together with (2) or (3).
11. USB-C port
Inserting batteries
Remove the battery cover (7) and insert
the rechargeable 18650 batteries provided,
following the polarity markings in the
battery pack (4).
Note: The batteries are connected in parallel
and must all point in the same direction
when inserted into the battery holder. Press
the lid firmly onto the battery pack.
2 4
Charging the head torch
1. Connect the USB cable to the USB-C port on the battery pack and to a
USB outlet.
2. The battery indicator will show the charging status:
Red 0–25%
Orange 25–75%
Green 75–100%
Note: The charging time will vary depending on the power source used.
For example, if the head torch is charged from a computer USB port,
the charging time can be twice as long.
Using the product
The product can be used as a head torch, work light and bike headlight.
The LED lamp and battery pack are attached by magnets to the headband
and the handlebar mount, and also to any iron or steel surface.
1. Switch the head torch on by pressing
the switch repeatedly: high power (350 lm) – low power (100 lm) – off.
2. The head torch also has a boost mode for greater light intensity (750 lm).
10
Activate boost mode by first switching the head torch on and then holding
down for about 4 seconds until the light brightens substantially.
The boost mode lasts for about 60 seconds and then the torch goes into
high power mode.
3. Adjust the light beam by moving the focus adjuster (8) forwards or
11
backwards.
Head torch
Bike light
Undo the locking knob (13) and put the
mount over the handlebars. Insert one or
more of the rubber spacers (12) between
the handlebars and the mount. Tighten the
locking knob and make sure that the mount
is securely fitted to the handlebars.
Care and maintenance
Clean the torch using a soft, damp cloth.
Never use cleaning agents or other chemicals.
Responsible disposal
This symbol indicates that this product should not be disposed of
with general household waste. This applies throughout the entire EU.
In order to prevent any harm to the environment or health hazards
caused by incorrect waste disposal, the product must be handed in
for recycling so that the material can be disposed of in a responsible
manner. When recycling your product, take it to your local collection
facility or contact the place of purchase. They will ensure that
the product is disposed of in an environmentally sound manner.
Specifications
Charging voltage
Battery
Operating time
and choose a mode by pressing
Colour temperature
Colour rendition
Power
Lumens
Operating temperature
Protection class
Weight
English
Work light
12 13
5 V DC from a USB charger
(USB charger sold separately)
Li-ion-battery 2800 mAh (type 18650) (2 ×)
Up to 3.5 hours (on high power),
up to 6 hours (on low power)
6000 K
Ra 70
10 W
750lm (60 sec in boost-mode),
350 lm (high power), 100 lm (low power)
−20 to +50 ºC
IP 44
Approx 325 g (battery pack, LED lamp
and headband)
