Eiko SEN5A-SPMR-WH Manual

SEN
Screw-in Microwave Motion Sensor: Stand-alone
H I G H L I G H T S
•
Screw-in Microwave Motion Sensor for Stand-alone Controls
•
Designed for use with EiKO's fixtures featuring screw-in receptacle for quick and easy
installation in the field
•
Features microwave technology; used for automatically turning the lights on when
occupancy is detected and off when there is no occupancy detected
•
Field adjustable settings included: brightness (high-end trim), dim level, sensitivity, hold
time, and dim time for customized lighting control
•
Dual ambient and daylight sensing technology improves accuracy in outdoor applications
when the sensor is within the range of artificial light emitted from the fixture, resulting in
a more energy-efficient and reliable lighting system
•
Daylight harvesting for energy efficiency*
•
Occupancy detection can be disabled, and the sensor can function as a photocell alone
•
Photocell function can be used as traditional dusk-to-dawn or two-stage dimming/
midnight dimming
•
Robust design for reliable operation in various environments
•
Impressive -40°F (-40°C) operating temperature
•
Supports maintenance-friendly features such as remote commissioning
C E R T I F I C A T I O N S
•
ETL listed for US & Canada
•
RoHS Compliant
•
FCC Compliant
•
IP65 Rated
P E R F O R M A N C E
•
Mounting Height: 8-40ft
•
0-10V Bi-Level Dimming
•
360˚ Coverage Pattern
E L E C T R I C A L
•
Input Voltage: 12-24VDC
•
Input Current: 50mA
•
Dimming: 0-10V
•
Remote Control: SEN5A-ACT (Purchased Separately)
T H E R M A L
•
-40°F to 140°F (-40°C to 60°C) operating temperature
C O N S T R U C T I O N
•
High strength, UV-resistant white polycarbonate housing
•
Screw-in installation
C O M P A T I B I L I T Y
•
Fixtures: AAL1, PG1, LH1, LHC1, HBV2, BAYE3, HBX2, HBX3, FL5, and SIG2
F A C T O R Y D E F A U LT S E T T I N G S
•
Brightness: 100%
•
Sensitivity: 75%
•
Hold Time: 10 minutes
•
Daylight Function: Disable
•
Dim level: 30%
•
Dim Time: 1 minute
W A R R A N T Y
•
5-Year limited warranty available online. Contact your EiKO sales rep for additional details.
* For detailed instructions on how to configure the daylight harvesting setting, please refer to the SEN5A-ACT Operation Instructions
1
©2023 EiKO Global, LLC. World Headquarters: 18000 W. 105
Head Office, Canada: 7900 Goreway Dr Unit 8, Brampton, ON L6T 5W6 1.888.741.2673
project name
catalog number
approved by
A P P L I C A T I O N S
•
Warehouse
•
Manufacturing Plants
•
Distribution Centers
•
Gymnasiums
•
Parking Garage
SEN5A-ACT Operation
Street, 3 Floor, Olathe, KS 66061 1.800.852.2217
th rd
type
voltage
date
•
Parking Lots
•
Car Dealerships
•
Athletic Facilities and Sports Field
•
Big Box Retail
•
Service Repair Center
Instructions.
eiko.com
Rev. 12/20/23
