- Page 1 FichtelBahn Handbuch / Manual ReadyServo8 eady Line...
- Page 2 The most recent version of this manual can be found in the download section of the FichtelBahn webpage. The version number in the footer will shows the current version. New functions und additions are always published in the online version on the webpage first.
- Page 3 Switch off the voltage supply before carrying out wiring work. Only use wire with suf- ficient cross-section. Wait for 2 hours after accumulation of condensate. Manual ReadyServo8 Page 3 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 4 85 % Dimensions casing 100mm x 90mm x 34mm / 3.94 in x 3.54 in x 1.34 in Weight 85 g / 3 oz Manual ReadyServo8 Page 4 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 5 (each port can be switched individually using the BiDiB tool „BiDiB-Wizard“) 5V voltage output for GPIO add-on modules 8x servo outputs (servo 0 to servo 7) Manual ReadyServo8 Page 5 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 6 DCC 1 Input Source POWER 5V DCC IN DCC BiDiB XP STATE DCC 1 DCC 2 EXT.STOP GPIO-PORT SERVO 0 - 3 SERVO 4 - 7 Manual ReadyServo8 Page 6 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 7 If the termination jumper is fitted on a module within the bus the transmission might be disrupted. Both cases will not lead to any damage of the modules. Manual ReadyServo8 Page 7 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 8 It is recommended to keep the cable length between the module and the servo short for safe operation. Cable lengths exceeding 2 metres should always be avoided. In the FichtelBahn-Shop you will find a 50cm servo cable extension with the article no. 000830. Manual ReadyServo8 Page 8 ©...
- Page 9 Here a large travel distance should be chosen and servos with metal gears should be used. In the FichtelBahn-Shop you will find a reliable and inexpensive solution with the article no. 410100...
- Page 10 If the GPIO-0 is required as an input, the change is made in the desired „Input“ category and on the relevant „Port“. Right-click on the port to open the „Switch port“ dialogue. Manual ReadyServo8 Page 10 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 11 The BiDiB-Wizard 2 is a Java program for displaying and configuring the BiDiB modules on the BiDiBus. The current version BiDiB-Wizard 2 is available for free download in our BiDiB-Wiki at https://wiki.fichtelbahn.de ( in the overview tree under „Programme für BiDiB“...
- Page 12 8 servo outputs and their control characteristics, position up / down, speed Flags Visualisation of internal flags for macro programmings CV Definitions Reading and writing of module specific CV settings (see Module settings on page 29) Manual ReadyServo8 Page 12 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 13 In addition to the configurator, the macros for a customised configuration can always be used. The wizard automatically creates macros, which can be changed after completion. Manual ReadyServo8 Page 13 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 14 The last saved values can be read with “Revert”. Manual ReadyServo8 Page 14 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 15 Effect applications e.g. shed gates, waving pedestrians Effect / Parts • Servo and relay separated Effect applications for servo movements and separate relay for switching of loads Manual ReadyServo8 Page 15 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 16 GND 5V Data Illustra�on exemplary for all eight outputs *mechanics simplified Node configurator Application examples Turnouts • servo and frog relay Servo turnout with frog polarisation Manual ReadyServo8 Page 16 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 17 Application examples Turnouts • servo and inputs Input operates servo e.g. external control panel or push-button at the edge of the layout / manual control Manual ReadyServo8 Page 17 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 18 GND 5V DATA Illustra�on exemplary for all eight outputs * mechanics simplified Node configurator Application examples Turnouts • Servo and sensor Servo turnout with position feedback Manual ReadyServo8 Page 18 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 19 220 Ohm Servo 7 Servo port assignment GND 5V Data Breakout power assignment on ReadyServo8 PORT X GND PORT X op�cal stop point Servo 6 Manual ReadyServo8 Page 19 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 20 “Servo, Relay and Feedback” from the Node Configurator. For other applications, individual steps can be omitted or configured differently. Manual ReadyServo8 Page 20 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 21 In the “Input ports” window, the states of the 4 inputs can be monitored. A user- defined name can be assigned in the “Input” field. A red box indicates an active input, a grey box indicates an inactive input. Manual ReadyServo8 Page 21 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 22 Waiting time in ticks (1 tick = 20ms with a slowdown factor of 1). After the waiting time has elapsed, the action of the macro step is executed. Manual ReadyServo8 Page 22 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 23 Selection of the port (e.g. servo 0-3) Extra Special functions and settings e.g. target value 0-100% for servos Please notice: Macro steps can be added and deleted with a right click. Manual ReadyServo8 Page 23 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 24 --> change the target position from 0% to 100%. the input reacts to the wrong state --> swap action “Wait until value=0” to value=1 Manual ReadyServo8 Page 24 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 25 Accessory Begriffe Einem Accessory können hier Begriffe zugeordnet werden, die mit einem Makro verknüpft werden. Please notice: Macro steps can be added and deleted with a right click Manual ReadyServo8 Page 25 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 26 For turnout B, port 0 is replaced by another value in the properties. e.g. 1 for Acces- sory 1. Manual ReadyServo8 Page 26 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 27 Straight movement with rough beginning and end Smooth Straight movement with soft beginning and end e.g. turnout Seesaw Rocking of a semaphore signal Bouncing Rebouncing of a railway barrier Manual ReadyServo8 Page 27 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 28 “Start macro X” can be add to macro 0 to 7. Input 3 macro Input 4 macro Input 5 macro Input 6 macro Input 7 macro Manual ReadyServo8 Page 28 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 29 The “Features” window can be opened here. Please notice: Only make changes to these settings after consulting FichtelBahn technical support. 06.2 CV register of the ReadyServo8 With a click on the „CV Definitions“ tab (1), the CV registers become visible in the BiDiB Wizard.
- Page 30 (e.g. node configuration) by BiDiB Wizard 2. Changes to the features or CV registers are not necessary and should not be made without consulting FichtelBahn technical support. 06.3.1 PowerOFF behaviour of the servos Servo x:...
- Page 31 07.2 Error states at module start 10x fast flashing (1, 2, 3) Power-ON LED, BiDiB-Identify LED, Message LED no bootloader found / no firmware update possible (contact FichtelBahn support) permanent flashing (1, 2, 3) Power-ON LED, BiDiB-Identify LED, Message LED EEPROM faulty (carry out a firmware update, see „09.
- Page 32 BiDiBus to avoid reflexions. The terminating resistor of 120 Ohms is part of every BiDiB module and is activated by fitting the corresponding jumper. Manual ReadyServo8 Page 32 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 33 Click on the button “Update firmware” (2.). In the new window choose the firmware zip file (3.) which can be loaded from the FichtelBahn website. Tick the check box (4.) for the desired firmware and proceed by clicking “Start” (5.). During the update process the Message-LED of the ReadyBoost module is lit.
- Page 34 20 euros. We reserve the right to refuse the repair of an assembly if this is not technically possible or uneconomical, there are no additional costs. Manual ReadyServo8 Page 34 © 2024 FichtelBahn® Manual Version 1.1 Technical changes and errors reserved...
- Page 35 12. Declaration of Conformity Hiermit erklärt FichtelBahn, dass die Baugruppe „ReadyServo8“ der Richtlinie 2014/30/EU entspricht. Der vollständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: www.fichtelbahn.de/declaration.html...
- Page 36 © 2024 FichtelBahn® Am Dummersberg 26 Alle Rechte, insbesondere das Recht der Vervielfältigung und Verbreitung sowie D-91220 Schnaittach FichtelBahn der Übersetzung vorbehalten. Vervielfältigungen und Reproduktionen in jeglicher Form bedürfen der Tel.: +49 9153 9703051 schriftlichen Genehmigung durch FichtelBahn. support@fichtelbahn.de Technische Änderungen vorbehalten.
