TYLO FLOOR STANDING PRO MODEL HEATERS

FOR LARGE AND COMMERCIAL SAUNAS

Need help?

Do you have a question about the Tylo Pro 105 and is the answer not in the manual?

Questions and answers

Summary of Contents for SaunaFin Tylo Pro 105

Page 1 TYLO FLOOR STANDING PRO MODEL HEATERS FOR LARGE AND COMMERCIAL SAUNAS...
Page 2 TYLO FLOOR STANDING PRO MODEL HEATERS FOR LARGE AND COMMERCIAL SAUNAS Tylo Sauna Control Panels Introducing Elite and Pure TYLOHELO PRO MODEL SAUNA HEATERS For decades Tylö has been the obvious choice for saunas in hotels, clubs, swimming baths and sports facilities.
Page 3 TYLO FLOOR STANDING PRO MODEL HEATERS FOR LARGE AND COMMERCIAL SAUNAS PURE INTUITIVE DESIGN AND FEATURES The elegant, compact design of Tylö’s Pure control panel makes it the go-to choice for those who value functionality and advanced technology without compromising on aesthetics. The ultra-thin black control lights up on touch and lets you set the lighting, temperature and sauna time by simply pressing a few buttons.
Page 4 TYLO FLOOR STANDING PRO MODEL HEATERS FOR LARGE AND COMMERCIAL SAUNAS TYLOHELO PRO MODEL SAUNA HEATER Freestanding Pro heaters have been the standard of the industry for more than 20 years. Designed for large, commercial-sized sauna rooms and for use with separate control panels.
Page 5 TYLO FLOOR STANDING PRO MODEL HEATERS FOR LARGE AND COMMERCIAL SAUNAS OPTIONAL EXTERNAL SWITCH FOR TYLO PRO HEATERS This momentary, illuminated switch provides simple ON/OFF function to your Tylo Plus or Combi heater. This optional external switch will provide the sauna bather with the ability to turn the sauna ON or OFF only. When the momentary switch is activated, the power icon will illuminate in blue and activate the sauna session that has been programmed into the main control.
Page 6 INSTALLATION AND OPERATING INSTRUCTIONS Page 1 WARNING Do not take a sauna if using alcohol, drugs or medications. External Pregnant women or persons Switch with poor health should Pro Heater 1601-36 consult their physician before 1105-XXX using any sauna. Pure 2.0 Elite Control Control...
Page 7 INSTALLATION AND OPERATING INSTRUCTIONS Page 2 SECTION 2: MOUNTING OF SAUNA HEATER WARNING Carefully locate the heater according to the dimensions shown in Diagram 1 Fire sprinkler systems used and bolt it to the floor. (Bolts are not supplied with the heater.) Tighten to inside any sauna room secure the heater in place.
Page 8 INSTALLATION AND OPERATING INSTRUCTIONS Page 3 DIAGRAM 1 Pro Heater 3" Model # 1105-XXX High Limit Control Reset Sensor 49½" min. 5" 1x1" min. wooden 78" 2½" post min. 5" min. min. ¾ x 4" wooden 2½" rail min. 27" max.
Page 9 INSTALLATION AND OPERATING INSTRUCTIONS Page 4 DIAGRAM 1 Locate the sensor 3" from ceiling directly above the heater. Contactor Box Room light outlet box Recess Mount 70" up from the ﬂoor. All wiring for sauna system or ac- cessories should be routed inside the walls or away from the high tem- Locate the control perature air from the sauna heater.
Page 10 INSTALLATION AND OPERATING INSTRUCTIONS Page 5 TABLE 1 Minimum Room Maximum Room Copper Wire Size 90° C Heater Power Contactor Light Circuit Model / Floor Wall Volume Wall Volume Contactor ** Breaker Supply to Contactor to Heater Contactor to or Fan Product Area Height...
Page 11 INSTALLATION AND OPERATING INSTRUCTIONS Page 6 DIAGRAM 4 CONTACTOR BOX CB 10-1 Sensor (Model # 1201-10-1) L1 L2 L1 L2 T1 T2 T3 T4 Transformer External T1 T2 T3 T4 1 Switch Not Used 1601-36 High (Optional) Limit Sensor L1 L2 L1 L2 Light External Heater Output...
Page 12 INSTALLATION AND OPERATING INSTRUCTIONS Page 7 DIAGRAM 4, Continued CONTACTOR BOX CB 10-3 Sensor (Model # 1201-10-3) T1 T2 T3 L1 L2 L3 Transformer External T1 T2 T3 Switch Not Used (Optional) High Limit (1601-36) L1 L2 L3 Sensor Light External Heater Output Switch...
Page 13 INSTALLATION AND OPERATING INSTRUCTIONS Page 8 DIAGRAM 4, Continued Heater Models 1105-105 / 1105-1052 1105-120 / 1105-1202 1105-140 / 1105-1402 1 Phase Block Wiring Diagram T3 T4 1 2 208V or 240V 1-Phase High Limit Not Used T1 T2 T3 T4 1 L1 L2 L1 L2 Light Sensor...
Page 14 INSTALLATION AND OPERATING INSTRUCTIONS Page 9 DIAGRAM 4, Continued Heater Models 1105-105 / 1105-1052 1105-120 / 1105-1202 1105-140 / 1105-1402 3 Phase Block Wiring Diagram 208V or 240V 3-Phase High Limit Not Used T1 T2 T3 L1 L2 L3 Light Sensor External Light...
Page 15 INSTALLATION AND OPERATING INSTRUCTIONS Page 10 WARNING SECTION 7: CONTROL INSTALLATION & OPERATION Do not locate benches over CONTROL OPTIONS: This heater has two different control options. An Elite Control (1601-33 or 1601-33-1) or Pure 2.0 Control (1601-40 or 1601-40-1) heater.
Page 16 SECTION 7: ELITE CONTROL OPERATION (1601-33 or 1601-33-1) Home Screen A. - Off Button B. - On Button C. - Current Room Temperature D. - Home Button E. - Temperature Button F. - Favorites Button G. - Calendar Button H. - Settings Button To Start Immediately 1.
Page 17 INSTALLATION AND OPERATING INSTRUCTIONS Page 12 SECTION 7: ELITE CONTROL (1601-33 or 1601-33-1) OPERATION, Continued Calendar Screen Options Adding One Time Event Adding One Time Event Adding One Time Event Calendar Showing Event Scheduled Click the date for the event. Click the + to add event.
Page 18 INSTALLATION AND OPERATING INSTRUCTIONS Page 13 SECTION 7: ELITE CONTROL (1601-33 or 1601-33-1) OPERATION, Continued Temperature Screen Options Temperature and Room Light Sauna Duration Creating Favorites Change temperature by pressing + Change sauna length by pressing Ensure temperature and sauna or - to desired temperature.
Page 19 INSTALLATION AND OPERATING INSTRUCTIONS Page 14 SECTION 7: ELITE CONTROL (1601-33 or 1601-33-1) OPERATION, Continued Calendar Screen Options Setting Screen Options Viewing Scheduled Events Setting Options Click the in the upper Select the icon in the lower right corner of the control to access right corner to see events.
Page 20 INSTALLATION AND OPERATING INSTRUCTIONS Page 15 SECTION 7: ELITE CONTROL (1601-33 or 1601-33-1) OPERATION, Continued Phone Application Setup Screen Your Elite Cloud control panel has been pre-registered for cloud connection. After connecting your Elite control to your WLAN Network, press Enable on the Cloud menu under Wi system settings. Application Home Screen Network Choose Network...
Page 21 INSTALLATION AND OPERATING INSTRUCTIONS Page 16 SECTION 7: ELITE CONTROL (1601-33 or 1601-33-1) OPERATION, Continued Connecting Phone to Control Scan Message QR Code Connect Device Scan QR code on phone and a On Elite Cloud Control Panel select A QR Code will appear on the success message will appear Settings →...
Page 22 INSTALLATION AND OPERATING INSTRUCTIONS Page 17 SECTION 7: PURE 2.0 CONTROL (1601-40 or 1601-40-1) OPERATION, Continued A. On/Off Light switch B. Indicators - lights for lighting, door switch (n/a), timer and the heater C. On/Off Sauna Switch and fault alarms D.
Page 23 INSTALLATION AND OPERATING INSTRUCTIONS Page 18 SECTION 7: EXTERNAL SWITCH CONTROL (1601-36) OPERATION External Switch This momentary, illuminated switch provides simple ON/OFF function to your Trend or Premium Sauna Control. In a commercial environment, it is recommended that the main Sauna Control be located either in a utility closet or at the Attendant's desk so the sauna time and temperature functions can be secured from the general public.
Page 24 INSTALLATION AND OPERATING INSTRUCTIONS Page 19 SECTION 10: WARNING PLACARDS Two metal placards are included in the Installation Instruction Envelope packaged with every Sauna Heater. The CAUTION placard must be attached to the interior wall of the sauna room directly above the heater where it is visible to the bather.
Page 25 INSTALLATION AND OPERATING INSTRUCTIONS Page 20 DIAGRAM 5 The "CAUTION" and "WARNING" placards must TYPICAL PRE-CUT WALL CONSTRUCTION be mounted in accordance 2x4" framing 1/2" wallboard with Section 10. fiberglass insulation foil vapor barrier T&G soft wood 1/2" wallboard SECTION 12: VENTILATION VENTILATION Ventilation shall be provided in a sauna, the air For safety purpose sauna should be changed about 6 times an hour.
Page 26 INSTALLATION AND OPERATING INSTRUCTIONS Page 21 SECTION 13: MAINTENANCE Inspect sauna room at the end of each day the room to ensure the control and system is oﬀ. The sauna, like a bathroom, should be kept clean and odor free. Towels or mats should always be used on benches and ﬂoor as perspiration otherwise penetrates the soft wood.
Page 27 INSTALLATION AND OPERATING INSTRUCTIONS Page 22 DIAGRAM 7: ROOM TEMPERATURES 190° F Ceiling Non-Typical Ceiling Height 140° F Head Height Notes: Temperatures vary in a sauna room by height and distance from heater. Ventilation will help reduce it but will not eliminate temperature variations.
Page 28 INSTALLATION AND OPERATING INSTRUCTIONS Page 23 SECTION 15: TROUBLESHOOTING Control will Run but No Heat - Press the (reset) high limit switch on the back right side of heater. Slow Heat Time or High Limit Tripping - Check rock placement, they will break down over time and reduce the air ow in the heater.
Page 29 SAUNAFIN SAUNA & STEAM 115 Bowes Road Unit #2, Concord, Ontario L4K 1H TOLL-FREE PHONE 1-800-387-7029 905-738-4017 EMAIL info@saunafin.com www.saunafin.com...

This manual is also suitable for:

Tylo pro 120 Tylo pro 140
