  • Page 1 T100 Smart Soldering Station User Manual Smart Soldering Station User Manual User Manual Download Revision history Version Date Modify V1.0 2019/11/18 First release V1.1~V1.4 2021/12/21 Modify some details V1.5 2023/07/26 Change the handle and related images...

  • Page 2: Table Of Contents

    Contents 1. Description ......................1 2. Specifications ......................1 3. Packing list ......................1 4. Install before use ....................2 4.1 Install the iron tip ........................ 2 4.2 Inset the handle ........................2 5. Panel description ....................3 5.1 Front panel .......................... 3 5.2 Rear panel ...........................

  • Page 3: Description

    Thank you for purchasing this product. We recommend that you spend some time reading this user manual in order that you fully understand all the operational features it offers. 1. Description T100 is a smart multi-function soldering station. It has the following characteristics:  Small size and light weight, portable.

  • Page 4: Install Before Use

    T100 Smart Soldering Station User Manual Smart Soldering Station 4. Install before use 4.1 Install the iron tip 4.2 Inset the handle...

  • Page 5: Panel Description

    T100 Smart Soldering Station User Manual Smart Soldering Station 5. Panel description 5.1 Front panel Fig 5.1 front panel Set temp: range is 80~500℃. Using time: In units of minutes. Heating indication: display when heating, flashing at constant temperature, not displayed when cooling.
  • Page 6 T100 Smart Soldering Station User Manual Smart Soldering Station Type-C interface: Connect a power bank that supports fast charging, support PD2.0 \ QC3.0 fast charge protocol (note: 20V by default, 50W heating power). Note: 1. Some quick chargers can only output 12V, heating power is only 18W.

  • Page 7: Display Description

    T100 Smart Soldering Station User Manual Smart Soldering Station 6. Display description Fig 6.1 system flow As shown in Figure 6.1 System work flow chart, the working status of the soldering station can be divided into the following four types: Normally(Main UI): Heating and constant temperature at set temp.

  • Page 8: Setting Menu Description

    T100 Smart Soldering Station User Manual Smart Soldering Station 7. Setting menu description Note: Double-click the encoder to enter the menu UI, click to enter next menu, long press to exit. 6.1 Voltage info Display the current working voltage. If 220V is connected, the internal power supply voltage is 25.2V.

  • Page 9: Standby Time

    T100 Smart Soldering Station User Manual Smart Soldering Station 6.5 Standby time In the sleeping state. If the handle is not used within the standby time, it enters the standby state, the tip no heating, and the vibrating handle or rotary encoder exits. This time range: 10sec~20min,or turn off.

  • Page 10: Parameter Calibration

    T100 Smart Soldering Station User Manual Smart Soldering Station 6.9 Parameter calibration Note: Temperature calibration requires a soldering iron thermometer! TMP: Show the calibration temperature point; CAL: After using the soldering iron thermometer to measure the actual temperature, adjust this value.

  • Page 11: Version Information

    T100 Smart Soldering Station User Manual Smart Soldering Station 6.12 Version information Version information: The firmware version of the current soldering station.

  • Page 12: Firmware Upgrade

    T100 Smart Soldering Station User Manual Smart Soldering Station 8. Firmware upgrade Step 1: Scan the QR code below to download the latest firmware (T100_APP. atk). Download Step 2: Press the knob, then insert the Type-C data cable, and connect to the computer. After the screen displays the firmware upgrade, release the knob.
  • Page 13 T100 Smart Soldering Station User Manual Smart Soldering Station Step 4: Open the firmware upgrade software, select the serial port number, open the serial port, select the network upgrade, and finally click start upgrade and wait for the upgrade to complete.

  • Page 14: Maintenance

    T100 Smart Soldering Station User Manual Smart Soldering Station 9. Maintenance When the new tip is used for the first time, it is necessary to heat the tin to 250 ° C first to prevent dry burning oxidation! When the new tip is used for the first time, there will be a temperature jump problem, which will stabilize after a few hours of use! ...

  • Page 15: Serivices

    12. Serivices 1. After – sales Service： T100 host has a one-year free warranty service in the case of non- artificial damage. Please contact the dealer for warranty service. Soldering tips are consumables, if there is no quality problem, once used they will not be returned.
