- Page 1 ALIENTEK T100 Smart Soldering station User Manual T100 Smart Soldering station Ver:1.0 @2019.06.27...
-
Page 2: Table Of Contents
ALIENTEK T100 Smart Soldering station User Manual Contents 1. Foreword ........................ 1 2. Specifications ......................1 3. Packing list ......................1 4. Parts description ....................2 4.1 Front panel .......................... 2 4.2 Back panel ........................... 2 4.3 Install iron tip and connect handle ..................3 5. -
Page 3: Foreword
Thank you for purchasing this product. We recommend that you spend some time reading this user manual in order that you fully understand all the operational features it offers. 1. Foreword T100 is a smart multi-function soldering station. It has the following characteristics: Small size and light weight, portable. -
Page 4: Parts Description
ALIENTEK T100 Smart Soldering station User Manual 4. Parts description 4.1 Front panel Fig 4.1 front panel Set temp: range is 100~500℃. Using time: In units of minutes, cleared after sleep. Heating indication: display when heating, flashing at constant temperature, not displayed when cooling. -
Page 5: Install Iron Tip And Connect Handle
ALIENTEK T100 Smart Soldering station User Manual 4.3 Install iron tip and connect handle Fig 4.3 install iron tip Fig 4.4 connect handle... -
Page 6: Display Description
ALIENTEK T100 Smart Soldering station User Manual 5. Display description Fig 5.1 system flow After the power switch is turned on, the soldering station starts to display the boot UI. If there is no access handle, prompt “No Tip”, otherwise enter main UI and the soldering station works normally. - Page 7 ALIENTEK T100 Smart Soldering station User Manual to 50 ° C, it enters the ready-to-shutdown state, and then counts down for 10 seconds. After the timer is over, the screen goes out and the system enters the off state. Off state：Not heated. The screen is off (Note: The power here is not disconnected!). In this state, the screen goes out and the system is running at very low power consumption.
-
Page 8: Setting Menu Description
ALIENTEK T100 Smart Soldering station User Manual 6. Setting menu description Note: Double-click the encoder on the main UI or warning UI to enter the menu UI, rotating the encoder to select the menu option, click to enter next menu, long press to exit. -
Page 9: Mode Set
ALIENTEK T100 Smart Soldering station User Manual 6.2 Mode set Fig 6.3 mode set Step set: In the temp adjust UI, rotating the encoder to adjust the set temp to step by this value. Boost set: Used in boost mode, including boost temp and boost time (boost countdown). -
Page 10: Tip Select
ALIENTEK T100 Smart Soldering station User Manual 6.4 Tip select Fig 6.5 tip select The system can save 6 tip calibration parameters, the user can select, calibrate and save any one. (Note: the factory default selection of the tip 1 is suitable for the tip of this soldering station) 6.5 Tip calibration... -
Page 11: Beep Set
ALIENTEK T100 Smart Soldering station User Manual Note: The soldering station has calibrated. The default is the soldering iron tip 1. If there is no professional soldering iron temperature measuring instrument, it is not recommended to recalibrate! 6.6 Beep set Fig 6.7 beep set... -
Page 12: Language
ALIENTEK T100 Smart Soldering station User Manual voltage is low as shown in Figure 5.1. The default is 19.8V, which is 6S lithium battery pack × 3.3V. Usually, the lithium battery is basically less than 3.3V. This parameter can be adjusted (10~26V), and user can adjust the value according to battery. -
Page 13: Firmware Upgrade
ALIENTEK T100 Smart Soldering station User Manual 7. Firmware upgrade Disconnect the power supply, disconnect the handle and the host, use cable to connect the USB to TTL serial port module and the host according to the following Figure 7.1 connection. - Page 14 ALIENTEK T100 Smart Soldering station User Manual Fig 7.3 upgrade software operation The upgrade is successful and the screen is shown in Figure 7.4 below. The system will automatically restart after the upgrade is complete. Fig 7.4 upgrade success...
-
Page 15: Maintenance
ALIENTEK T100 Smart Soldering station User Manual 8. Maintenance note: When the new tip is used for the first time, it is necessary to heat the tin to 250 ° C first to prevent dry burning oxidation! When the new tip is used for the first time, there will be a temperature jump problem, which will stabilize after a few hours of use! ... -
Page 16: Warranty Items
ALIENTEK T100 Smart Soldering station User Manual 10. Warranty items The term of service Guangzhou Xingyi Electronic and Technology Co., Ltd promise good quality products. If the product is defective unit by normal use within 7 days after purchasing, the customer can choose to return or repair warranty (doesn’t affect the secondary sales after they can...
