- Page 1 Alienware Tri Mode Wireless Gaming Headset AW725H User’s Guide Regulatory Model: AW725H/UD2202u Oct. 2024 Rev. A00...
- Page 2 Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
- Page 3 Alienware Command Center (AWCC) ........
- Page 4 Safety instructions Keep the volume at optimal levels while in use. Do not listen at high volume levels for a long period. Prolonged exposure to high volume levels may cause high sound pressure and may run the risk of hearing damage. Safety instructions...
- Page 5 NOTE: The documents that are shipped with your headset may vary depending on the region. Table 1. The following table shows the headset components and description. Component image Component description Alienware Tri Mode Wireless Gaming Headset AW725H USB-A to USB-C charging cable USB-C wireless dongle 3.5 mm inline audio cable...
- Page 6 Headset features Headset Figure 1. Headset features and controls Table 2. The following table shows the headset controls and description. Label Description LED indicator Power/BT button Volume control wheel Retractable microphone USB–C charging port Inline audio cable port Game/Chat balance button Microphone mute button Headset features...
- Page 7 Accessories Figure 2. 3.5 mm inline audio cable features and controls Table 3. The following table shows the accessories controls and description. Label Description Microphone mute slider Microphone Headset specifications Table 4. The following table provides the headset specifications. Specifications Value Weight 348 g...
- Page 8 Charging the headset NOTE: The European Union (EU) has a mandate for a common charger requirement that applies to wireless products with embedded rechargeable battery. For more information about the EU charging power requirements, see Charging power requirement. To charge the headset, connect on one end of the USB-A to USB-C cable to the USB-C port on your headset. Connect the USB-A end of the cable to the USB port to your computer.
- Page 9 Battery life Complete charging from flat to full may take less than 2.5 hours. Charging indication can be found on both the power and Alien head LEDs. Figure 4. Location of the power LED Table 5. The following tables provides the battery status and LED behavior. Battery status LED behavior Fully charged...
- Page 10 Turning your headset on or off Press and hold the power button on the right-ear cup for one second to turn the headset on or off. Figure 5. Position of power button Auto power off When the USB-C wireless dongle connection is lost (either the computer is turned off or the USB-C wireless dongle is removed from the USB port), the headset automatically turns off after 30 minutes.
- Page 11 Connecting the headset to your device System requirements One USB port for USB-C wireless dongle • One USB port for charging (optional) • Microsoft Windows 10 or Microsoft Windows 11, 64-bit • PlayStation®/Xbox/Mobile devices with 3.5 mm audio port • Connecting the headset to your device using Bluetooth Turn on the Bluetooth connection on your device before connecting the headset using Bluetooth.
- Page 12 Connect the headset to a computer, laptop, smartphone, or tablet and so on. You will hear “Bluetooth connected”, then the LED will light up in blue for 3 seconds and slowly blinks in blue. Figure 8. Indication when headset is successfully connected Connecting the headset to your device...
- Page 13 Connecting the headset to your device using the USB-C wireless dongle 1. Insert the USB-C wireless dongle directly into the USB-C port on your computer or insert the USB-C wireless dogle into the USB-A to USB-C adapter, then connect the adapter into the USB port on your computer. Figure 9.
- Page 14 Connecting the headset to your device using the inline audio cable Connect the microphone end of the 3.5 mm inline audio cable to the port on your headset. Connect the other end of the audio cable to the headphone/headset port on your computer or mobile device. 2.
- Page 15 Switch connection mode between Bluetooth and USB-C wireless dongle Double-click the power button to switch the connection mode between Bluetooth and USB-C wireless dongle. Figure 12. Switching connection mode Connecting the headset to your device...
- Page 16 Figure 13. Position of the speaker icon 2. Click the Playback tab: Set following device name as the default playback device. • When using the USB-C wireless dongle, select AW725H Game • Set following device name as the default communication device. •...
- Page 17 • Set following device name as the default communication device. • When using USB-C wireless dongle, select AW725H Chat. Figure 15. Image of Recording setting page 4. Click the Communications tab, select Do nothing. Click OK. Figure 16. Image of Communications setting page...
- Page 18 Site. Installing AWCC To use the AWCC features, uninstall Alienware Headset Center (AWHC) if you have already installed AWHC on your computer. You need to install AWCC to configure the features available in Alienware Wireless Gaming Headset AW725H. Before installing AWCC on your computer, ensure that your computer is connected to the Internet. If your computer is preinstalled with AWCC 6.4 or later, you can configure your Alienware gaming headset through FX available in AWCC.
- Page 19 Activating Dolby Atmos for headphones The headset automatically activates Dolby Atmos when connected to Microsoft Windows 10 or Microsoft Windows 11 computer by following the steps below: Go to the Microsoft Store. 2. Download the Dolby Access app. Connect the headset to the computer. 4.
- Page 20 AW725H. 2. From the Drivers & Downloads tab, download AW725H Headset FW update tool. Connect your headset to your computer through the USB cable, and plug in the wireless audio receiver to the USB port of your computer.
- Page 21 Using the headset Adjusting the headset Adjust the headband to find your optimal fit. The elastic band can be shifted up and down for the best fit. It is also detachable. Figure 17. Adjustable elastic headband When using the boom microphone, position it approximately two centimeters away from your mouth. Figure 18.
- Page 22 Using features on the headset Adjusting the volume Scroll the volume control wheel to increase or decrease the volume. Scroll up for volume up, scroll down for volume down. Adjusting Game/Chat balance control The volume balance of game and chat is 100% for each mode when using the headset for the first time. Push up the game chat balance button to increase game volume or decrease chat volume.
- Page 23 Muting or unmuting the microphone When the microphone is retracted fully into the headset, the microphone will be muted and the microphone mute button is disabled. When the microphone is extended, user can mute or unmute by pressing the microphone mute button. The microphone mute LED lights up red, and the microphone is muted.
- Page 24 Replacing the ear pads To remove ear pads, hold the ear pad firmly, twist toward the back of the headset and pull straight out. Note that the left and right ear pads are different. Match the arrow marks on the ear pad and the ear cup to replace the ear pad. Figure 22.
- Page 25 Regulatory label position The regulatory labels are on the left ear cup. Remove the ear pad to locate their positions. Left ear cup Figure 23. Regulatory labels on left ear cup Right ear cup Figure 24. Right ear cup Using features on the headset...
- Page 26 Ensure that the device/media player is not muted. Check the playback setting on the computer, and ensure • that the default device is set to AW725H Game. Check the headset is within range (10 m) of the USB-C • wireless dongle We recommend using the headset in dongle mode when •...
- Page 27 Ensure that the red portion of the microphone mute button • is covered. Alienware command center does not recognize the headset • Ensure that the headset is powered on and connected to the computer via the USB-C wireless dongle.
- Page 28 Charging power requirement: NOTE: The information in this section is only applicable to the computers shipped to the European Union (EU) countries. Charging power requirement: The power delivered by the charger must be between minimum 2.5 W required by the radio equipment, and maximum 7.5 W in order to achieve the maximum charging speed.
- Page 29 Töltési teljesítményigény: A maximális töltési sebesség eléréséhez a töltő által leadott teljesítménynek a rádióberendezés által megkövetelt minimális 2.5 W és a maximális 7.5 W között kell lennie. Requisiti di alimentazione per la ricarica: L’alimentazione fornita dal caricabatterie deve essere compresa tra i 2.5 W minimi richiesti dall’apparecchiatura radio e i 7.5 W massimi, al fine di raggiungere la velocità...
- Page 30 Warranty information Limited warranty and return policies The Alienware Tri Mode Wireless Gaming Headset AW725H carries a 2-years limited hardware warranty. If purchased together with a Dell computer, it will follow the system warranty. For U.S. customers: This purchase and your use of this product are subject to Dell’s end user agreement, which you can find at the Dell Support Site.
