- Page 1 FIREBALL-D1.600 MONOBLOCK POWER AMPLIFIER USER MANUAL PLEASE READ CAREFULLY BEFORE USING...
- Page 2 INTRODUCTION Congratulations and thank you for purchasing the AurA FIREBALL Series amplifier, a logical choice for beginner to intermediate projects. Your amplifier was designed and engineered using quality components to help you achieve superior sound quality. To achieve optimal amplifier performance, please take a few minutes to read this owner's manual or, if necessary, contact an authorized dealer before beginning installation.
- Page 3 Connect the positive power cable to the “+12V” terminal of the “POWER INPUT” block. All AurA FIREBALL amplifiers must use external fuses as rated in the diagram above. Connect one terminal of the fuse holder to the power cable going to the amplifier and the other terminal to the positive terminal of the battery.
- Page 4 RCA-CABLE CONNECTION Remote control Power REMOTE LINE INPUT SUBSONIC BASS BOOST GAIN 0 ° 180 ° 0.2v 10Hz 50Hz 0dB 12dB 50Hz 250Hz SPEAKER CONNECTION POWER FUSE PROT +12V SPEAKER OUTPUT POWER INPUT Speakers with 1+1 Ohm coils: 1-4 Ohm Speakers with 2+2 Ohm coils: Speakers with 4+4 Ohm coils:...
- Page 5 TROUBLESHOOTING ◆ AurA FIREBALL series amplifiers have safety features to prevent any damage from improper connection or use. ◆ In case of overheating, short circuit of speaker wires or exceeding operating voltage, the protection indicator will light up and the system will be turned off immediately.
- Page 6 WARRANTY CARD Model name Serial No. Buyer name Buyer address Phone No. Sales date Signature Seller name/stamp...
- Page 7 TERMS OF WARRANTY SERVICE The manufacturer guarantees high quality and reliability of products subject to compliance technical requirements described in the operating instructions. This guarantee is issued for a period of one year from the date of purchase and is provided in the event that the product is found to be defective due to inadequate quality of materials or...
- Page 8 Due to continuous development and improvement of the product, all technical specifications, as well as appearance, are subject to change without prior notice. © AURA Electronics Inc. All rights reserved.
