Product Service Manual – Level 3
Service Manual for BenQ:
FP222W
P/N: 9J.03V72.xxx
Applicable for All Regions
Version: 001
Date:27/09/06
Notice:
- For RO to input specific "Legal Requirement" in specific NS regarding to responsibility and liability
statements.
- Please check BenQ's eSupport web site, http://esupport.benq.com, to ensure that you have the most
recent version of this manual.
First Edition (June, 2006)
© Copyright BenQ Corporation 2006. All Right Reserved.
- 1 -

Advertisement

loading
Need help?

Need help?

Do you have a question about the FP222W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BenQ FP222W

Summary of Contents for BenQ FP222W

  • Page 1 - For RO to input specific “Legal Requirement” in specific NS regarding to responsibility and liability statements. - Please check BenQ’s eSupport web site, http://esupport.benq.com, to ensure that you have the most recent version of this manual. First Edition (June, 2006) ©...
  • Page 2 Content Index Abbreviations & Acronyms………………………………………………………...…..3 1. About This Manual…………………………………………………………………..4 1.1. Trademark… …………………………………………………………………...4 2. Introduction…………………………………………………………………………...5 2.1. RoHS (2002/95/EC) Requirements……………………………………………..5 2.2. Safety Notice……………………………………………………………………5 2.3. General Descriptions……………………………………………………………5 2.4. Related Service Information…………………………………………………..5 3. Product Overview……………………………………………………………………..6 3.1. Specification……………………………………………………………………..6 3.2 Customer Acceptance…………………………………………………………..19 4. Disassembly / Assembly…………………………………………………………….26 4.1 Exploded View………………………………………………...………………..26 4.2 Disassembly / Assembly Flow………………………………………………….26 5.
  • Page 3 Abbreviations & Acronyms - 3 -...
  • Page 4 About This Manual This manual contains information about maintenance and service of BenQ products. Use this manual to perform diagnostics tests, troubleshoot problems, and align the BenQ product. 1.1. T r a d e m a r k The following terms are trademarks of BenQ Corporation:...
  • Page 5 Level 1: Cosmetic / Appearance / Alignment Service Level 2: Circuit Board or Standard Parts Replacement Level 3: Component Repair to Circuit Boards 2.4. Related Service Information BenQ Global Service Website: http://support.benq.com/front/benqmain.asp eSupport Website: http://bqpgsr.benq.corp.com/customize/asplogin.asp 3. Product Overview - 5 -...
  • Page 6 3.1. Specification 3.1.1. Specification FP222G W is defined as an entry-level 22 inch wide monitor targeting on both commercial and consumer users that need an affordable 22” wide monitor. FP222G W has family look with FP202W and FP92W and the ID design is neat and clean and is welcomed by majority of users. The monitor supports maximum resolution up to 1680x1080 with analog, digital inputs.
  • Page 7 Mechanical Lift base design Kensington compatible lock design 3.1.2. Operational Specification 3 .1.2.1 P o w e r s u p p l y Item Condition Spec OK N.A Remark √ Input Voltage range Universal input full range 90~264VAC /47~63Hz √...
  • Page 8 Signal Assignment Signal Assignment Red video PC5V (+5 volt power) Green video Sync Ground Blue video Ground Ground Cable Detected H-Sync (or H+V) Red Ground V-sync Green Ground Blue Ground Note-2: The pin assignment of 24-pin DVI-D connector is as below, Signal Assignment Signal Assignment TMDS RX2-...
  • Page 9 √ Settling Time after Refer to VESA VSIS < 5% final full-scale value overshoot /undershoot Standard V1R1 < 12% of step function √ Refer to VESA VSIS Overshoot/Undershoot voltage level over the full Standard V1R1 voltage range 3 .1.2.4 S c a n r a n g e Item Condition Spec...
  • Page 10 √ 1024x768 48.36(N) 60.00(N) 65.00 1280x1024 VESA √ 1024x768 56.48(N) 70.10(N) 75.00 1280x1024 VESA √ 1024x768 60.02(P) 75.00(P) 78.75 1280x1024 VESA √ 1024X768 60.24(N) 74.93(N) 80.00 1280x1024 Macintosh √ 1152x864 67.50(P) 75.00(P) 108.00 1280x1024 VESA √ 1152x870 68.68(N) 75.06(N) 100.00 1280x1024 Macintosh √...
  • Page 11 At default contrast level Max. brightness value – √ (saturate point) & Full-white Brightness adjustable range Min. brightness value) color pattern 100 cd/ 3 .1.3 .3 A c o u s t i c a l N o i s e Item Condition Spec...
  • Page 12 (3) Procedure: Confirmed sample with appearance and function ready before testing then compare with after test record as brightness, uniformity and contrast ratio. Perform random vibration after sine- wave vibration test. Test Spectrum: 20 Hz 0.0185(g2/Hz) √ 200Hz 0.0185(g2/Hz) (2) Unpackaged Vibration Unpackaged, Non-Operating Duration : 5 Minutes Axis : 3 axis ( Horizontal...
  • Page 13 3 .1.3 .9 A u d i o p e r f o r m a n c e Item Condition Spec OK N.A Remark Preamp + Power amp √ (1)Output power 1 Wrms/CH @ 1KHz √ (2)THD (@ 1W) <1% √...
  • Page 14 [msec] Rising + Falling Red x 0.641 0.644 0.664 Red y 0.330 0.333 0.336 Color / Chromaticity Green x 0.284 0.287 0.290 Green y 0.598 0.601 0.604 Coordinates (CIE) Blue x 0.150 0.153 0.156 Blue y 0.074 0.077 0.080 White x 0.310 0.313 0.316...
  • Page 15 √ OSD Time From 5 sec to 30 sec √ OSD Lock √ 8/14 languages for Language Asia/Europe Version √ Recall Recall All √ √ Standard / Movie / Dynamic / Mode Photo √ D-sub Input Select √ Sharpness √ Display Information For input timing √...
  • Page 16 √ Heat deflection To √ UV stability Delta E < 8.0 √ MPRII: ABS Resin (SD0150/GP35/D350/PA757) √ RC partial texture Texture MT-11010 MT-11020 √ Color BCS-Y7015A 3 .1.6 .4 C a r t o n Item Condition Spec OK N. Remark √...
  • Page 17 Carton Interior Dimension (mm) Carton External Dimension (mm) L*W*H L*W*H 578*493*148 590*505*170 3.1.8. Certification Item Condition Spec OK N.A Remark √ ISO14000 BenQ Doc. 715-C49 Green design Requirement √ Blue Angel German Standard √ E-2000 Switzerland √ Environment USA Standard √...
  • Page 18 3.2.1. SCOPE This document establishes the general workmanship standards and functional Acceptance criteria for LCD color monitor model Q22W6 Produced by BenQ Corporation. 3.2.2. PURPOSE The purpose of this publication is to define a procedure for inspection of the LCD monitor by...
  • Page 19 acceptance levels. 3.2.3. APPLICATION The "Customer Acceptance Criteria" is applicable to the inspection of the LCD monitor, completely packed and ready for dispatch to customers. Unless otherwise specified, the customer acceptance inspection should be conducted at manufacturer's site. 3.2.4. DEFINITION The "Customer Acceptance Criteria"...
  • Page 20 TEST EQUIPMENTS 1. PC with display adapter or other specific display adapter which is agreed upon by both parties 2. Test program by BenQ 3. Ruler 4. Power saving test tool 5. Minolta color analyzer ( CA-110 or BM – 7 ) 3.2.12.
  • Page 21 Wrong packing material Major Carton damaged(over 6cm dia).wet, badly taped or stapled, product will not arrive in good condition Minor at customer Carton damaged(3cm to 6cm dia), badly taped or stapled , product will arrive in good condition at Minor customer Wrong marking of trade mark Major...
  • Page 22 AC power and signal cable AC power or connector not correct or damaged, not safe Critical AC power or connector not correct or damaged, but safe Major Signal cable contact pin dirty Minor Signal cable plug dirty or surface damaged, but safe Minor Cable crack Major...
  • Page 23 256 COLORS Color Check 16 GREY Gray Check Black/White stripe pattern Electric characteristics 3 .2.13 .2. V i d e o p e r f o r m a n c e Item Condition Spec OK N.A Remark √ Max. support Pixel rate 165 MHz √...
  • Page 24 √ VESA 640x480 37.86(N) 72.80(N) 31.5 1280x1024 √ VESA 640x480 37.50(N) 75.00(N) 31.5 1280x1024 √ VESA 800x600 37.88(P) 60.32(P) 40.00 1280x1024 √ VESA 800x600 48.08(P) 72.19(P) 50.00 1280x1024 √ VESA 800x600 46.86(P) 75.00(P) 49.50 1280x1024 √ Macintosh 832X624 49.72(N) 74.55(N) 57.29 1280x1024 √...
  • Page 25 Distance between B and D dot :>=10mm 4. Disassembly /Assembly 4.1. Exploded View - 25 -...
  • Page 26 4.2. Disassembly /Assembly Preparation before disassembly: 1. Ensure the room is clean for disassembly; 2. Check and ensure the location of the monitor to be placed; 3. Prepare the equipments/tools as below: ♦ work table ♦ screwdriver ♦ antistatic mat ♦...
  • Page 27 - 27 -...
  • Page 28 - 28 -...
  • Page 29 5. Level 1 Cosmetic / Appearance / Alignment Service 5.1 Software / Firmware Upgrade Process 5.1.1. Hardware prepared: Print Board (or not); Print Cord I2C Board b. I2CBoard. And I2C Board Jump wire should follow J10 (short), J9 (open), J8/J7/J6/J5 (3 and 2 pin short) Connected to print Connected to Display cord and PC...
  • Page 30 If you have no print cord, you can insert I2C BD into print port on PC directly. Connect to Monitor PC Print port 5.1.2. Software Prepare: Please set up attached Genesis ISP software. Operation sequence as following: a. Open the execute file and enter into software operation surface. - 30 -...
  • Page 31 b. click “ ” , select “Parallel”. - 31 -...
  • Page 32 c. Modify “Speed” to 140000 Hz in Parallel item Click “ ”, device finish. - 32 -...
  • Page 33 d. Follow the follow steps in turn     O L QN O L QN O L QN O L QN ,  & % ' ,  & % ' ,  & % ' ,  & % ' S R Z H U F D E O H S R Z H U F D E O H S R Z H U F D E O H S R Z H U F D E O H V L J QD O F D E O H...
  • Page 34 3 3 3 3 O H D V H H QW H U O H D V H H QW H U I R U F H I R U F H I R U F H I R U F H V DV DV DV D     O H D V H H QW H U O H D V H H QW H U...
  • Page 35 - 35 -...
  • Page 36     H QW H U H QW H U H QW H U H QW H U L QW R I L O H S D W K L QW R I L O H S D W K E D W F K F  E D W F K F  E D W F K F  E D W F K F  ? ? ? ? , 6 3 , 6 3 , 6 3 , 6 3? ? ? ? V S L B V S L B V S L B V S L B I O D V K B I O D V K B I O D V K B I O D V K B L V S B L V S B L V S B L V S B QY U D P B QY U D P B QY U D P B QY U D P B    B Y   W [ W    B Y   W [ W  D QG U  D QG U  D QG U  D QG U X Q S U R J U D P ...
  • Page 37 5.2. Alignment procedure (for function adjustment) 5.2.1. Preparation: Setup input timing ICL-605( 1280x1024@75Hz ), 32-Grays pattern. Setup unit and keep it warm at least 30 minutes. 5.2.2. Timing adjustment: 1. Enter factory setting area (press “ENTER”, “MENU” and then press “SOFTPOWER”). 2.
  • Page 38 5.2.4. Color adjustment: 1. Set input timing ICL-605, white pattern. 2. Confirm and make sure auto color adjustment had been done. 3. Measure color temperature by Minolta CA-110 (or equivalent equipment). 4. Check the color temperature Bluish, Reddish & Normal. The color temperature specification as follows: White Balance 0.283+(-) 0.03 (Bluish, 9300K set on OSD)
  • Page 39 640×480 @ 75Hz 37.500 75.000 800×600 @ 60Hz 37.879 60.317 800×600 @ 75Hz 46.875 75.000 1024×768 @ 60Hz 48.363 60.004 1024×768 @ 75Hz 60.023 75.029 1152x864 @ 75Hz 67.500 75.000 1280×1024 @ 60Hz 63.981 60.020 1280×1024 @ 75Hz 79.976 75.025 6.
  • Page 40 √ Write Contrast to EEPROM Data cksum √ Write Brightness to EEPROM Data cksum 1=C1/9300/Bluish, 2=C2/6500/sRGB/, 3=C3/5800/Reddish, √ Write C/T index to EEPROM 1~4 cksum 4=User, 5=Cx √ Write OSD-Hpos to EEPROM Data cksum √ Write OSD-Vpos to EEPROM Data cksum 0=DE, 1=EN, 2=ES, 3=FR, 4=IT, 5=JA, 6= , 7=...
  • Page 41 0= D E , 1 = E N , 2 = E S , 3= F R , 4 = I T , 5 = J A , 6 = , 7 = European version: 1=English, 3=French, 0=Deutsch, 4=Italian, 2=Spanish, 8=Hungarian, 9=Serbian, 0A=Russian, 0B=Dutch, 0C=Polish, 0D=Czech, 0E=Swedish,...
  • Page 42 XX cksum √ Read ADC R-Gain XX cksum √ Read ADC G-Gain XX cksum √ Read ADC B-Gain √ User mode to factory mode XX cksum √ Auto Color (Offset1, Offset2, Gain) XX cksum F o r s p e c i f i e d “I n d u s t r y √...
  • Page 43 6. Level 2 Circuit Board and Standard Parts Replacement 6.1. Block diagram The FP222GW consists of a LCD module with 4 lamps, a power board including an inverter, a control board, and a LED board. The block diagram is shown as below. Interface board diagram: NO USE - 43 -...
  • Page 44 Power board diagram: Inverter circuit Rectifier and Isolation power EMI Filter Rectifier and filter filter transformer Switching element Rectifier and filter LDO regulator PWM controller Feedback Isolation Inverter diagram: CCFL ON/OFF OSCILATOR TRANSFORMER 15Vin switching CIRCUIT PWM CONTROLLER ON/OFF TL1451 CIRCUIT PROTECTION AND DETECT BRT_ADJ...
  • Page 45 6.2. TROUBLE SHOOTING GUIDE 6.2.1. No Display or display is unstable: I n t e r f a c e B o a r d : - 45 -...
  • Page 46 6.2.2. BUTTON function: Control Board 6.2.3. OSD function: - 46 -...
  • Page 47 6.2.4. No power troubleshooting - 47 -...
  • Page 48 7. Level 3 Component Repair to Circuit Boards 7.1. Circuit Operation Theory Introduction: This specification describes FP222GW, which is a 22” WSXGA+(1680×1050 @60Hz) , 16.7M colors(8bit R,G,B data) and dual interface(D-SUB and DVI). FP222GW has family look with FP202W and FP92W and the ID design is neat and clean and is welcomed by majority of users.
  • Page 49 #1 EMI Filter This circuit (fig. 2) is designed to inhibit electrical and magnetic interference for meeting FCC, VDE, VCCI standard requirements. Fig. 2 #2 Rectifier and filter AC Voltage (90-264V) is rectified and filtered by BD601, C605 (See Fig 3) and the DC Output voltage is 1.4*(AC input).
  • Page 50 Fig. 4 #4 Rectifier and filter D701 and C703 are to produce DC output. L701 is used to suppress high Frequency switching spikes. (See Fig.5) Fig. 5 #5 PWM Controller The PWM controller NCP1200A implements a standard current mode architecture. With an internal structure operating at a fixed 40KHz, the switch time is dictated by the peak current set-point.
  • Page 51 Fig. 6 #6 Feedback circuit PC123 is a photo-coupler and TL431 is a shunt regulation. They are used to detect the output voltage change and be the primary and secondary isolation. When output voltage changes, the feedback voltage will be compared and duty cycle will be decided to control the correct output voltage.
  • Page 52 The main parts of the control board are a push button, and a LED. (a) Push button: It’s a simple switch function, pressing it for “ON” to do the auto adjustment function, releasing it for “OFF” to do nothing. (c) LED: It indicates the DPMS status of this LCD monitor; green light means DPMS on (Normal operating condition).
  • Page 53 TL1451 is a dual PWM controller.C807 and R811 decide the working frequency.BLT_ADJ signal is from control board, control pulse width then decide how much energy delivery to CCFL also decide CCFL brightness. Q810 and Q811 be the buffer to rise the drive capability and the totem poles circuit can improve a capable of driving for Q812.C813 decide the striking time delay.
  • Page 54 7.2. Circuit Schematics - 54 -...
  • Page 55 - 55 -...
  • Page 56 - 56 -...
  • Page 57 - 57 -...
  • Page 58 - 58 -...
  • Page 59 - 59 -...
  • Page 60 - 60 -...
  • Page 61 - 61 -...
  • Page 62 7.3. Spare Parts List BENQ LCD FP222W Spare Parts List P/N: 9J.03V72.MBA ITEM PART NUMBER DESCRIPTION LOCATION 5E.03V01.001 PCBA I/F BD CMO MI 7A.05766.00E IC LCD GM5766-LF-AB PQFP128P 5E.03V02.001 PCBA SPS BD CMO MI 5E.03V03.001 PCBA CTRL BD MI 5E.03V26.001 PCBA LED BD MI 5K.L9028.501...
  • Page 63 Appendix 1 – Screw List / Torque STANDARD SCREW TORQUE SPEC. NP V O UJO H ! UP S R V F! I P MF!TJ[ F! Td s f x ! JUFN! Q 0 O ! E FTDS JQ UJP O ! NBUFS JBM! ) L H .DN* ! ) NN* !
  • Page 64 SPECIAL SCREW TORQUE SPEC. NP V O UJO H ! UP S R V F! I P MF!TJ[ F! Td s f x ! JUFN! Q 0 O ! E FTDS JQ UJP O ! NBUFS JBM! ) L H .DN* ! ) NN* ! I f b e ! 9G / 11385/ 9S 1! TDS FX!G Q I !UBQ !N4+ 9M!O J!
  • Page 65 Appendix 2 Physical Dimension Front View and Side view Physical Dimension Front View and Side view - 65 -...
