Summary of Contents for DTE LUX I
- Page 2 Content 1. Introduction ..................1 2. Principle and usage ................1 3. Structure and components ..............1 4. Technical specifications ..............2 5. Install and uninstall way ..............3 6. Operation .................... 3 7. Precaution ..................5 8. Contraindication ................. 6 9.
- Page 3 2. Principle and usage 1.Principle and usage 1.1 LUX I adopts the principle of ray radiation to solidify the light- sensitive resin by shooting at it in a short time. 1.2 This product is used to restore teeth. 3. Structure and components...
- Page 4 4. Technical specifications 4.1 Dimensions: 79.5mm×79.5mm×261mm. 4.2 Net weight: 230g. 4.3 Power source 4.3.1 Power supply: rechargeable Lithium battery 4.3.2 Battery mode: ICR 18490 4.3.3 Battery voltage and capacity: 3.7/1400mAh Battery has protection against Over-voltage, over-current and short circuit. 4.3.4 Adapter Power Input: 100V to 240V, 50Hz/60 Hz Input Power: 10VA Power Output: DC5V/1A...
- Page 5 4.6.2 Relative humidity: 30%~75% 4.6.3 Atmosphere pressure: 70kPa to106kPa 4.7 Equipment safety 4.7.1 Operating mode: intermittent operation 4.7.2 Protection type against electrical shock: class Ⅱ . 4.7.3 Protection degree against electrical shock: type B. 4.7.4 Protection against harmful ingress of water or particular matter: ordinary equipment (IPX0).
- Page 6 6.1.1 Full power mode: screen shows 01, LED works in full power. 6.1.2 Ramping mode: screen shows 02, LED turns from weak to stronger, and reaches the highest power in 5 seconds. 6.1.3 Pulse mode: screen shows 03, LED works on the pulse condition. 6.2 Press the time button to choose the solidification time, 4 working time is available: 5, 10, 15, 20seconds.
- Page 7 the indicator turn to green, that means the pedestal is standby. Put the main unit to the charging point of the pedestal, the indicator turn to yellow, and the curing lights starts charging. When charging finished, the indicator turn to green. 6.8 After operating, take off the disposable sleeve and throw away, forbidden to reuse.
- Page 8 composite resin to ensure the effect of solidification. 7.5 Avoid aiming the blue light at eyes directly. 7.6 Please use the power adapter and lithium battery which is designed and supplied by our company. It may cause potential dangers to operator and patient by using the power adapter and lithium battery which is designed and supplied by other manufacturers.
- Page 9 9. Daily maintenance 9.1 This equipment does not include the self-maintainable spare parts. The maintenance of this equipment should be taken by the appointed professional or special repair shop. 9.2 Users can change the disposable sleeve and lithium battery. Please use accessory which is designed and supplied by our company, contract with the local dealer or our company if you want to buy.
- Page 10 11. Trouble shooting Faulty Possible cause Solutions N o i n d i c a t i o n , n o 1. Battery is out of 1. Charge the response. power. equipment/Change a 2. Faulty of battery. new batter. 3.
- Page 11 Faulty Possible cause Solutions The equipment is not 1. The adapter is not 1. Reconnect. charging when the connected well. 2. Change the adapter. adapter is connected. 2. Faulty of adapter or 3. Cleaned by the incompatible. alcohol. 3. The charging point is impurity.
- Page 12 13. Storage and transportation 13.1 This equipment should be handled carefully, kept away from shaking point, installed or stored at shadowy, dry, cool and ventilated places. 13.2 Don't store it together with articles that are combustible, poisonous, caustic and explosive. 13.3 This equipment should be stored in a room where the relative humidity is 10%~93%, atmospheric pressure is 70kPa to106kPa, and the temperature is -20 ℃...
- Page 13 Date of manufacture Manufacturer Recovery Used indoor only Keep dry Handle with care Temperature limitation for storage Humidity limitation for storage Atmospheric pressure for storage Appliance compliance WEEE directive Follow Instructions for Use 16. Statement All rights of modifying the product are reserved to the manufacturer without further notice.
- Page 14 ZMN-SM-148 V2.2 - 20200318...
