This chapter explains how to display the various configuration options and settings of the SAM DX server.
Displaying scanner information and settings
Refer to the table below for instructions on how to display scanner and system settings.
In many cases you cannot modify these settings, but Leica Biosystems Technical Support may ask you for the
information during troubleshooting or maintenance procedures. Some settings can only be seen by users with the Lab
Admin role.
To View:
MAC Address
Scanner Hostname
Scanner Friendly Name
Scanner Model
Scanner Language
Scanner Serial Number
Scanner Firmware Version
Scanner Hardware Version
Scanner Installation Date
DICOM Server Settings
DSR Server Settings
Event Handling (Mirth server)
Settings
Camera Configuration Settings
Scanner Additional Config
Settings
Focus Algorithm Config Settings
Motion Config XML File
Autoloader Config XML File
List of Users
List of PINs
Aperio GT 450 DX IT Manager and Lab Administrator Guide, MAN-0507 Revision A
Copyright © Leica Biosystems Imaging, Inc. 2024
Select the scanner from the main screen to display the Edit Scanner dialog box.
Select the scanner from the main screen to display the Edit Scanner dialog box, or
Click System Information for the scanner, and then click Info from the side menu.
Click System Information for the scanner, and then click Info from the side menu.
Click Configuration for the scanner, and then click Images from the side menu.
Click Configuration for the scanner, and then click DSR from the side menu.
Click Configuration for the scanner, and then click Event Handling from the side
menu.
Click System Information for the scanner, and then click Settings from the side
menu.
Click the Users icon in the top banner.
Click Configuration for the scanner, and then click PIN Management from the side
menu.
4 Viewing system information
