4
Solar panel configurations
Either one panel or two panels can be connected to the IQ PowerPack 1500,
as shown below.
One-panel configuration
200 W
Two-panel series configuration
200 W
200 W
DC Solar input port limits, applicable to either one-panel or two-panel configuration:
• Operating voltage: 12—50 V
• Maximum voltage: 60 V
IQ Portable Panel quick start guide
MC4
SOL AR CHARGING CABLE
MC4
SOL AR CHARGING CABLE
• Maximum current: 10 A
• Maximum power: 440 W
MC4 TO XT60
MC4 to XT60
XT60
XT60
5
