Access & Power Integration
Altronix/LiftMaster Kits
Models Include:
TLM400K1
4 Door Kit with Fused Outputs
Fully assembled kit includes:
- TM400 enclosure
- One (1) eFlow4NTB - Power Supply/Charger
- One (1) ACM4 - Fused Access Power Controller
- One (1) NetWay5P - PoE+ Hardened Switch
- One (1) LMBK2 - LiftMaster CAP2D Mounting Bracket
T2LMK7F8N
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TM2 backplane
- One (1) eFlow104NTB - Power Supply/Charger
- One (1) ACMS8 - Dual Input Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
- One (1) NetWay5P - PoE+ Hardened Switch
- Two (2) LMBK2 - LiftMaster CAP2D Mounting Brackets
T3LMK77F16N
16 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove3 enclosure with TM3 backplane
- Two (2) eFlow104NTB - Power Supply/Chargers
- Two (2) ACMS8 - Dual Input Fused Access Power Controllers
- Two (2) VR6 - Voltage Regulators
- Two (2) PDS8 - Dual Input Fused Power Distribution Modules
- Two (2) NetWay5P - PoE+ Hardened Switches
- Four (4) LMBK2 - LiftMaster CAP2D Mounting Brackets
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TLMK_080224
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
TLM400K1D
4 Door PTC with Fused Outputs
Fully assembled kit includes:
- TM400 enclosure
- One (1) eFlow4NTB - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
- One (1) NetWay5P - PoE+ Hardened Switch
- One (1) LMBK2 - LiftMaster CAP2D Mounting Bracket
T2LMK7F8ND
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TM2 backplane
- One (1) eFlow104NTB - Power Supply/Charger
- One (1) ACMS8CB - Dual Input PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
- One (1) NetWay5P - PoE+ Hardened Switch
- Two (2) LMBK2 - LiftMaster CAP2D Mounting Brackets
T3LMK77F16ND
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove3 enclosure with TM3 backplane
- Two (2) eFlow104NTB - Power Supply/Chargers
- Two (2) ACMS8CB - Dual Input PTC Access Power Controllers
- Two (2) VR6 - Voltage Regulators
- Two (2) PDS8CB - Dual Input PTC Power Distribution Modules
- Two (2) NetWay5P - PoE+ Hardened Switches
- Four (4) LMBK2 - LiftMaster CAP2D Mounting Brackets
More than just power.™
Advertisement
Related Manuals for Altronix TROVE TLM400K1
Summary of Contents for Altronix TROVE TLM400K1
- Page 1 Access & Power Integration Altronix/LiftMaster Kits Models Include: TLM400K1 TLM400K1D 4 Door Kit with Fused Outputs 4 Door PTC with Fused Outputs Fully assembled kit includes: Fully assembled kit includes: - TM400 enclosure - TM400 enclosure - One (1) eFlow4NTB - Power Supply/Charger...
- Page 2 Overview: Trove LiftMaster kits are pre-assembled and consists of Trove enclosures/backplanes with factory installed Altronix sub-assemblies. These kits also accommodate LiftMaster CAP2D for up to sixteen (16) doors in a single enclosure. Configuration Chart: Nominal DC Output Voltage Power Power...
- Page 3 2. Mount LiftMaster CAP2D onto LMBK2 Mounting Brackets. 3. Mount LMBK2 onto enclosure with metal spacers. TRIGGER INPUT IN GND IN GND IN GND IN GND Altronix ACM4(CB) LED1 LED2 LED3 LED4 NC C NO COM NC C NO COM NC C NO COM...
- Page 4 1. Remove factory installed LMBK2 Mounting Brackets. Do not discard metal spacers. 2. Mount LiftMaster CAP2D onto LMBK2 Mounting Brackets. 3. Mount LMBK2 onto backplane with metal spacers. 3. Mount backplane to enclosure with hardware. – Altronix NetWay5P is mounted on BR1 Altronix eFlow104NTB LiftMaster LiftMaster STATUS...
- Page 5 PWR1 + PWR2 + PWR2 + Altronix Altronix ACMS8(CB) NetWay5P is mounted on BR1 Altronix VR6 is mounted under ACMS8(CB) PWR1 + PWR1 + PWR2 + PWR2 + Altronix ACMS8(CB) Altronix VR6 is mounted under ACMS8(CB) PWR1 + IN1 Fuse...
- Page 6 TLM400K1 and TLM400K1D Enclosure Dimensions (H x W x D): 15.5” x 12” x 4.5” (393.7mm x 304.8mm x 114.3mm) 1.5” 1.5” 4.615” (117.2mm) 4.615” (117.2mm) (38.1mm) (38.1mm) 1.75” (44.5mm) 1.25” 1.25” 4.5” (114.3mm) 4.5” (114.3mm) 12.23” (310.6mm) (31.8mm) (31.8mm) 1.1”...
- Page 7 T2LMK7F8N and T2LMK7F8ND Enclosure Dimensions (H x W x D): 27.25” x 21.75” x 6.5” (692.15mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 5.25” (133.35mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77” 1.125”...
- Page 8 8.75” (222.3mm) 2” (50.8mm) Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
