- Page 1 McGrey BP-210 Bandpack ArtNr.: 00061292 User manual Version: 07.2020...
- Page 2 Instruction: ......................4 Description of the front view: ................5 Description of the rear view: ................. 8 Specifications ......................9 Maintenance ......................10 Cleaning ........................ 10 WEEE Declaration (Waste of Electrical and Electronic Equipment) ....10 2020-07-27 McGrey BP-210 / ArtNr.: 00061292...
- Page 3 Operating Manual. Other product, brand or company designations specified in this document are possibly the trademarks of their respective owners. Compliance with all applicable copyright laws is the responsibility of the user of this document. 2020-07-27 McGrey BP-210 / ArtNr.: 00061292...
- Page 4 This symbol indicates a non-isolated, hazardous voltage within the enclosure voltage sufficient to present a risk of electric shock. o This symbol indicates important operating and maintenance instructions in the manual. Please read the manual. McGrey BP-210 / ArtNr.: 00061292 2020-07-27...
- Page 5 2020-07-27 McGrey BP-210 / ArtNr.: 00061292...
- Page 6 Consult qualified service personnel for all maintenance work. Turn off the device and contact your merchant immediately if the device is damaged or malfunctioning. McGrey BP-210 / ArtNr.: 00061292 2020-07-27...
- Page 7 This controller adjusts the level sent to the built-in digital delay effect control (effect portion). 7. Cinch-Line Input: Channel 4 accepts RCA connectors for stereo line level devices. You can use either the microphone input or the channel 4 RCA inputs. 2020-07-27 McGrey BP-210 / ArtNr.: 00061292...
- Page 8 This is a stereo output (RCA) for connecting an external recording device. 14. CD/TAPE IN Volume Controller: This controller is used to adjust the volume of the devices which are connected to input 12. McGrey BP-210 / ArtNr.: 00061292 2020-07-27...
- Page 9 See the operating instructions for your device. 2. Press the “MODE” button and activate BT-function. 3. Find on your BT-device “BP-210” and make the connection. Attention: The BT distance is approx. 10 meter without any barrier. 2020-07-27 McGrey BP-210 / ArtNr.: 00061292...
- Page 10 Two speakers can be connected to these jacks. Connect the two passive speakers with these outputs. Use 16Ω speakers when 4 speakers are used at the same time. If only one speaker is used, use a 4-8Ω Speaker. McGrey BP-210 / ArtNr.: 00061292 2020-07-27...
- Page 11 <10% at 20Hz-20KHz for an output power of 55W to a 4 ohms speaker Power Consumption 150W Mixer Peak power: 2x100W RMS power: 2x50W Power consumption: 150W Speaker Peak power: 160W RMS power: 80W Power Requirement AC115V/230V, 50/60Hz 2020-07-27 McGrey BP-210 / ArtNr.: 00061292...
- Page 12 Please help to protect the environment in which we all live. SIMPLIFIED EU DECLARATION OF CONFORMITY Herewith Musikhaus Kirstein GmbH declares that the radio unit of Model [McGrey BP-210 Bandpack PA-Anlage mit Powermischer] is in compliance with the EU directive 2014/53/EU. You can download the full EU declaration of conformity for this item under download link: http://www.kirstein.de/docs/Konformitaetserklaerung/CE_Konformitaetserklaerung_0...
