Page 3
Operating Manual. Other product, brand or company designations specified in this document are possibly the trademarks of their respective owners. Compliance with all applicable copyright laws is the responsibility of the user of this document. 2020-07-27 McGrey BP-215 / ArtNr.: 00061293...
This symbol indicates a non-isolated, hazardous voltage within the enclosure voltage sufficient to present a risk of electric shock. o This symbol indicates important operating and maintenance instructions in the manual. Please read the manual. McGrey BP-215 / ArtNr.: 00061293 2020-07-27...
Consult qualified service personnel for all maintenance work. Turn off the device and contact your merchant immediately if the device is damaged or malfunctioning. McGrey BP-215 / ArtNr.: 00061293 2020-07-27...
This controller adjusts the level sent to the built-in digital delay effect control (effect portion). 7. Cinch-Line Input: Channel 5 and 6 accept RCA connectors for stereo line level devices. You can use either the microphone input or the channel 5 and 6 RCA inputs. 2020-07-27 McGrey BP-215 / ArtNr.: 00061293...
Page 8
This is a stereo output (RCA) for connecting an external recording device. 14. CD/TAPE IN Volume Controller: This controller is used to adjust the volume of the devices which are connected to input 12. McGrey BP-215 / ArtNr.: 00061293 2020-07-27...
Page 9
1. Set the search function on of the BT device (Handy, Laptop, etc.) you want to play the music. See the operating instructions for your device. 2. Press the “MODE” button and activate BT-function. 3. Find on your BT-device “BP-215” and make the connection. Attention: The BT distance is approx. 10 meter without any barrier. 2020-07-27...
Two speakers can be connected to these jacks. Connect the two passive speakers with these outputs. Use 8~16Ω speakers when 4 speakers are used at the same time. If only one speaker is used, use a 4-8Ω Speaker. McGrey BP-215 / ArtNr.: 00061293 2020-07-27...
<10% at 20Hz-20KHz for an output power of 55W to a 4 ohms speaker Maximum Power Output 120W @ 4 Ohm Mixer Peak power: 2x150W RMS power: 2x75W Power consumption:220W Speaker Peak power:200W RMS power:100W Power Consumption 150W Power Requirement AC115V/230V, 50/60Hz 2020-07-27 McGrey BP-215 / ArtNr.: 00061293...
Please help to protect the environment in which we all live. SIMPLIFIED EU DECLARATION OF CONFORMITY Herewith Musikhaus Kirstein GmbH declares that the radio unit of Model [McGrey BP 215 Bandpack PA-Anlage mit Powermischer] is in compliance with the EU directive 2014/53/EU.
