- Page 1 ICESPA 7 POMPE À CHALEUR POUR SPA Manuel d’installation et d’utilisation Installation and user manual Manual de usuario y instalación Manuale d’installazione e d’uso Installations und Gebrauchsanleitung Installatieen en gebruikershandleiding poolex.fr...
- Page 2 Cher client, Nous vous remercions pour votre achat et pour la confiance que vous accordez à nos produits. Nos produits sont le résultat d’années de recherche dans le domaine de la conception et de la production de pompe à chaleur pour piscine et spa. Notre ambition, vous fournir un produit de qualité...
- Page 3 WARNING This heat pump contains R32 flammable refrigerant. Prior approval must be obtained before any procedure is performed on the refrige- rant circuit. To ensure user safety, the following precautions must be followed before any procedure is performed on the refrigerant circuit. 1.
- Page 4 ACKNOWLEDGEMENTS Dear customer, Thank you for your purchase and your trust in our products. Our products are the result of years of research in the design and manufacture of heat pumps for pools. Our goal is to deliver high-quality products with exceptional performance. We took great care to put together this manual so you can get the most out of your Poolex heat pump.
- Page 5 ⚠ ⚠ PLEASE READ CAREFULLY These installation instructions form an integral part of the product. They must be provided to the installer and kept in a safe place by the user. If you lose this manual, please visit our website: www.poolex.fr The indications and warnings contained in this manual should be carefully read and understood as they provide important information regarding the safe handling and operation of the heat pump.
- Page 6 CONTENTS 1. General information 1.1 General terms and conditions of delivery 1.2 Safety instructions 1.3 Water treatment 2. Description 2.1 Operating limits 2.2 Package contents 2.3 General characteristics 2.4 Technical characteristics 2.5 Product dimensions 2.6 Exploded view 3. Installation 3.1 Location 3.2 Installation diagram 3.3 Hydraulic connection 3.4 Electrical connection...
- Page 7 CONTENTS 5.10 Status values 5.11 User settings 6. Use of optional control relays 6.1 Using the SPA heater control relay 6.2 Using the circulation pump control relay (optional) 7. Use via mobile application 7.1 Downloading & installing the application «Smart Life» 7.2 Setting up the application 7.3 Pairing the heat pump 7.4 Controlling...
- Page 8 1. GENERAL INFORMATION General terms and conditions of delivery All products and packaging, even those delivered carriage paid, travel at the risk of the recipient. Persons responsible for accepting delivery of the device must perform a visual inspection to make a note of any damage that may have occurred during transportation (refrigeration circuit, casing, electric box, frame).
- Page 9 1. GENERAL INFORMATION When in use Do not touch the vent during operation due to the risk of serious injury. Do not leave the heat pump within reach of children due to the risk of injury caused by the heat exchanger fins.
- Page 10 2. DESCRIPTION Operating limits For the heat pump to operate normally, the ambient air temperature must be between -25°C and 43°C. However, we recommend winterising your spa if the water temperature falls below 10°C. Your hot tub must be correctly insulated to enable the heat pump to function in an optimal way. ✓...
- Page 11 2. DESCRIPTION Technical characteristics ICE SPA 70 ICE SPA 70 Heating power (kW) 3.3~7 26°C 0.28~1.4 Consumption (kW) Water 26°C COP (Coeff. of performance) 11.9~5 Heating power (kW) 2.3~5.4 15°C Consumption (kW) 0.35~1.1 Water 26°C COP (Coeff. of performance) 6.6~4.9 Heating power (kW) 2.8~4.7 15°C...
- Page 12 2. DESCRIPTION Product dimensions Dimensions in mm Note: When the electric heating, water pump, and wire control are not fully connected, please use 'rubber plug' to avoid damage due to moisture. EN | 55...
- Page 13 2. DESCRIPTION Exploded view Top cover Motor support component Side panel mounting strips Electronic expansion valve Electrical components Flash evaporator Pressure gauge Chassis components Inducer seal box Anti-vibration feet Inductor Drain elbow Display box assembly Chassis heating belt Fan motor Compressor Front panel assembly Evaporator components...
- Page 14 3. INSTALLATION To install the heat pump the hydraulic circuit and the power need to be connected. Location Standard NF C 15-100 recommends installing the heat pump at least 2.5 meters from the spa. However, thanks to the differential circuit breaker, you can also choose to install it closer: Leave at least 1.50 m in front of the heat pump and 50 cm of empty space to the sides and rear of the heat pump.
- Page 15 3. INSTALLATION Installation diagram The filter located upstream of the heat pump must be regularly cleared so that the water in the system is clean, thus avoiding the operational problems associated with dirt or clogging in the filter. * If the relay is installed outdoor, please install it with the wire outlet side facing down. Hydraulic connection Step 1 Step 2...
- Page 16 3. INSTALLATION Operation Use conditions For the heat pump to operate normally, the ambient air temperature must be between -25°C and 43°C. Advance notice Prior to starting the heat pump, please: ✓ Check that the equipment is secure and stable. ✓...
- Page 17 4. USE OF CONTROL PANEL Control panel Heating mode WiFi indicator "ON/OFF” button “High” button “Mode” button “Low” button Automatic mode Cooling Circulation pump mode indicator Heater pilot indicator (RECH indicator) Heating / Cooling / Automatic mode Before use, ensure that the filtration pump is working and that water is circulating through the heat pump.
- Page 18 4. USE OF CONTROL PANEL Functions overview The indicators to the right of the control panel indicate the heat pump’s other functions. WiFi indicator Indicates your Wifi connection status. Flashes during pairing (see paragraph "4.7 Wifi connection", page 62). It remains on when a connection is active.
- Page 19 4. USE OF CONTROL PANEL Locking and unlocking In the main interface, if no key is pressed for 30s, the control panel is locked automatically. When the screen is locked, it displays "LOC". Press the simultaneously for 3 seconds to lock and unlock the control panel. When the device unlocks, it emits a long beep.
- Page 20 4. USE OF CONTROL PANEL Setting When the heat pump is off, press for 3 seconds. to access the settings interface. The parameter code appears and the value is displayed after 3 seconds. to navigate between the different parameters. Use the arrows To change a parameter: Display the parameter to be changed, then press The parameter value starts flashing.
- Page 21 4. USE OF CONTROL PANEL 4.10 Forced defrost The heat pump must be set to 40°C for this procedure to work. Set the heat pump to 40°C in heating mode, then use the arrows to force defrosting: > > > >...
- Page 22 5. USE OF WIRE CONTROLLER Installation The remote control panel or wire controller is an option that allows you to control your heat pump from a remote location. To optimise the readability of the screen and its durability, place it away from direct sunlight, rain and splashing water (IPX5 protection rating).
- Page 23 5. USE OF WIRE CONTROLLER Control panel Before use, ensure that the filtration pump is working and that water is circulating through the heat pump. Fonction Heating mode Automatic mode Cooling mode Defrost Frost protection Circulation pump Lock icon Fonction Time programming ON/OFF button Silent mode...
- Page 24 5. USE OF WIRE CONTROLLER Sound and light settings Audible warning Each time it is pressed, the buzzer emits a short beep. The user can deactivate the buzzer by setting parameter P1 to 0. See "5.10 User parameters", page 25. Backlighting Set parameter P2 on the remote control panel to 1 to activate the backlight or to 0 to deactivate the backlight.
- Page 25 5. USE OF WIRE CONTROLLER Time programming Timer ON interface Programmed start displays the time and icon, as well as the set temperature that will be executed after start-up. The other dis- plays are consistent with the shutdown interface. Example of display: 1.
- Page 26 5. USE OF WIRE CONTROLLER 5.10 Status values Press for 5 seconds to view the status values. In this interface, the time zone displays the code of the parameter to be interrogated and the temperature zone displays the value of the parameter. Press to move up or down the page.
- Page 27 5. USE OF WIRE CONTROLLER 5.11 User settings From the main interface, press for 5 seconds to access the user parameters consultation interface. In this interface, the time zone displays the code of the parameter to be interrogated and the temperature zone displays the value of the parameter.
- Page 28 6. USE OF OPTIONAL CONTROL RELAYS Using the SPA heater control relay Poolex Relay 240VAC 30A SPA heater 125VAC 30A controller 250VAC 15A cos Ø = 0.4 Insulate the connectors inside the spa in a waterproof connection box elements not provided) The SPA heater driver system consists of a power relay (230V50Hz / 30A) which plugs into the heater phase wire (between the SPA heater controller output and the heater itself).
- Page 29 6. USE OF OPTIONAL CONTROL RELAYS Using the circulation pump control relay (optional) Poolex Relay 240VAC 30A 125VAC 30A 250VAC 15A cos Ø = 0.4 Circulation pump Insulate the connectors inside the spa in a waterproof connection box elements not provided) This relay is controlled by the heat pump control box either automatically or manually.
- Page 30 For more information, refer to the “Help” section of the “Smart Life” app. The “Smart Life” app and services are provided by Hangzhou Tuya Technology. The company Poolstar, owner and distributor of the Poolex brand, cannot be held responsible for the operation of the "Smart Life" application.
- Page 31 7. USE VIA MOBILE APPLICATION Setting up the application WARNING : Before you begin, make sure you have downloaded the «Smart Life» app, connected to your local WiFi network, and that your heat pump is electrically powered and running. You’ll need to create a «Smart Life» account to control your heat pump remotely. If you already have a Smart Life account, please log in and go directly to step 3.
- Page 32 7. USE VIA MOBILE APPLICATION Step 3 (recommended): Add an object by clicking “...” and then “Add Object”. Enter a name («Pool» for example), then click “Done”. Now add a device to your “Pool”. Step 4: Click “Add” or “+” and then “Large appliances...” followed by “Water heater”. At this point, leave your smartphone on the “Add”...
- Page 33 7. USE VIA MOBILE APPLICATION Pairing the heat pump Step 1: Now start the pairing. Choose your home WiFi network, enter the WiFi password and press “Confirm”. WARNING : The «Smart Life» application only supports 2.4Ghz WiFi networks. If your WiFi network uses the 5GHz frequency, go to the interface of your home WiFi network to create a second 2.4GHz WiFi network (available for most Internet boxes, routers and WiFi access points).
- Page 34 7. USE VIA MOBILE APPLICATION Controlling 1. User interface Current spa temperature Temperature set point Current operating mode Switch the heat pump on/off Change the temperature Change operating mode Set the operating range To adjust the temperature, you can drag the semi-circular scale bar or click on "+/-".
- Page 35 7. USE VIA MOBILE APPLICATION 3. About the settings Activating the manual mode (or automatic) for the SPA heater Activating the manual mode (or automatic) for the optional pump Mode memory during stop Timer Parameter settings Viewing status values Resetting parameters 4.
- Page 36 7. USE VIA MOBILE APPLICATION 5. Setting parameters To change the settings, you will be asked for a code: please contact our team to request permis- sion to change the settings and to obtain the code. Make sure you enter consistent values in the system. EN | 79...
- Page 37 7. USE VIA MOBILE APPLICATION 6. Reset settings To reset settings, you will be asked for a code: 7416. After entering the password to reset the parameters, all the parameter setting options are returned to their default values. 80 | EN...
- Page 38 7. USE VIA MOBILE APPLICATION 7. Viewing status values The application lets you view status values in list form. You will find: • Ambient temperature • Condenser temperature • Compressor outlet temperature • Compressor suction temperature • Inlet temperature • Outlet temperature •...
- Page 39 7. USE VIA MOBILE APPLICATION 8. Upgrade operation To update your device, follow these steps: Click the edit icon in the upper right corner of the home page Click ‘Device Update’ Press ‘Update’ Press ‘Start update’ 82 | EN...
- Page 40 8. MAINTENANCE AND REPAIRS Maintenance, servicing and winterizing : Before undertaking maintenance work on the unit, ensure WARNING that you have disconnected the electrical power supply. Cleaning The heat pump housing must be cleaned with a damp cloth. Using detergents or other household cleaning products may degrade the surface of the housing and affect its integrity.
- Page 41 8. MAINTENANCE AND REPAIRS Under normal conditions, a suitable heat pump can heat up the tub water by 1°C to 2°C per hour. It is therefore normal that you do not feel any difference in temperature at the outlet level when the heat pump is on. A heated tub must be covered and insulated to avoir any heat loss.
- Page 42 8. MAINTENANCE AND REPAIRS Code Malfunction or protection Troubleshooting Outdoor DC fan failure 1. Strong wind or typhoon below toward to the fan, to make thefan running in the opposite direction. Change the unit direction or make shelter to avoid typhoon below to the fan. 2.
- Page 43 8. MAINTENANCE AND REPAIRS Code Malfunction or protection Troubleshooting Temperature sensor failure DSP and communication board communication fault 1. Check input power supply,wiring. Abnormal communication with 2. Check input voltage. main PCB 3. Check and replace. 4. Check whether the working load of the unit is out of range. IPM module overheating 5.
- Page 44 Poolstar. The parts under warranty shall be replaced or repaired at the discretion of Poolstar. Faulty parts must be returned to us during the warranty period in order to be covered. The warranty does not cover unauthorized labor or replacement costs.
- Page 45 A. Annexe / Apéndice / Appendice / Appendix / Anhang / Bijlage A.1. Schéma électrique / Diagrama de cableado / Schema electtrico / Wiring diagram / Stromlaufplan / Elektrisch schema...
- Page 46 A. Annexe / Apéndice / Appendice / Appendix / Anhang / Bijlage A.2. Branchement des relais / Conexión de relés / Connessione a relè / Relay connection / Anschließen der Relais / Relaisaansluiting...
