GBA C 4220 3 E
Instructions for Use
Hot plate glass ceramic for
flush built-in 30-90°C
The device must not be used if the glass ceramic is cracked or broken. The device
DANGER
must then be switched off immediately and disconnected from the power supply.
Model-No.
26040/60/FB
26032/53/FB
26065/53/FB
26065/53/FB-D
26098/53/FB
26098/53/FB-D
Scholl Apparatebau GmbH & Co. KG
Zinhainer Weg 4
D–56470 Bad Marienberg/Germany
Phone
+0049 (0) 2661 – 9868-10
Fax
+0049 (0) 2661 – 9868-38 (Service)
Internet
www.scholl-gastro.de
E-mail
info@scholl-gastro.de
BA
Last revised 06-2021
Art.-No.
C 4220
C 4230
C 4241
C 4246
C 4251
C 4256
Page 1 of 24
Juni 8, 2021
Rev. 3
Advertisement
Related Manuals for Scholl 26040/60/FB
Summary of Contents for Scholl 26040/60/FB
- Page 1 C 4230 26065/53/FB C 4241 26065/53/FB-D C 4246 26098/53/FB C 4251 26098/53/FB-D C 4256 Scholl Apparatebau GmbH & Co. KG Zinhainer Weg 4 D–56470 Bad Marienberg/Germany Phone +0049 (0) 2661 – 9868-10 +0049 (0) 2661 – 9868-38 (Service) Internet www.scholl-gastro.de E-mail info@scholl-gastro.de...
- Page 2 GBA C 4220 3 E ABLE OF CONTENTS Table of contents ............................... 2 Preface ................................4 Conventions ............................... 5 Pictograms – General safety notes ....................5 Pictograms – Warning notes ......................7 Pictograms – Important notes ......................8 Product information ..........................9 Information regarding compliance with standards, laws and directives .........
- Page 3 GBA C 4220 3 E Execution............................19 Dimensioned drawings........................20 Circuit diagrams ..........................20 Spare parts list..........................21 Disposal and Environmental Notes ......................22 Disposal of packing material ......................22 Disposal of the appliance ....................... 22 Warranty and service ......................... 23 10.1 Warranty conditions ........................
- Page 4 REFACE Congratulations! In purchasing this new SCHOLL appliance you have chosen a product which meets highest technical stand- ards while providing outstanding convenience in practical use. This appliance has been designed with minimal energy consumption in mind. Used responsibly, it will serve you well in an ecologically sound manner.
- Page 5 GBA C 4220 3 E ONVENTIONS – G ICTOGRAMS ENERAL SAFETY NOTES Be sure to observe these Instructions for Use as well as the safety notes to prevent injuries or damage to health or property. Do not alter or modify this appliance. Never use a defective appliance.
- Page 6 GBA C 4220 3 E Do not touch the surfaces of the appliance. The surfaces of this appliance may get hot. Please allow the unit to cool down fully before cleaning or stowing it. Never cover this appliance. Burn injury or fire hazard! Do not allow the glass surface to be scratched by pointed or sharp objects.
- Page 7 GBA C 4220 3 E – W ICTOGRAMS ARNING NOTES Before any cleaning, maintenance or repair work is carried out, the appliance must be disconnected from the mains and de-energized. To do so, it is not enough to set the power switch to OFF. Instead, the mains plug must be pulled or the electrical circuit must be de-energized, respectively.
- Page 8 GBA C 4220 3 E – I ICTOGRAMS MPORTANT NOTES DANGER indicates an immediately threatening hazard. Failure to observe this warning notice will result in severe physical injury or death. WARNING indicates a potentially dangerous situation. Failure to observe this warning notice may result in severe physical injury or death.
- Page 9 GBA C 4220 3 E RODUCT INFORMATION Hot plates are electrically heated and are used for keeping the preheated food and baked goods on output temperature. Hot plates are feeded from above using appropriate dishes. NFORMATION REGARDING COMPLIANCE WITH STANDARDS LAWS AND DIRECTIVES This appliance conforms to the following: Standards, laws, directives...
- Page 10 GBA C 4220 3 E ACKING TRANSPORT INTERMEDIATE STORAGE SCOPE OF DELIVERY ACKING The type of packing employed will depend, to a large extent, on the adopted shipping mode and route. Except where otherwise agreed by contract, packing will conform to the "HPE Packing Guideline" defined by the German Federal Association of the Wooden Materials, Pallets and Export Packing Industry and by the German Engineering Federation.
- Page 11 GBA C 4220 3 E NSTALLATION AND ELECTRICAL INSTALLATION NSTALLATION Before the installation of the appliance, observe the following: Inspect the unit for any defect or damage sustained in transit. Check all screw connections for tightness. Familiarize yourself with the Instructions for Use and with the conditions for the safe operation of this appliance.
- Page 12 GBA C 4220 3 E LECTRICAL INSTALLATION The appliance may only be installed by a qualified electrician whilst taking into account the applicable regulations! Connect this appliance to suitably earthed mains outlets only. Ensure that your mains power supply conforms to the data stated on the nameplate of the appliance. Failure to observe this warning may result in a fire hazard or electrical shock! Before putting the appliance into service, observe the following: ...
- Page 13 GBA C 4220 3 E PERATION The hot plate has a thermostat, an indicator lamp and a red LED under the ceramic glass for each GN 1/1 field to warn of residual temperature. The separately heated hot plate 2 x GN 1/1 has 2 thermostats and 2 indicator lamps. The separately heated hot plate 3 x GN 1/1 has 3 thermostats and 3 indicator lamps.
- Page 14 GBA C 4220 3 E NTENDED USE Practice: Turn the thermostat to the maximum temperature (position "10"). The heating time of the hot plate is approx. 45 minutes. After the heating time, the device is ready for operation and can be equipped with the foods to be kept warm.
- Page 15 GBA C 4220 3 E AINTENANCE AINTENANCE AND REPAIR Maintenance and repairs on the appliance must only be carried out by an author- ized professional observing applicable safety regulations. Improperly executed work will put your safety at risk! Before any cleaning, maintenance or repair work is carried out, the appliance must be disconnected from the mains and de-energized.
- Page 16 GBA C 4220 3 E Cleaning must only be performed by qualified persons who have read and under- stood these Instructions for Use and are familiar with applicable hygiene rules. En- sure that care is exercised during cleaning of the unit. Cleaning of stainless steel For light cleaning, wipe down the surface with a cloth or soft brush/sponge soaked in warm water which contains a small amount of dishwashing detergent.
- Page 17 GBA C 4220 3 E ROUBLESHOOTING Repairs must be carried out by an authorized specialist in compliance with applica- ble safety codes and regulations. Improperly executed work will put your safety at risk! Note that some work must only be carried out by an electrical specialist. According to DIN EN 60204-1: 2011-01, specialists are "persons who by reason of their relevant training and experience are capable of recognizing risks and avoiding potential hazards."...
- Page 18 GBA C 4220 3 E OSSIBLE MALFUNCTIONS Malfunction Cause Remedy Hot plate does not heat Defective plug/electrical cord DANGER! Hazardous electrical voltage. Pull out the mains plug and bar product from further use. To be remedied by an electrical specialist. Hot plate does not heat Overheating protection has Let the device cool off until the...
- Page 19 Mounting height 160 mm with cable gland and compliance with the minimum bending radius of the cable Model-No. Art.-No. L/mm D/mm H/mm GN/BN Voltage Power 26040/60/FB C 4220 1xBN 230V~ 0,45kW 26032/53/FB C 4230 1 x GN 1/1 230V~ 0,40kW...
- Page 20 GBA C 4220 3 E IMENSIONED DRAWINGS Dimensioned drawings are available upon request. The information in the dimensioned drawings always take precedence over the summary of the technical data in chapter 8.1. IRCUIT DIAGRAMS Circuit diagrams are available upon request. Page 20 of 24 Juni 8, 2021 Last revised 06-2021...
- Page 21 GBA C 4220 3 E PARE PARTS LIST Maintenance and repairs on the appliance must only be carried out by an author- ized professional observing applicable safety regulations. Improperly executed work will put your safety at risk! Work at the electrical installation must only be performed by qualified electricians! Art.
- Page 22 GBA C 4220 3 E ISPOSAL AND NVIRONMENTAL OTES The appliance has been packed before shipping to protect it against damage in transit. After unpacking, please dispose of packing materials in an environmentally sound manner. All packing materials are eco-compatible, 100% recyclable and marked with a sym- bol to that effect.
- Page 23 GBA C 4220 3 E ARRANTY AND SERVICE 10.1 W ARRANTY CONDITIONS The manufacturer accepts no liability or warranty in the following cases: failure to observe notes and instructions given in the Instructions for Use; use of the product in a manner not conforming to its intended use; ...
- Page 24 7:00 a.m. till 4:00 p.m. Fridays from 7:00 a.m. till 12:15 p.m. Outside these office hours please communicate your requests per e-mail or telefax. Scholl Apparatebau GmbH & Co. KG Zinhainer Weg 4 D-56470 Bad Marienberg/Germany Phone 0049 (0)2661/9868-10...
