Sealey YK30FAH.V2 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE
OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY INSTRUCTIONS
1.1 GENERAL SAFETY
Familiarise yourself with this products application and limitations, as well as the specific potential hazards peculiar to the press.
Maintain the press in good condition (use an authorised service agent).
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
Keep the press clean for best and safest performance.
Locate the press in an adequate working area for its function, keep area clean and tidy and free from unrelated materials, and ensure
there is adequate lighting.
Ensure the workpiece is correctly secured before operating the press.
WARNING! Always wear approved eye or face protection when operating the press.
Remove ill fitting clothing. Remove ties, watches, rings, and other loose jewellery, and contain long hair.
Keep hands and body clear of the work table when operating the press.
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
Keep children and unauthorised persons away from the working area.
DO NOT operate the press if any parts are missing as this may cause failure or possible personal injury.
DO NOT force the press to achieve a task it was not designed to perform.
DO NOT adjust or tamper with the safety valve.
DO NOT exceed the rated capacity of the press.
DO NOT apply off centre loads.
DO NOT allow the workpiece or the arbor plates to fall from the press working bench.
DO NOT get the press wet or use in damp or wet locations or areas where there is condensation.
DO NOT operate the press when you are tired, under the influence of alcohol, drugs or intoxicating medication.
When not in use release pressure from the pump and clean the press. Stand or store the arbors in a safe location.
 WARNING! Always position the press against a wall. If the press is situated in the open workshop, it is essential that a guard be
placed at the rear of the unit. This will prevent injury to bystanders in the event of the work piece ejecting suddenly.
 WARNING! The warnings, cautions and instructions in this manual cannot cover all possible conditions and situations that
may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this
product, but must be applied by the operator.
 DANGER! The press is top heavy. If it requires moving after assembly or for relocation, use suitable slings around the top crossbeam, or
lift direct with a forklift with the forks located under the top crossbeam. DO NOT use a pallet truck.
2. INTRODUCTION & SPECIFICATIONS
Heavy-duty press frame with integrally mounted air motor powering reliable hydraulic pump unit. Reinforced frame head fitted with sliding
hydraulic ram assembly giving 250mm of lateral travel for off-centre pressing applications. Fitted with ram pressure gauge and table winch
aiding exact alignment of the ram head and workpiece. Supplied with a pair of V-blocks.
 WARNING! All models are purpose designed to withstand greater loads than the hydraulic units can develop. For safety reasons, always
ensure the workpiece is secured on table and loads that flex will not suddenly "give" causing danger to operator or damage to component.
Model: YK30FAH.V2
capacity
Ram Stroke 95mm
Extension screw 75mm
Lateral ram travel 250mm
Max Ht-ram to table 615mm
Min Ht-ram to table 165mm
Table Aperture 145mm
Work table width 710mm
overall Height 1770mm
Gauge Included
Weight
Working Pressure 100 - 145psi
Air consumption 9.0cfm
3. ASSEMbLY
WARNING! This equipment is very heavy! 2 - 3 people will be required to manoeuvre the components during assembly.
Ensure correct form is observed where lifting is involved and that all health and safety precautions regarding the movement/use of such
equipment are observed.
Unpack product and check contents against list above. Should there be any damaged or missing parts contact your supplier immediately.
Retain pressure gauge in carton until required, and do not remove white tape from gauge mount.
YK50FAH.V3
30ton 50ton
120mm
75mm
250mm
720mm
155mm
170mm
710mm
1910mm
Yes Yes
202kg 242kg
100 - 145psi
9.5cfm
InSTRUcTIonS FoR:
AIR HYDRAULIC FLOOR PRESS
Models: YK30FAH.V2, YK50FAH.V3
List of Contents
Frame
Legs
Worktable
Worktable Pins
V-Blocks
Pump Handle
Pressure Gauge
Winch Handle
Quantity
1
1
1
2
2
1
1
1
YK30FAH.V2 & YK50FAH.V3 Issue no: 1 - 01/12/08
