3-Point Post Hole Digger
PART # 24-0361, MODEL 400
PART # 24-0362, MODEL 650
PART # 24-0318, MODEL 1000
PART # 24-0337, MODEL 1500
Operation Manual
messages in this manual. Failure to follow this important
safety information may result in serious injury or death.
29-019
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AGKNX 400
Summary of Contents for AGKNX 400
- Page 1 3-Point Post Hole Digger PART # 24-0361, MODEL 400 PART # 24-0362, MODEL 650 PART # 24-0318, MODEL 1000 PART # 24-0337, MODEL 1500 Operation Manual messages in this manual. Failure to follow this important safety information may result in serious injury or death.
- Page 3 Personal Protective Equipment ..........4 General Safety ..............5 Safety Decals ..............7 Assembly Instructions ............8 Operating Instructions ............12 Maintenance ..............13 Parts List Model 1500 ............14 Parts List Model 1000 ............15 Parts List Model 650 ............16 Parts List Model 400 ............17 ..........18 Registration ..............19...
- Page 4 IMPORTANT SAFETY INFORMATION WARNING: Read and thoroughly understand all instructions and safety information before assembling or operating this post hole digger. Failure to do so may cause serious injury or death. Do not allow anyone to operate this post hole digger who has not read this manual. As with all power equipment, a post hole digger can be dangerous if assembled or used improperly.
- Page 5 IMPORTANT SAFETY INFORMATION GENERAL SAFETY Failure to follow warnings, cautions, assembly and operation instructions in the Operation Manual may result in serious injury or death. Read the Operation Manual before operation. Do not permit children to operate this equipment at any time. Do not permit others that have not read and understood the complete Operation Manual to operate this equipment.
- Page 6 IMPORTANT SAFETY INFORMATION Make sure that the tractor brake is set before deploying the post hole digger. Do not manually deploy the auger. Do not manually position or force the auger into the ground. tractor engine before leaving the seat of the tractor. Do not Do not exceed the 540 RPM PTO operating speed.
- Page 7 IMPORTANT SAFETY INFORMATION SAFETY DECALS Make sure all safety warning decals are attached and in readable condition. Replace missing or 720-437-7640 for replacement decals. 6) Part # 29-021 7) Part # 29-027 2) Part # 29-024 8) Part # 29-025 3) Part # 29-023 4) Part # 29-023 1) Part # 29-026...
- Page 8 ASSEMBLY INSTRUCTIONS STEP 1: The gear box is shipped without lubricant. Fill the top hole with 80W-90 gear oil or equivalent. The this can cause damage to the seals. Check the oil level every 50 hours of operation. STEP 2: Remove the manual and hardware pack from the manual canister B .
- Page 9 ASSEMBLY INSTRUCTIONS STEP 4: Connect the “A” frame assembly C to the tractor’s 3-point lift arms. Attach the boom assembly B to the tractor. A bushing is included in the hardware kit to attach the Model 650 boom to a CAT 1 tractor.
- Page 10 3/8”-16 hex nut E . A 3/8" x 2.5" G2 shear bolt is used on the model 400 and model 650. A 3/8" x 3" G2 shear bolt is used on the model 1000 and model 1500. Insert the ¼”x 3/8”...
- Page 11 ASSEMBLY INSTRUCTIONS STEP 7: Attach the auger B to the output shaft on the bottom of the gear box using the hex bolts 1/2"- 13x3.5" E , ½” lock washer D and ½” hex nut C . Tighten the hardware. NOTE: See the images below for reference in assembling the digger and mounting it to the tractor.
- Page 12 OPERATING INSTRUCTIONS WARNING: Read and thoroughly understand all instructions and safety information before assembling or operating this post hole digger. Failure to do so may cause serious injury or death. STEP 1: After attaching the post hole digger to the tractor, before engaging the power, slowly lower the auger to the ground at the desired angle for hole digging.
- Page 13 MAINTENANCE ALWAYS PERFORM MAINTENANCE OPERATIONS WITH THE TRACTOR’S ENGINE POWERED OFF, PTO DISENGAGED, AND THE AUGER TIP RESTING ON THE GROUND. Before operation check all safety shields. Replace shields that are worn or broken before operating the post hole digger. When the self-sharpening points on the auger show excessive wear it is important to replace them.
- Page 14 POST HOLE DIGGER PARTS LIST MODEL 1500 POST HOLE DIGGER ITEM # DESCRIPTION 27-024 SERIES 4 DRIVELINE 95462A545 7/8”- 14 HEX NUT 91102A037 7/8” LOCK WASHER 43-027 7/8” DRAW PIN 24-0358 MODEL 1500 A-FRAME 24-0029 A-FRAME PIN 43-047 7/16” LYNCH PIN AUGER (VARIOUS SIZES) 95462A033 1/2”-13 HEX NUT...
- Page 15 POST HOLE DIGGER PARTS LIST MODEL 1000 POST HOLE DIGGER ITEM # DESCRIPTION 27-024 SERIES 4 DRIVELINE 95462A545 7/8”- 14 HEX NUT 91102A037 7/8” LOCK WASHER 43-027 7/8” DRAW PIN 24-0356 MODEL 1000 A-FRAME 24-0029 A-FRAME PIN 43-047 7/16” LYNCH PIN AUGER (VARIOUS SIZES) 95462A033 1/2”-13 HEX NUT...
- Page 16 POST HOLE DIGGER PARTS LIST MODEL 650 POST HOLE DIGGER ITEM # DESCRIPTION 27-023 SERIES 1 DRIVELINE 95462A545 7/8”- 14 HEX NUT 91102A037 7/8” LOCK WASHER 43-027 7/8” DRAW PIN 24-0370 MODEL 650 A-FRAME 24-0029 A-FRAME PIN 43-047 7/16” LYNCH PIN AUGER (VARIOUS SIZES) 95462A033 1/2”-13 HEX NUT...
- Page 17 POST HOLE DIGGER PARTS LIST MODEL 400 POST HOLE DIGGER ITEM # DESCRIPTION 27-023 SERIES 1 DRIVELINE 95462A545 7/8”- 14 HEX NUT 91102A037 7/8” LOCK WASHER 43-027 7/8” DRAW PIN 24-0016 MODEL 400 A-FRAME 24-0029 A-FRAME PIN 43-047 7/16” LYNCH PIN...
- Page 18 WARRANTY IMPORTANT NOTICE reference only. Warranty Repair and Service Do not return this product to the store for warranty issues or repair. Call our customer service department at 303-278-0664 for the location of the nearest service center. Record the information below for future reference. Model No.
- Page 19 REGISTRATION Acceptance of responsibility: explained all instructions to me. I understand this warranty does not cover any labor and that all disputes will be settled by binding arbitration. Warranty void if any attempt to repair or replace defective parts has been made by unauthorized personnel. The mark next to each item below understand that I alone am responsible for the proper maintenance, care and safe operation of this post hole digger.
- Page 20 REGISTRATION Warranty void if registration not postmarked within 15 days of purchase! WARRANTY REGISTRATION BY MAIL To register your device: 1. Fill in the information below. 2. Cut out and attach receipt or proof of purchase. 3. Mail to: 15000 West 44th Ave, Suite B Golden, CO 80403 WARRANTY REGISTRATION INFORMATION Purchase date:...
