AGKNX 400 Operator's Manual

3-point post hole digger
Hide thumbs Also See for 400:

Advertisement

Quick Links

3-Point Post Hole Digger
Operator's Manual
Product registration form included in this booklet. Register your product today.
For Models:
400 (24-0361)
650 (24-0362)
1000 (24-0318)
1500 (24-0337)
Part # 29-019
(for replacement manual)
Rev. C (01/24)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 400 and is the answer not in the manual?

Questions and answers

Summary of Contents for AGKNX 400

  • Page 1 3-Point Post Hole Digger Operator's Manual For Models: 400 (24-0361) 650 (24-0362) 1000 (24-0318) 1500 (24-0337) Product registration form included in this booklet. Register your product today. Part # 29-019 (for replacement manual) Rev. C (01/24)
  • Page 3: Table Of Contents

    Safety Decals ........................8 Parts List Model 1500 ......................9 Parts List Model 1000 ....................... 10 Parts List Model 650 ......................11 Parts List Model 400 ......................12 Assembly Instructions ....................13-16 Operating Instructions ...................... 17 Maintenance & Specifications ..................18 Warranty ...........................
  • Page 4: Welcome

    Welcome! Thanks for buying an AgKNX 3-point post hole digger! We design our products to meet the high standards of our industrial and commercial clients, with ease-of-use that’s aimed at homeowners and do-it-yourselfers. That means that our products are tough enough to meet the rigorous demands of the industry, but designed for non- professionals to learn to use.
  • Page 5: Safety First

    Safety First! This safety alert symbol identifies important safety messages in this manual. Failure to follow this important safety information may result in serious injury or death. Use common sense and stay safe! This "Notice" symbol is used throughout this manual to identify situations in Notice: which damage to equiptment may occur;...
  • Page 6: General Safety Information

    GENERAL SAFETY INFORMATION GENERAL SAFETY Failure to follow the warnings, cautions, assembly and operation instructions below and throughout this manual may result in serious injury or death. SERIOUS INJURY OR DEATH WILL RESULT FROM ENTANGLEMENT WITH MOVING PARTS. DO NOT OPERATE THE POST HOLE DIGGER WHILE ANYONE IS IN CONTACT WITH ANY PART OF THE IMPLEMENT, INCLUDING THE PTO DRIVELINE AND AUGER.
  • Page 7: Additional Safety Information And Best Practices

    ADDITIONAL SAFETY INFORMATION Notice: The information below is provided for better operation and extended working life with your 3-pt. post hole digger. Follow the guidelines below for best results. If not followed your safety could be put at risk. ● READ YOUR TRACTOR'S OPERATION MANUAL concerning the proper attachment and use of 3-point equipment and safety.
  • Page 8: Safety Decals

    SAFETY DECALS SAFETY DECALS Make sure all safety warning decals are attached and in readable condition. Replace missing or defaced decals. Call or e-mail Tool Tuff Direct for replacement decals: (720) 437-7640; techsupport@tooltuffdirect.com 6) Part # 29-021 7) Part # 29-027 2) Part # 29-024 8) Part # 29-025 3) Part # 29-023...
  • Page 9: Parts List Model 1500

    POST HOLE DIGGER PARTS LIST MODEL 1500 POST HOLE DIGGER ITEM # DESCRIPTION 27-024 SERIES 4 DRIVELINE 95462A545 7/8”- 14 HEX NUT 91102A037 7/8” LOCK WASHER 43-027 7/8” DRAW PIN 24-0358 MODEL 1500 A-FRAME 24-0029 A-FRAME PIN 43-047 7/16” LYNCH PIN AUGER (VARIOUS SIZES) 95462A033 1/2”-13 HEX NUT...
  • Page 10: Parts List Model 1000

    POST HOLE DIGGER PARTS LIST MODEL 1000 POST HOLE DIGGER ITEM # DESCRIPTION 27-024 SERIES 4 DRIVELINE 95462A545 7/8”- 14 HEX NUT 91102A037 7/8” LOCK WASHER 43-027 7/8” DRAW PIN 24-0356 MODEL 1000 A-FRAME 24-0029 A-FRAME PIN 43-047 7/16” LYNCH PIN AUGER (VARIOUS SIZES) 95462A033 1/2”-13 HEX NUT...
  • Page 11: Parts List Model 650

    POST HOLE DIGGER PARTS LIST MODEL 650 POST HOLE DIGGER ITEM # DESCRIPTION 27-023 SERIES 1 DRIVELINE 95462A545 7/8”- 14 HEX NUT 91102A037 7/8” LOCK WASHER 43-027 7/8” DRAW PIN 24-0370 MODEL 650 A-FRAME 24-0029 A-FRAME PIN 43-047 7/16” LYNCH PIN AUGER (VARIOUS SIZES) 95462A033 1/2”-13 HEX NUT...
  • Page 12: Parts List Model 400

    POST HOLE DIGGER PARTS LIST MODEL 400 POST HOLE DIGGER ITEM # DESCRIPTION 27-023 SERIES 1 DRIVELINE 95462A545 7/8”- 14 HEX NUT 91102A037 7/8” LOCK WASHER 43-027 7/8” DRAW PIN 24-0016 MODEL 400 A-FRAME 24-0029 A-FRAME PIN 43-047 7/16” LYNCH PIN...
  • Page 13: Assembly Instructions

    ASSEMBLY INSTRUCTIONS The gearbox is shipped without lubricant. DO NOT attempt to operate the Notice: device without first filling it with 80w-90 gear oil: model 1500 gearboxes take approximately 75 fl.oz. (2.25 liters) of oil, all other models take 50 fl.oz. (1.5 liters) STEP 1: Fill the gearbox with lubricant.
  • Page 14 ASSEMBLY INSTRUCTIONS STEP 4: Connect the boom [1] and A-frame [2] to the tractor’s 3-point lift arms. Next, mount the boom [1] to the A-frame [2] using the A-frame pin [4]. Secure with lynch pin [3]. When mounting the boom to the A-frame, the pin position may need to be adjusted. Notice: The size of your tractor and auger will determine which boom hole works best for the angle adjustment: with the tractor lift arms raised, the auger should 6"...
  • Page 15 BOLT THAT IS LONGER OR STRONGER (HIGHER G RATING) THAN DESCRIBED HERE. YOU RISK DAMAGE TO EQUIPMENT AND PERSONAL INJURY! Model 400 and Model 650 require a 3/8"x 2.5" G2 shear bolt. Model 1000 and Model 1500 require a 3/8" x 3" G5 shear bolt.
  • Page 16 ASSEMBLY INSTRUCTIONS STEP 7: Attach the auger [1] to the output shaft on the bottom of the gearbox and secure with two ½" x 3½" hex bolts [4], ½” lock washers [3] and ½” hex nuts [2]. Tighten all hardware securely. The images below are for reference when assembling the digger and mounting it to the Note: tractor.
  • Page 17: Operating Instructions

    OPERATING INSTRUCTIONS FOLLOW ALL SAFETY GUIDLINES WHEN OPERATING THIS POST HOLE DIGGER. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. STEP 1: After attaching the post hole digger to the tractor, before engaging the power, slowly lower the auger to the ground at the desired angle for hole digging.
  • Page 18: Maintenance & Specifications

    MAINTENANCE ALWAYS PERFORM MAINTENANCE OPERATIONS WITH THE TRACTOR’S ENGINE POWERED OFF, PTO DISENGAGED, AND THE AUGER TIP RESTING ON THE GROUND. Gearbox lubrication: Check the oil level after every 50 hours of operation. Use 80W-90 lubricant or equivalent and fill to oil level plug.
  • Page 19: Warranty

    WARRANTY We warranty all AgKNX parts for manufacturing defects: 3 years from date of purchase for gearboxes, and 1 year for all other parts. The warranty gives the consumer certain and specific rights which may vary from state to state.
  • Page 20 NOTES PAGE 20...
  • Page 21: Registration

    REGISTRATION Acceptance of Responsibility: I (the purchaser) have read the Operation Manual and Limited Warranty or someone has read and explained all instructions to me. I understand this warranty does not cover any labor and that all disputes will be settled by binding arbitration. Warranty void if any attempt to repair or replace defective parts has been made by unauthorized personnel.
  • Page 22 15000 West 44th Ave, Suite B Golden, CO 80403 WARRANTY REGISTRATION FORM Product: 3-point Post-Hole Digger Model 400 (SKU # 24-0361); Model 650 (SKU# 24-0362); Model 1000 (SKU# 24-0318); Model 1500 (SKU# 24-0337) Device Serial #: Purchase date: Purchased from (Store / City):...
  • Page 23 ToolTuff Direct 15000 W 44th Ave., Ste B Golden, CO 80403 For service call or email: 720-437-7640 customerservice@tooltuffdirect.com...
