- Page 1 FT10CMQ Quick Start Guide Version: 1.0...
- Page 2 Overview Front Back Side Microphone 1.25"(31.8mm) Proximity sensor Bottom Security Camera Near-Infrared Flash Card Reading Area Binocular Camera Touch Doorbell LED Indicator 2.76"(70.0mm) Speaker Tamper Switch Terminal Block Reset...
- Page 3 Installation Environment Please refer to the following recommendations for installation. 10ft KEEP DISTANCE AVOID GLASS AVOID DIRECT KEEP EFFECTIVE REFRACTION SUNLIGHT DISTANCE AND EXPOSURE 0.5-2m Recommended Palm Gestures KEEP EFFECTIVE KEEP SPACES DO NOT KEEP DISTANCE OF BETWEEN YOUR FINGERS 20 to 40 cm YOUR FINGERS CLOSE...
- Page 4 Recommended Method for Swiping Card The Specific Range of Card Reading Area: Notes for Swiping Card: 1. Supports card orientation in horizontal, vertical, and oblique directions. 2. The card should be placed parallel to the device. 3. Ensure that the card is at the center of the card reading area. Frequency Protocols Card Types...
- Page 5 Device Installation With Backplate: Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. Fix the Backplate on the wall using wall mounting screws. Attach the device to the Backplate. Fasten the device to the Backplate with a security screw. Baseline 59"(1.5m)
- Page 6 Standalone Installation RS485 RS485 Exit button Reader Wiegand Card Bell Reader Smoke Detector Door Sensor Alarm Lock TCP/IP Terminal Block ALARM+ ALARM- Alarm & Bell BELL+ BELL- Lock, 12-24VIN 12-24VIN Door Sensor, 12-24VIN Exit Button & Power In Auxiliary Input 12V_OUT Power Out, RS-485A...
- Page 7 Power Connection The device can be powered using either a 12-24V DC power adapter or PoE, depending on availability. 12-24V Recommended AC Adapter 12V, 3A / 24V, 1.5A. To share the power with other devices, use an AC Adapter with higher current ratings. Ethernet Connection Connect the device and computer software over an Ethernet cable.
- Page 8 Wiegand Reader Connection 12V_OUT 12V_OUT Access RS-485A Controller RS-485A RS-485B RS-485B Wiegand D0-OUT Wiegand D1-OUT Wiegand D0-OUT Wiegand D0-IN Wiegand D1-IN Wiegand D1-OUT Wiegand D0-IN +9~24V DC Wiegand D1-IN Ground Wiegand Data 0 Wiegand Data 1 Wiegand Reader RS485 Connection +12V 12V_OUT 485+...
- Page 9 Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally unlocked when power-on) is connected with 'NO' and 'COM' terminals, and the NC LOCK (normally locked when power-on) is connected with 'NC' and 'COM' terminals. Take NC Lock as an example below: 1) Device not sharing power with the lock +12V DC 12V...
- Page 10 Door Sensor, Exit Button, Auxiliary Connection Door Sensor Smoke Detector Detector Power ExitButton Alarm, Bell Connection DC 12V ALARM+ ALARM+ ALARM- Alarm ALARM- BELL+ BELL+ BELL- BELL- Bell DC 12V...
- Page 11 Controller Connection The device can be used as a reader and connected to the AHSC-1000 controller via RS-485. AHSC-1000 Controller +12V 120Ω 485+ 485- 485 Reader...
- Page 12 Armatura Connect Step 2: Activate your credentials on the Armatura ID App When you register as a user of Armatura ID, you will receive an email with activa -tion code from Armatura. Please activate your mobile credential according to the following steps.
- Page 13 Login to the Webserver Step 1: Login to the Webserver After the device is powered on, connect the device using a network cable. Access the WebServer by entering the IP address and server port in the address bar of your browser. The IP address is set as: https://device IP address:1443.
- Page 14 Step 2: Modify the IP address Click [Advanced Settings] > [COMM.] to set the network parameters. Step 3: Cloud Service Setting Click [Advanced Settings] > [Cloud Service Setup] to set the server address and server port, that is, the IP address and port number of the server after the software is installed.
- Page 15 IP addresses of the server (PC) and the device are in the same network segment. 1. Log into the Armatura One software. 2. Click [Access] > [Device] > [Device] > [New] > [Search] to search the device on the software.
- Page 16 Step 2: Register users on the Armatura One software 1. Click [Personnel] > [Personnel] > [New] and fill in all the required fields to register a new users in the software. Personnel + New 2. Click [OK] to save and exit.
- Page 17 Device Set Access Levels Step 1: Add Access Levels Group 1. Click [Access] > [Access Control] > [Access Levels] to enter the setting interface. 2. Click [New] to add a new access control level group. 3. Enter the level name, time zones and setting area, then click [OK] to confirm and exit.
- Page 18 3. Select the person and then click > to move it to the selected column on the right. 4. Click [OK] to confirm and exit. Set Access By Levels For more details, please refer to the Armatura One User Manual.
- Page 19 Click button to confirm the reader. Then click [Connect] to connect the reader. 4. Click [Company Assignment] and select the company in the popup window. Then click [Assign] to assign the reader to the specified company. FT10CMQ...
- Page 20 Using Mobile Credential Open the Armartura ID App. You can use mobile credential in two ways. Mode 1: Using Remote Mode 1. After enabling the Remote Mode, click icon > [Credentials] to enter the Credentials. 2. Directly click the icon to swipe the card remotely within the valid range. 3.
- Page 21 > [Credentials] to enter the Credentials. 2. Click icon to open Mobile Credentials. 3. Hold your mobile phone close to the reader until you hear a "beep" and the LED lights up red, indicating that the card is swiped successfully. Verication successful FT10CMQ-0006...
- Page 22 Copyright © 2024 ARMATURA LLC. All rights reserved.
