- Page 1 PLANETARY MIXER HURAKAN HKN-IP10FM, HKN-IP15FM, HKN-IP20FM, HKN-IP30FM, HKN-IP40FM, HKN-IP50FM, HKN-IP60FM DEUTSCH EESTI ENGLISH ITALIANO LATYSŠSKI LIETUVIŠKAS POLSKI РУССКИЙ...
- Page 2 1. Specifications Bowl Max. Voltage, Power Mixing speed Dimensions Model volume, mixed (kW) (rpm) (mm) mass (kg) HKN- 220-240 0,37 90/160/300 444x360x650 IP10FM HKN- 220-240 0,37 90/160/300 444x360x650 IP15FM HKN- 220-240 1,10 105/180/425 513x405x762 IP20FM HKN- 220-240 1,50 110/200/420 450x430x880 IP30FM HKN- 380-415...
- Page 3 compliance may result in fire. • Some models are equipped with a 3-phase motor, it is necessary to check whether it rotates in the direction indicated by the mark. If the direction of rotation is incorrect, change two of the three electrical phases between each other. Never install attachments during testing, otherwise they will fall out if the direction is wrong, and cause the damage of the equipment parts.
- Page 4 • When not in use or used in adverse weather conditions, disconnect the machine from the power source to prevent accidents. • It is strictly forbidden to wash the machine with an open source of water. Failure to observe this rule may result in equipment damage and possibly fatal injury. Do not allow water to get on the outlet and switch.
- Page 5 conventional press button, or in the form of an emergency switch (mushroom button). If your mixer has a mushroom emergency stop button, then after pressing it, the mixer will stop and will not start until the button is deactivated by turning it clockwise by 30°. When turned, the button will return to its original position and the mixer can be started again.
- Page 6 Dough hook: used for kneading batter or other non-sticky products at low speed. Operating cycle: up to 20 min of work, then a break of at least 20 min. One-time loading: the bowl should be filled with the product no more than 30% full. Beater: used for mixing loose, pasty or chopped products at medium speed.
- Page 7 the machine. • Conduct a survey of the personnel working with the machine to identify uncharacteristic operation of the machine. • Check the condition of the machine visually. • Check for exposed wires. • Check the continuity of the grounding line and the grounding circuit of the machine itself (from the grounding clamp to the accessible metal parts –...
