Page 1
Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page 2
Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page 3
Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page 5
• You can use any DLNA V1.5 certified media server • AI Sound software (DMS class). • AI EQ • You can use the Philips TV Remote app (iOS and For 9206 Series: Android) on mobile devices. Output power (RMS) : 50W Performance may vary, depending on the capabilities Dolby MS12 V2.5...
Page 6
(DMS class). • Mains power : AC 220-240V +/-10% • You can use the Philips TV Remote app (iOS and • Ambient temperature : 5°C to 35°C Android) on mobile devices. • Power saving features : Eco mode, Picture mute (for Performance may vary, depending on the capabilities radio), Auto switch-off timer, Eco settings menu.
Page 7
Refer to the diversity tables for the correct values. two pins of the Mains/AC Power plug. • The correct component values are listed on the Philips • Check the cabinet for defects, to prevent touching of any Spare Parts Web Portal.
Page 8
• Mix of lead-free soldering tin/parts with leaded soldering tin/parts is possible but PHILIPS recommends strongly to avoid mixed regimes. If this cannot be avoided, carefully clear the solder-joint from old tin and re-solder with new tin.
Page 9
originating from the USA and used e.g. in • Always respect voltages. While some may not be dangerous in themselves, they can cause unexpected LATAM and AP-NTSC countries reactions that are best avoided. Before reaching into a B-TXT Blue TeleteXT powered TV set, it is best to test the high voltage Centre channel (audio) insulation.
Page 10
G-TXT Green TeleteXT distance is 6.5 MHz. L' is Band I, L is all H_sync to the module bands except for Band I High Definition LG.Philips LCD (supplier) Hard Disk Drive Loudspeaker HDCP High-bandwidth Digital Content Protection: LVDS Low Voltage Differential Signalling A “key”...
Page 11
Serial Peripheral Interface bus; a 4-wire module, implementing the CA system for a synchronous serial data link standard host (e.g. a TV-set) S/PDIF Sony Philips Digital InterFace Power On Reset, signal to reset the uP SRAM Static RAM PSDL Power Supply for Direct view LED...
Page 12
Thin Film Transistor toward external amplifier Total Harmonic Distortion Vestigial Side Band; modulation method TMDS Transmission Minimized Differential WYSIWYR What You See Is What You Record: record Signalling selection that follows main picture and Transport Stream sound TeleteXT WXGA 1280 × 768 (15:9) TXT-DW Dual Window with TeleteXT XTAL...
Page 28
(85x6 Series stand removal-1) (85x6 Series stand removal-2) Stand removal and rear cover for PML9636 series 1. Remove the cover in the blue box first 2. Release the connector from the Audio Board in red box as following 3. Remove the fixation screws [1] that secure the stand. 4.
Page 29
(65"/75" PML9636 Series stand removal -2) 3.2.2 Rear Cover Warning: Disconnect the mains power cord before removing the rear cover. For (85x6 Series) 1. Remove all fixation screws [4] that secure the Back cover assy. 2. Unplug the connectors that marked by red circle below from SSB, and take the cables from the clip that in red box 3.
Page 31
3.2.4 IR Board Control Unit 1. Release the connectors from the IR Board. Caution: be careful, the Keyboard is catch on the Back cover, please be careful to avoid damage the fragile connectors! 2. Remove all the fixation screws from the IR and keyboard control panel [2] and take it out from the Back cover. When defective, replace the whole unit.
Page 32
3.2.8 WIFI module 1. Unplug the connector from the SSB. 2. Remove fixation screw that secure the WIFI module. When defective, replace the whole unit. 3.2.9 LCD Panel 1. Remove the SSB as described earlier. 2. Remove the PSU as described earlier. 3.
Page 33
4. Service Modes 4.1 Service Modes The Service Mode feature is split into following parts: Service Alignment Mode (SAM). Factory Mode. Customer Service Mode (CSM).SAM and the Factory mode offer features, which can be used by the Service engineer to repair/align a TV set. ...
Page 34
– (De) activate the selected menu item. – (De) activate the selected sub menu. – Change the value of the selected menu item. When you press the MENU button once while in top level SAM, the set will switch to the normal user menu (with the SAM mode still active in the ...
Page 35
Remark: Under main menu “NVM editor”, you can use the UP/DOWN keys to view and change the set Type number, the set Production Number or the 18AC of a part.(The NVM-editor still has the same function as before, alpha-numeric entry.) 4.3 Factory mode: Purpose To perform extended alignments.
Page 36
4.4 Customer Service Mode (CSM) Purpose The Customer Service Mode shows error codes and information on the TVs operation settings.The call centre can instruct the customer (by telephone) to enter CSM in order to identify the status of the set.This helps the call centre to diagnose problems and failures in the TV set before making a service call.
Page 37
5. Software Upgrading, Error code and Panel Code 5.1 Software Upgrading 5.1.1. The following update is for .pkg file. 1. Rename the file to “upgrade_loader.pkg”. 2. Prepare a USB memory (File format: FLAT, Size: 1G~8G). 3. Copy the software to USB flash disk (root directory). 4.
Page 38
Step 2: F/W Upgrade 1. Press [Settings]> [update software], then Choose [Search for update] in the Settings menu, and press OK. 2. Choose [USB], then press OK. 3. Choose [Identify], then press OK. 4. .Select the file that you downloaded and press OK 5.
Page 39
6.Choos [Upadte] press OK start the softwear update. 6. Upgrade in progress Step 3: Check the SW version After burning software, TV will restart Press “123654”, enter Customer Service Mode to check if the software version is correct. Caution: Please make sure that software upgrade is finished before unplug the USB and AC power!
Page 40
5.2 Error Code 5.2.1 Introduction Error codes are required to indicate failures in the TV set. In principle a unique error code is available for every: • Activated (SW) protection. • Failing I2C device. • General I2C error. The last five errors, stored in the NVM, are shown in the Service menu’s. This is called the error buffer. The error code buffer contains all errors detected since the last time the buffer was erased.
Page 41
“Set Option Code” in below tab. After resetting the Display Code, restart the set immediately. Serial No Panel ID Set Option CTN_ALT BOM# Panel Type Code 43PUS8506/12 TPT430U3-QVN03.U SBB0G 43PUS8506/12 TPT430WR-EQYSMA.G S3A 43PUS8506/12 TPT430WR-QUBF70.K SNWPAB 43PUS8536/12 TPT430U3-QVN03.U SBB0G...
Page 44
Trouble shooting 2016年12月10日 2016/4/8 Picture-related Intermittent Ask Photo Picture ? problem ? Menu Smarkt Signal SW latest ? Backlight? issue function? issue SSB+LVDS+Panel Update SW LED working ? PSU/SSB Problem solved ? Sound ? PSU+ Panel Finish SW+SSB...
Page 45
Trouble shooting 2016年12月10日 2016/4/8 Audio/Sound- related Intermittent Sound ? problem ? Setting SW latest ? Mute ? issue issue Update SW Extra device Check extra connect? device Problem solved ? Factory setting Finish Sound back ? Setting issue SSB+SPK...
Page 46
6.Slow response to user interaction 7.Switches ON by itself 8.Switches Off by itself 9.Stuck in standby mode / unable to start up 10.Stuck on PHILIPS / ANDROID logo 11.CAM not recognized by TV 12.CAM authentication issue 13.Misc CAM issue 14.IP-EPG issues 15.BC-EPG issues...
Page 47
7.Electrical Diagram Block diagram 7.2 Power Supply Power architecture of this platform. AUDIO LVDS Platform power Display power CN8601 ON/OFF Platform PS_ON MT9970A 12V_A CN1190 AC-input + Main filter AC IN...
Page 53
9. Circuit Diagrams 9.1 A 715GA052 PSU (For 43”85x6 Series) 9-1-1 AC Input F9902 T 5 A H / 2 5 0 V 5A 250V FB9901 D9901 BEAD NR9902 SG9901 PG4007 Spark Gap 500V F9901 T 5 A L / 2 5 0 V NC / 5A 250V BD9901 C9913...
Page 55
9-1-3 Main Power HS9123 36 KOHM +-1% 1/8W R9103 HEAT SI NK R9100 F o r D 9 1 2 3 R9101 3M 1% 3M 1% R9191 +Vboost H O T C O L D C9102 2.2NF 10% 50V D9123 R9192 2 4 V / 3 .
Page 63
9-3-3 LLC with MD6701 F o r D 9 1 2 1 & D 9 1 2 2 & D 9 1 2 3 HS9101 D9123 C 9101 H O T C O L D HEAT SINK F CQS20A065 R 9105 10K 5% 1/4W T9101 12VS...
Page 67
9-4-3 LLC with MD6701 & PF7302 HS9101 HEAT SINK H OT COLD C9101 2.2nF 1KV HS9131 R9101 4 0 m m 3 5 m m For Q9101 & Q9102 12VS T9101 D9104 R9102 IN4148W Q9101 2 N t R9105 0R05 IPA60R400CE M a x : 8 A 470R 1/8W 1%...
Page 75
9-6-3 LLC with SSC3S927 Vbus C9922 NC/330PF 250V HS9101 68K OHM 1% 1/10W R9101 R9100 R9103 3M 1% 3M 1% C9101 D9102 C9103 FR107G-A0 R9123 2.2NF 1KV/1000PF HEAT SINK C9102 D9104 H O T C O L D 2.2NF 50V Q9101 1N4148W F o r...
Page 77
9.7 A 715GC008 PSU (For 65” PML9506/9636 Series) 9-7-1 AC Input F r o m P S U F r o m F r om D O B O U T DOB IN +VLED +VLED CN8101 CN8102 F r o m CONN 26P CONN 26P SSB or...
Page 82
9.9 A 715GC018 PSU (For 75” PML9506/9636 Series) 9-9-1 AC Input F r o m P S U F r o m F r o m D O B O U T DOB IN +VLED +VLED CN8101 CN8102 F r o m CONN 26P CONN 26P SSB or...
Page 83
9.10 B 715GB414M SSB( For 9006 & 85x6/12 Series) 9-10-1 SOC-EMMC 2 4 M C R Y ST A L M T 9 9 7 0 H E A T S I N K +3V3-STANDBY +3V3-STANDBY X401 D4001 D4002 XTALI XTALO HS401 LBAV99WT1G...
Page 84
9-10-2 SOC-DDR4-1-2 D D R 4 # 1 U401-1 U402A U402B DDRV_VDD1 EMI0_DMI0 EMI0_DMI0 VDD1_1 VSS_1 EMI0_DQS0_T EMI1_DQ0 EMI0_DQ0 EMI0_DQS0_T DQ0_a DQ0_b VDD1_2 VSS_2 EMI0_DQS0_C EMI1_DQ1 EMI0_DQ1 EMI0_DQS0_C DQ1_a DQ1_b VDD1_3 VSS_3 EMI0_DQ0 EMI1_DQ2 EMI0_DQ2 V D D 1 = 1 . 8V EMI0_DQ0 DQ2_a DQ2_b...
Page 86
9-10-4 DDR POWER L P D D R 4 P o w 1 . 1 V DDRV_PWR_CTRL DDRV_PWR_CTRL +5V-STANDBY R4127 0R05 1/10W DDRV_VDD2 C4165 C4166 R4112 U406 C4171 L4104 10uF 10V 100NF 16V NC/10K 5% 1/16W 100NF 16V VBST DDRV_VDD1 2.2uH R4111 TPS563201DDCR...
Page 87
9-10-5 FE-TUNER-DEMOD Cl o s e a i n C h i p C248 C l o s e a i n C h i p C205 NC/100NF 16V C201 NC/47PF 50V NC/10PF 50V TUNER_LNB C222 IF_P_TU R214 C203 TU_FAT_IN2+ R201 R207 ADCINPI_DEMOD...
Page 88
9-10-6 SOC-VB1-OUT T 9 9 7 0 V x 1 U T P U T V - B Y - 1 U T P U T D i s p l a y TP3790 U401-3 CN1162 AM12 VB1_1P SOC-VB1-TX0P 100NF 16V C3001 CONN 51P VB1_1P...
Page 93
9-10-11 AUDIO-1st-CLASS-D-AMP +12V-AUDIO +12V-AUDIO1 +12V-AUDIO1 CN604 +3V3-AUDIO1 +3V3 +12V-AUDIO1 FB5104 AUDIO-PD AMP-RESETn U p d a t e d 2 0 2 0 / 5 / 3 +3V3 SCL-SSB SDA-SSB SOC-I2S-SD1 SOC-I2S-LRCK 120R 3A +12V-AUDIO +12V-AUDIO U T E CI R CU I T SOC-I2S-BCLK FB7501 FB7502...
Page 95
9-10-13 PCMCIA 3 V 3 U401-8 DEMOD_RST TP7558 DEMOD_RST CIL_DEMOD0_CLK DEMOD_TSCLK TP7559 LED2 CIL_DEMOD0_CLK DEMOD_TSCLK LED2 DEMOD_TSDATA0 TP7560 +3V3 +3.3V_CI_Normal +3V3 CI_AVDD_1833 DEMOD_TSDATA0 CIL_TX_CLK DEMOD_TSDATA1 TP7561 CIL_TX_CLK DEMOD_TSDATA1 A d d For Home repair service 2 0 1 8 / 8 / 1 4 CIL_TX0_D0 DEMOD_TSDATA2 TP7562...
Page 96
9-10-14 HDMI-INPUTS H D M I 4 C o n n e c t e d p o r t 0 ( 2 . 0 ) H D M I 3 C o n n e c t e d p o r t 1 ( 2 .
Page 97
9-10-15 HDMI-SOC-ARC H D M I T M D S s i g n a l s Differential 100 Ohm nets U401-6 R7200 HDMI-CEC-IN 100 OHM HDMI-CEC-IN HDMI_CEC HDMI_0_RX_0 HDMI_0_RX_0 A n a l o g P o w HDMI_0_RX_0B HDMI_0_RX_0B HDMI_0_RX_1 HDMI_0_RX_1...
Page 99
9-10-17 CTRL-CONNECTORS SOC-AMBI-SPI-CLK SOC-AMBI-SPI-CLK CN1112 SOC-AMBI-SPI-MOSI P r e v i s i o n f o r S P I f r o m SOC-AMBI-SPI-MOSI CONN KEY BOARD KEYBOARD SOC-AMBI-SPI-CLK R3241 0R05 AMBI-SPI-CLK RC-IR RC-IR Main_12V LED2 +3V3 SDA-SET R7669 4.7K SDA-SET...
Page 100
9-10-18 CTRL-ETHERNET-PHY RJ 4 5 U401-10 C7604 AM24 ETHERNET-TXp 100NF 16V TXVP_0 AN24 ETHERNET-TXn T7601 W i - F i Co n t r o l TXVN_0 ETHERNET-TXp R7618 2R2 5% TXP0 C7653 10PF 50V AN23 ETHERNET-RXp RJ45_FE_TX+ CN1313 RXVP_1 AP23 ETHERNET-RXn +5V-WI FI...
Page 101
9.11 B 715GB843M SSB( For 85x6/62 Series) 9-11-1 SOC-EMMC 2 4 M C R Y ST A L M T 9 9 7 0 H E A T S I N K +3V3-STANDBY +3V3-STANDBY X401 D4001 D4002 XTALI XTALO HS401 LBAV99WT1G LBAV99WT1G 24MHz...
Page 104
9-11-4 DDR POWER L P D D R 4 P o w 1 . 1 V DDRV_PWR_CTRL DDRV_PWR_CTRL +5V-STANDBY R4127 0R05 1/10W DDRV_VDD2 C4165 C4166 R4112 U406 C4171 L4104 10uF 10V 100NF 16V NC/10K 5% 1/16W 100NF 16V VBST DDRV_VDD1 2.2uH R4111 TPS563201DDCR...
Page 105
9-11-5 FE-TUNER-DEMOD T U N E R TU201 TUNER_SCL C l o s e a i n C h i p C248 C l o s e a i n C h i p C205 NC/100NF 16V TUNER_SDA C201 NC/47PF 50V NC/10PF 50V TUNER_3V3 IF_P_TU...
Page 106
9-11-6 SOC-VB1-OUT T 9 9 7 0 V x 1 U T P U T V - B Y - 1 U T P U T D i s p l a y U401-3 TP3790 AM12 VB1_1P SOC-VB1-TX0P CN1162 100NF 16V C3001 VB1_1P AL12...
Page 108
9-11-8 DCDC-SYSTEM-POWER1 W E R I N P U T BL-ON BL-ON +3V3-STANDBY +3V3-STANDBY 12V-DETECT 12V-DETECT BL-DIM1 R4391 BL-DIM1 R4388 10K 5% STANDBY STANDBY TRIG_NORMAL_PWR BL_EVDD_ON BL_EVDD_ON R4390 +3V3-STANDBY +3V3 VCCK_VSEN CN1190 ZD4302 ZD4304 +5V-SW 4.7K VCCK_VSEN NC/0R05 OHM R4378 RLZ15B Q4312 NC/P4SMAJ15CA 15V...
Page 109
9-11-9 DCDC-SYSTEM-POWER2 WIFI-PWR-EN WIFI-PWR-EN LNB_EN LNB_EN + 1 2 V + 5 V - S W LNB_LINEDROP LNB_LINEDROP 13V/18V_SW 13V/18V_SW U1701 TUNER_LNB TUNER_LNB SY 8286ARAC DISEQC_OUT DISEQC_OUT C1711 100NF 16V DISEQ_IN_DIG DISEQ_IN_DIG +12V +5V-SW R1730 0R05 1/4W L1701 2.2uH 8.2A +12V R1731 C1715...
Page 110
9-11-10 DCDC-SYSTEM-POWER3 SCL-STB SCL-STB Main_12V SDA-STB SDA-STB OPWRSB_N OPWRSB_N C4116 C4122 C4125 C4124 C4154 C4155 PMIC_INT PMIC_INT 10uF 16V 10uF 16V NC/10UF 10% 16V NC/10UF 10% 16V NC/4.7U 10% 16V NC/4.7U 10% 16V A_MUTE A_MUTE GPU_P_VSEN GPU_P_VSEN U4101 PE642DT CPU_P_VSEN CPU_P_VSEN U p d a t e d 2 0 2 0 / 7 / 1 5...
Page 111
9-11-11 AUDIO-1st-CLASS-D-AMP U p d a t e d 2 0 2 0 / 7 / 1 5 CN604 +12V-AUDIO +12V-AUDIO1 +12V-AUDIO1 +3V3-AUDIO1 +3V3 +12V-AUDIO1 FB5104 AUDIO-PD Updated on 2020/5/3 AMP-RESETn +3V3 SCL-SSB SDA-SSB SOC-I2S-SD1 SOC-I2S-LRCK 120R 3A M UT E C I R C UI T +12V-AUDIO SOC-I2S-BCLK...
Page 114
9-11-14 HDMI-INPUTS H D M I 4 C o n n e c t e d p o r t 0 ( 2 . 0 ) H D M I 3 C o n n e c t e d p o r t 1 ( 2 .
Page 115
9-11-15 HDMI-SOC-ARC H D M I T M D S s i g n a l s Differential 100 Ohm nets U401-6 R7200 HDMI-CEC-IN 100 OHM HDMI-CEC-IN HDMI_CEC HDMI_0_RX_0 HDMI_0_RX_0 A n a l o g P o w HDMI_0_RX_0B HDMI_0_RX_0B HDMI_0_RX_1 HDMI_0_RX_1...
Page 117
9-11-17 CTRL-CONNECTORS SOC-AMBI-SPI-CLK SOC-AMBI-SPI-CLK CN1112 SOC-AMBI-SPI-MOSI P r e v i s i o n f o r S P I f r o m SOC-AMBI-SPI-MOSI CONN KEY BOARD KEYBOARD SOC-AMBI-SPI-CLK R3241 0R05 AMBI-SPI-CLK RC-IR RC-IR Main_12V LED2 +3V3 SDA-SET R7669 4.7K SDA-SET...
Page 118
9-11-18 CTRL-ETHERNET-PHY R J 4 5 U p d a t e d 1 8 A C 2 0 2 0 / 1 0 / 2 8 U401-10 C7604 AM24 ETHERNET-TXp 100NF 16V TXVP_0 AN24 ETHERNET-TXn T7601 i - F i C o n t r o l TXVN_0 ETHERNET-TXp...
Page 119
9.12 B 715GB126M SSB( For all size 9206 & PML9506Series) 9-12-1 SOC-EMMC 2 4 M C R Y ST A L M T 9 9 7 0 H E A T S I N K +3V3-STANDBY +3V3-STANDBY X401 D4001 D4002 XTALI XTALO HS401...
Page 122
9-12-4 DDR POWER L P D D R 4 P o w 1 . 1 V DDRV_PWR_CTRL DDRV_PWR_CTRL +5V-STANDBY R4127 0R05 1/10W DDRV_VDD2 C4165 C4166 R4112 U406 C4171 L4104 10uF 10V 100NF 16V NC/10K 5% 1/16W 100NF 16V VBST DDRV_VDD1 2.2uH R4111 TPS563201DDCR...
Page 123
9-12-5 FE-TUNER-DEMOD Cl o s e a i n C h i p C248 C l o s e a i n C h i p C205 NC/100NF 16V C201 NC/47PF 50V NC/10PF 50V TUNER_LNB IF_P_TU TU_FAT_IN2+ ADCINPI_DEMOD IFDEMOD_TP C222 R214 C203 R201...
Page 124
9-12-6 SOC-VB1-OUT T 9 9 7 0 V x 1 U T P UT +3V3-AVDD V- B Y- 1 UT P UT Di s p l a y TP3790 U401-3 CN1160 CN1162 CTRL-DISP4_FW_GPIO R3351 100 OHM AM12 VB1_1P 100NF 16V C3001 SOC-VB1-TX0P CONN 51P...
Page 126
9-12-8 DCDC-SYSTEM-POWER1 I N P U T O L E D n o n - O L E D +3V3-STANDBY +3V3-STANDBY R 4 3 1 9 Y e s 12V-DETECT 12V-DETECT BL-DIM1 BL-DIM1 R4391 R 4 3 2 3 Y e s STANDBY R4388 STANDBY...
Page 127
9-12-9 DCDC-SYSTEM-POWER2 WIFI-PWR-EN WIFI-PWR-EN LNB_EN LNB_EN LNB_LINEDROP + 1 2 V + 5 V - S W LNB_LINEDROP 13V/18V_SW 13V/18V_SW U1701 TUNER_LNB TUNER_LNB SY 8286ARAC DISEQC_OUT DISEQC_OUT C1711 100NF 16V DISEQ_IN_DIG DISEQ_IN_DIG +12V +5V-SW R1730 0R05 1/4W L1701 2.2uH 8.2A +12V R1731 C1715...
Page 132
9-12-14 HDMI-INPUTS H D M I 4 C o n n e c t e d p o r t 0 ( 2 . 0 ) H D M I 3 C o n n e c t e d p o r t 1 ( 2 .
Page 133
9-12-15 HDMI-SOC-ARC H D M I T M D S s i g n a l s Differential 100 Ohm nets U401-6 R7200 HDMI-CEC-IN 100 OHM HDMI-CEC-IN HDMI_CEC HDMI_0_RX_0 HDMI_0_RX_0 A n a l o g P o w HDMI_0_RX_0B HDMI_0_RX_0B HDMI_0_RX_1 HDMI_0_RX_1...
Page 135
9-12-17 CTRL-CONNECTORS SOC-AMBI-SPI-CLK SOC-AMBI-SPI-CLK P r e v i s i o n f o r S P I f r o m SOC-AMBI-SPI-MOSI SOC-AMBI-SPI-MOSI KEY BOARD KEYBOARD SOC-AMBI-SPI-CLK AMBI-SPI-CLK RC-IR R3241 0R05 RC-IR SDA-SET SDA-SET SOC-AMBI-SPI-MOSI AMBI-SPI-MOSI SCL-SET R3242 0R05 CN1107 SCL-SET...
Page 136
9-12-18 CTRL-ETHERNET-PHY RJ 4 5 U401-10 C7604 AM24 ETHERNET-TXp 100NF 16V TXVP_0 AN24 ETHERNET-TXn T7601 TXVN_0 ETHERNET-TXp R7618 2R2 5% TXP0 C7653 10PF 50V AN23 ETHERNET-RXp RJ45_F E_TX+ CN1313 W i - F i Co n t r o l RXVP_1 AP23 ETHERNET-RXn...
Page 137
9.13 B 715GC497M SSB( For PML9636 Series) 9-13-1 SOC-EMMC 2 4 M C R Y ST A L M T 9 9 7 0 H E A T S I N K +3V3-STANDBY +3V3-STANDBY X401 D4001 D4002 XTALI XTALO HS401 LBAV99WT1G LBAV99WT1G U p d a t e d...
Page 140
9-13-4 DDR POWER L P D D R 4 P o w 1 . 1 V DDRV_PWR_CTRL DDRV_PWR_CTRL +5V-STANDBY R4127 0R05 1/10W DDRV_VDD2 C4165 C4166 R4112 U406 C4171 L4104 10uF 10V 100NF 16V NC/10K 5% 1/16W 100NF 16V VBST DDRV_VDD1 2.2uH R4111 TPS563201DDCR...
Page 141
9-13-5 FE-TUNER-DEMOD Cl o s e a i n C h i p C248 C l o s e a i n C h i p C205 NC/100NF 16V Track1 is 900mil (RFIN to C3933) C201 NC/47PF 50V NC/10PF 50V Track2 i s 350mi l (C3933 to C3931) TUNER_LNB C222...
Page 142
9-13-6 SOC-VB1-OUT M T 9 9 7 0 V x 1 U T PU T +3V3-AVDD V- B Y- 1 UT P U T D i s p l a y TP3790 U401-3 CN1160 CN1162 CTRL-DISP4_FW_GPIO R3351 100 OHM AM12 VB1_1P SOC-VB1-TX0P CTRL-DISP8_ON_RF...
Page 147
9-13-11 AUDIO-1st-CLASS-D-AMP 12V-DETECT 9,16 12V-DETECT U T E C I R C U I T AMP-SHUTDOWNn 5805 1st AMP-SHUTDOWNn AMP-SHUTDOWN_5805 +12V +3V3 AMP-SHUTDOWN_5805 AUDIO-PD_5805_1n 11,13 AUDIO-PD_5805_1n CN604 5805 2nd +12V-AUDIO +12V-AUDIO1 +12V-AUDIO1 PDN_5805_2p +3V3-AUDIO1 +3V3 +12V-AUDIO1 PDN_5805_2p AUDIO-PD FB5100 R5190 R5194 AMP-RESETn AMP-RESETn...
Page 151
9-13-15 PCMCIA 3 V 3 P W R U401-8 DEMOD_RST TP7558 DEMOD_RST CIL_DEMOD0_CLK DEMOD_TSCLK TP7559 BL-DIM1 CIL_DEMOD0_CLK DEMOD_TSCLK BL-DIM1 DEMOD_TSDATA0 TP7560 +3V3 +3.3V_CI_Normal +3V3 CI_AVDD_1833 DEMOD_TSDATA0 CIL_TX_CLK DEMOD_TSDATA1 TP7561 CIL_TX_CLK DEMOD_TSDATA1 CIL_TX0_D0 DEMOD_TSDATA2 BT_EN A d d For Home repair service 2 0 1 8 / 8 / 1 4 TP7562 BT_EN...
Page 152
9-13-16 HDMI-INPUTS H D M I 4 C o n n e c t e d p o r t 0 ( 2 . 0 ) H D M I 3 C o n n e c t e d p o r t 1 ( 2 .
Page 153
9-13-17 HDMI-SOC-ARC H D M I T M D S s i g n a l s Differential 100 Ohm nets U401-6 R7200 HDMI-CEC-IN 100 OHM HDMI-CEC-IN HDMI_CEC HDMI_0_RX_0 HDMI_0_RX_0 A n a l o g P o w HDMI_0_RX_0B HDMI_0_RX_0B HDMI_0_RX_1 HDMI_0_RX_1...
Page 155
9-13-19 CTRL-CONNECTORS SOC-AMBI-SPI-CLK SOC-AMBI-SPI-CLK SOC-AMBI-SPI-MOSI P r e v i s i o n f o r S P I f r o m SOC-AMBI-SPI-MOSI KEY BOARD KEYBOARD SOC-AMBI-SPI-CLK AMBI-SPI-CLK RC-IR R3241 0R05 RC-IR SDA-SET SDA-SET SOC-AMBI-SPI-MOSI AMBI-SPI-MOSI SCL-SET R3242 0R05 CN1107 SCL-SET...
Page 156
9-13-20 CTRL-ETHERNET-PHY R J 4 5 U401-10 C7604 AM24 ETHERNET-TXp 100NF 16V TXVP_0 AN24 T7601 ETHERNET-TXn TXVN_0 ETHERNET-TXp R7618 2R2 5% TXP0 C7653 10PF 50V AN23 ETHERNET-RXp RJ45_FE_TX+ CN1313 i - F i C o n t r o l RXVP_1 AP23 ETHERNET-RXn...
Page 157
9.14 E 715GB499 IR Board (For 85x6 Series) 9-14-1 IR&STB LED&Light sensor L i g h t S e n s o r DVD3V3 U222 DVD3V3 C222 JSA-1136 C221 100N 16V 1uF 16V R221 R222 B o t t o m 10K 5% 10K 5% LS_SCL...
Page 158
9-14-2 Key/AL interface Y S T I C K C231 100PF 50V Joystick diversity for AL TACT SW 6P SW231 C N 2 4 1 C N 2 4 2 C 2 4 1 C 2 4 2 R241 R 2 4 2 R 2 4 3 R 2 4 4 Ri g h t...
Page 159
9.15 E 715GA039 IR Board (For 9026 Series) 9-15-1 IR&STB LED&Light sensor L i g h t S e n s o r DVD3V3 U222 DVD3V3 R 2 2 3 R 2 2 4 R 2 2 5 R 2 2 6 R 2 2 7 R 2 2 8 R 2 2 9...
Page 160
9.16 E 715GA334 Keyboard control panel (For 9206 Series) 9-16-1 Key CONN TO SSB JOYSTICK Joystick key define CN03 CN02 CN01 Direction switch Key functionResistance Voltage Range KEY1 Center 2-5 short Menu 0.0 to 0.22 V GND_Key AMBI_SPI_CLK CONN Right 1-5 short 0.5V 0.39 to 0.60 V...
Page 162
9.18 E 715GB037 Audio Board (For 48”/55”/65” OLED936 & PML9636 series) 9-18-1 sound board 6 5 m i l C e n t e r S P K 1 3 0 m i l W O O F E R S P K CN602 RSPK3p...
Page 196
11. Dismantling procedure for specific handling parts As complete appliances, LCDs are deemed to be hazardous waste (e.g. 16 02 13*, 20 01 35*) in the EU according to the German Waste Catalogue Ordinance. These appliances may only be handled by authorized handling plants. LCDs must be stored in accordance with the requirements stipulated in Appendix VIII (1) or (2) of Directive 2012/12/EU and must, amongst other things, be stored in a weatherproof manner.
Page 197
These substances, mixtures and components shall be disposed of or recovered in compliance with Directive 2008/98/EC cathode ray tubes: the fluorescent coating has to be removed equipment containing gases that are ozone depleting or have a global warming potential (GWP) above 15, such as those contained in foams and refrigeration circuits: the gases must be properly extracted and properly treated.
Page 198
can be removed with appropriate tools. The panel consists of several plastic sheets which can be processed. A final consideration is that of the back light which must be removed prior to processing. These may be present along either the bottom, or either side of the display as a strip of lights.
Page 199
A Power cord or other external cables plugged into the back of the LCD can easily be removed by hand and/or screwdriver; 2 types of connection of power cord are typical as shown in the pictures. Capacitors > 25 mm are located in the power supply units and can be removed by nipper.
