Colour Television
Contents
11. Styling Sheets
5101 series 32"
Published by XMM/SC 1611 Quality
©
TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page
Contents
2
2
5
9
9
9
21
23
30
37
Drawing PWB
38
40-41
42
44-45
46
62-63
64
65
66
67
68
69
Printed in the Netherlands
Chassis
TPM16.3L
Page
Subject to modification
EN 3122 785 20011
LA
2016-Mar-18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 32PHG5101/78 and is the answer not in the manual?

Questions and answers

Related Manuals for Philips 32PHG5101/78

Summary of Contents for Philips 32PHG5101/78

  • Page 1: Table Of Contents

    Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

  • Page 2: Revision List

    & drivers. Notes: • Figures can deviate due to the different set executions. Table 2-1 Described Model Numbers and Diversity Mechanics Schematics 32PHG5101/78 10.1 10.3 10.4 10.5 11.1 43PFG5101/78 10.2 10.3 10.4...
  • Page 3 Technical Specs, Diversity, and Connections TPM16.3L LA Connections Rear Connectors Side Connectors HDMI 2 SERV .U HDMI 1 TV ANTENNA SPDIF 20010_001.eps Figure 2-1 Connection overview Note: The following connector colour abbreviations are used 5 - HDMI 2 ARC: Digital Video - In, Digital Audio with ARC - (acc.
  • Page 4 Technical Specs, Diversity, and Connections TPM16.3L LA - D2+ Data channel 16 - DDC_SDA D DC data - Shield 17 - Ground Gnd - D2- Data channel 18 - +5V - D1+ Data channel 19 - HPD Hot Plug Detect - Shield 20 - Ground Gnd - D1- Data...

  • Page 5: Precautions, Notes, And Abbreviation List

    Spare Parts the following points: • Route the wire trees correctly and fix them with the For the latest spare part overview, consult your Philips Spare mounted cable clamps. Part web portal. • Check the insulation of the Mains/AC Power lead for external damage.
  • Page 6 Precautions, Notes, and Abbreviation List TPM16.3L LA result in sets which have the same CTN (Commercial Type 6 = play 16 : 9 format, 12 = play 4 : 3 Number; e.g. 28PW9515/12) but which have a different B.O.M. format number.
  • Page 7 6.5 MHz. L' is Band (VESA standard for communication I, L is all bands except for Band I channel and display). Using E-DDC, LG.Philips LCD (supplier) the video source can read the EDID Loudspeaker information form the display.
  • Page 8 SOPS Self Oscillating Power Supply Serial Peripheral Interface bus; a 4-wire synchronous serial data link standard S/PDIF Sony Philips Digital InterFace SRAM Static RAM Service Reference Protocol Small Signal Board Spread Spectrum Clocking, used to reduce the effects of EMI...

  • Page 9: Mechanical Instructions

    Mechanical Instructions TPM16.3L LA 4. Mechanical Instructions Index of this chapter: Notes: 4.1 Cable Dressing • Figures below candeviate slightly from the actual situa tion, 4.2 Service Positions due to the different set executions. 4.3 Assembly/Panel Removal 4.4 Set Re-assembly Cable Dressing ECN701 ECN408...
  • Page 10 Mechanical Instructions TPM16.3L LA ECN408 ECN701 CN8601 CN408 MAIN POWER SUPPLY (1054) (1053) ECN401 ECN601 ECN701 KEYBOARD CONTROL (1057) ECN408 ECN401 LOUDSPEAKER LOUDSPEAKER IR/LED BOARD CN201 (1056) (1184) (1184) 20011_100.eps Figure 4-2 Cable dressing (43" 5101 series) back to 2016-Mar-18 div.table...
  • Page 11 Stand assy_R, pull out them from the set. Refer to seriously damage the display! Figure 4-3 for details. Ensure that ESD safe measures are taken. Assembly/Panel Removal Instructions below apply to the 32PHG5101/78,but will be similar for other 32", 43"models. M4 × 14 20010_101.eps Figure 4-3 Stand removal 4.3.2...
  • Page 12 Mechanical Instructions TPM16.3L LA M3 × 6 M3 × 8 20010_102.eps Figure 4-4 Rear cover removal 4.3.3 Keyboard Control unit 1. Gently release the tapes that secure the keyboard cable. 2. Remove the fixation screws that secure the keyboard control panel. 3.
  • Page 13 Mechanical Instructions TPM16.3L LA 4.3.6 IR board Control Unit 4.3.8 Speakers Refer to Figure 4-6, Figure 4-7 for details. 1. Gently release the tapes that secure the speaker cables. 1. Unplug the connector from the SSB. 2. Unplug the speaker connector from the SSB. Caution: be careful, as these are very fragile connectors! 3.

  • Page 14: Service Modes, Error Codes, And Fault Finding

    Service Modes, Error Codes, and Fault Finding TPM16.3L LA 5. Service Modes, Error Codes, and Fault Finding • XXX is the main version number: this is updated with a Index of this chapter: 5.1 Service Modes major change of specification (incompatible with the 5.2 Stepwise Start-up previous software version).
  • Page 15 Service Modes, Error Codes, and Fault Finding TPM16.3L LA Main Menu Sub-menu 1 Sub-menu 2 Description Options OP#1-OP#8 e.g. “032” Option code Alignments Warm R Gain To align the White Tone. See paragraph 6.3 Software Alignments in the Alignments section for a detailed G Gain description B Gain...
  • Page 16 Service Modes, Error Codes, and Fault Finding TPM16.3L LA Default value Item Item value 40" Description NVM COPY TV to USB Press OK Use this to store the NVM data to the REPAIR folder of a FAT formatted USB memory stick. The TV will write two files in the REPAIR folder of the memory stick.
  • Page 17 Service Modes, Error Codes, and Fault Finding TPM16.3L LA Default value Item Item value 40" Description DUMP AQ FROM TV Press OK Saves the audio quality data to a file “AQ.bin” to the root of a FAT formatted USB memory stick LOAD AQ to TV Press OK Loads the audio quality data from a file “AQ.bin”...
  • Page 18 A description on how to upgrade the main check that what the current TV software: software can be found in the DFU or on the Philips website. 1. Press the “1 2 3 6 5 4” butto n on the remote control to enter the CSM mode.
  • Page 19 Service Modes, Error Codes, and Fault Finding TPM16.3L LA • Do not remove the USB flash drive during the software 5.3.5 Update the TV software update. • If a power failure occurs during the update, do not remove 1. Turn the TV on and wait for it to boot completely. the USB flash drive from the TV.
  • Page 20 Service Modes, Error Codes, and Fault Finding TPM16.3L LA An error with a designated error code never leads to a • It is assumed that the components are mounted correctly deadlock situation. It must always be diagnosable (e.g. error with correct values and no bad solder joints. buffer via OSD or blinking LED).

  • Page 21: Alignments

    Picture mode Screen size Green Blue signal strength of at least 1 mV and a frequency of Warm (6500K) 32PHG5101/78 128 61.25 MHz (channel 3). Normal (9000K) 32PHG5101/78 128 • LATAM models: an NTSC M TV-signal with a signal Cool (11000K)
  • Page 22 6-3. After resetting the Display Code, restart the set immediately. Table 6-3 Display code overview CTN_ALT BOM# Panel Type Display Code 32PHG5101/78 TPT315B5-WX226.K S4944G 32PHG5101/78 TPT315B5-0TU2A.Q S11B 43PFG5101/78 TPT430H3-DUYSHA.G S1U Reset of Repaired SSB A very important issue towards a repaired SSB from a Service repair shop (SSB repair on component level) implies the reset of the NVM on the SSB.

  • Page 23: Circuit Descriptions

    Circuit Descriptions TPM16.3L LA 7. Circuit Descriptions Index of this chapter: Introduction 7.1 Introduction The TPM16.3L LA is a new chassis launched in BRAZIL in 7.2 Power Supply 2016. The whole range is covered by MT5561LVNT. 7.3 DC/DC Converters The major deltas versus its predecessor support NTSC; 7.4 Front-End Analogue and DVB-T, DVB-C;...
  • Page 24 Circuit Descriptions TPM16.3L LA 7.1.3 SSB Cell Layout DC/DC DC/DC DC/DC DC/DC DC/DC MT5561 Headphone SERVICE CONNECTOR TUNER HDMI 20010_200.eps Figure 7-1 SSB layout cells (top view) back to 2016-Mar-18 div.table...
  • Page 25 This part is available in the regular market. PSL stands for Power Supply with integrated LED-drivers. Consult the Philips Service web portal for the order codes of the PSLS stands for a Power Supply with integrated LED-drivers boards.
  • Page 26 Circuit Descriptions TPM16.3L LA • TUNER3.3V, supply voltage for tuner DC/DC Converters The on-board DC/DC converters deliver the following voltages • +5V_SW, input intermediate supply voltage for the USB (depending on set execution): Power • PVDD from the power 12V_AMP for the AUDIO AMP. •...
  • Page 27 Circuit Descriptions TPM16.3L LA 7.3.1 Power layout SSB C409, Panel_VCC(12V) L703, +5VSB C719, DVDD3V3 C702, Vcck(1.2V) L401, DDRV(1.5V) U103, PIN5 1V2 C609, PVDD(12V) U113, TUNER3.3V 20010_200.eps Figure 7-4 Power SSB Top View back to 2016-Mar-18 div.table...
  • Page 28 Circuit Descriptions TPM16.3L LA 20010_200.eps Figure 7-5 Power SSB Bottom View Front-End Analogue and DVB-T, DVB-C; ISDB-T reception MxL661-AG-R 7.4.1 Front-End Analogue part The Front-End for analogue tuner consist of the following key components: IF_AGC IF_AGC • Silicon Tuner MxL661-AG-R RF_AGC •...
  • Page 29 Circuit Descriptions TPM16.3L LA • Panel overdrive control 7.4.2 Front-End ISDB Reception DTV part • Two-link LVDS The MT5561LVNT combines front-end video processing The Front-End for DVT part consist of the following key functions, support NTSC/PAL/SECAM TV decoder with a 3D components: comb filter (NTSC/PAL).

  • Page 30: Ic Data Sheets

    IC Data Sheets TPM16.3L LA 8. IC Data Sheets This chapter shows the internal block diagrams and pin configurations of ICs that are drawn as “black boxes” in the electrical diagrams (with the exception of “memory” and “logic” ICs). Diagram 10-3-1 System Power B01, M5723B (IC U703) Block diagram...
  • Page 31 IC Data Sheets TPM16.3L LA Diagram 10-3-2 Peripheral, B02, MT5561LVNT/B (IC U401) Block diagram MT5561LVNT I nput JPEG/M P2/M P4/ L VDS/min-L VS/ Demux DivX/H.264/VC-1/ Panel Demod RM /AVS/VP8 OD, TCON (option) Decoder s (option) Tuner I nput NTSC/ PAL / 2D/3D Conver ter Vplane SECAM...
  • Page 32 IC Data Sheets TPM16.3L LA Pinning Information MT5561LVNT DVSS AO0P AOCKP AE1P DVSS CI_A3 GPIO0 AO0N AOCKN AE1N CI_D0 CI_REG# TCON4 TCON2 AO1P AO2P AO3P AE0P AE2P AE3P CI_A1 CI_MOVAL TCON5 TCON7 AO1N AO2N AO3N AE0N AE2N AE3N CI_A0 CI_A4 TCON3 TCON0 GPIO1...
  • Page 33 IC Data Sheets TPM16.3L LA Pinning Information MT5561LVNT CI_MCLKO CI_MDI4 CI_A14 CI_MDI0 CI_IORD# CI_A10 FSRC_WR CI_A6 CI_MIVAL CI_WE# CI_A13 CI_A11 CI_CE1# CI_D7 CI_WAIT# CI_RESET CI_MDI3 CI_MDI2 CI_MDI1 CI_A8 CI_A9 CI_OE# CI_MDO7 CI_MDO6 CI_MOSTRT CI_A7 CI_D1 CI_MCLKI CI_MISTRT CI_IOWR# CI_D6 CI_MDO5 CI_D5 CI_MDO0 CI_MDI5...
  • Page 34 IC Data Sheets TPM16.3L LA Diagram 10-3-4 Speaker Amp B04, TAS5729MDDCAR (IC U601) Block diagram DVDD AVDD ANA_REG1 ANA_REG2 DIG_REG DRVDD DR_CN DR_CP DRVSS PVDD GVDD_REG TAS5729MDD Analog Supply Gate Drive Regulators Regulator Charge Pump Digital Supply Regulator PWM Power Stage Digital Audio Processor Full Bridge SPK_OUTA...
  • Page 35 IC Data Sheets TPM16.3L LA Diagram 10-3-9 TUNER B09, MxL661 (IC U104) Block diagram MxL661 IF1 Out Channel RF Input Balun Filtering IF2 Out AGC1 Synth Gain Calibration Control Synth Synth AGC2 Crystal Voltage Reference Regulator CLK_OUT Pinning information VDD_3p3 CLK_OUT LNA_INP LNA_INN...
  • Page 36 IC Data Sheets TPM16.3L LA Diagram 10-3-16 DEMOD_Toshiba TC90537 B16, TC90537FG (IC U101) Block diagram TC90537FG Quadrature Adaptive Interpolation ISIC (unguarded IF input Filter Frequency Pilot detection phase pre/post echo interpolation or IQ input extraction suppression) Correction filter Tuner Synchroni Equalization FFT window Control...

  • Page 37: Block Diagrams

    Block Diagrams TPM16.3L LA EN 37 9. Block Diagrams Block diagram 5101 series Silicon Tuner MxL661-AG-R IF+/- LVDS TSB Demod TC90537 DEMOD MT5561 SPIDF Out PC Audio in Headphone AMP APA2176A Headphone CVBS / L / R 5W SPK AUDIO AMP HDMI1 CN501 (Side)

  • Page 38: Circuit Diagrams And Pwb Layouts

    Circuit Diagrams and PWB Layouts TPM16.3L LA EN 38 10. Circuit Diagrams and PWB Layouts 10.1 A 715G7734 PSU 10-1-1 Power Power +18V BD9901 NC/KBJ608G-FUC BD9902 GBL408-C D9110 D9109 SR510-22 SR34H ZD9101 BZT52-B22 +12V_A D9111 +12VS SR510-22 R9130 Q9306 1K OHM Full range: BD9901/093G 50460938 L9101 D9112...
  • Page 39 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 39 10-1-2 LED Driver LED Driver R8615 C8617 22K 1/4W 100PF 500V +18V FB8605 L8602 BEAD VLED+ 47uH D8601 C8601 C8605 SR506 330UF 35V 0.1uF 50V C8621 C8623 R8612 R8611 Q8601: 357G0763100601 or D8602 0.1uF 50V 100K...
  • Page 40 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 40 10-1-3 Power layout top CN8602 FB9906 Q9101 BD9901 C9908 NR9901 BD9902 C9105 HS9101 C9126 C9102 FB8605 R9101 L9903 C9902 C9113 R8601 J9102 FB9908 C9903 J9106 C8601 L9901 L8602 J9120 T9101 J9107 R9907 CN9902 J9108...
  • Page 41 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 41 10-1-4 Power layout bottom MH19 R9142 R9128 R9127 R9103 R9102 JR9101 R9112 R9109 R8612 R8611 MH14 JR9103 R8608 R8647 R9108 R9104 R9105 C8602 C8606 R8603 JR9104 R9106 R9107 C8605 R8616 R9307 C9306 R9122 R8605...

  • Page 42: A 715G6934 Psu

    Circuit Diagrams and PWB Layouts TPM16.3L LA EN 42 10.2 A 715G6934 PSU 10-2-1 Power Power R9161 33ohm 1/ 4W +/-5% FB9902 HOT COLD 127R R9162 C9161 C9162 33ohm 1/ 4W +/-5% 1N5 50V 1N5 50V FB9901 R9163 BEAD 33ohm 1/ 4W +/-5% 12V Switch +12V1 +12V'...
  • Page 43 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 43 10-2-2 LED DRIVER LED DRIVER L8602 FB8602 +22V NC/BEAD D8602 NC/SR506 VLED+ FB8601 L8601 BEAD D8601 33uH SR506 D8605 NC/1N4148 C8601 C8607 C8605 R8603 R8604 C8606 220uF 50V 100K 100N 50V C8603 C8604 220uF 50V...
  • Page 44 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 44 10-2-3 Power layout top GND3 CN8601 GND1 C9921 HS9101 C9802 Q9101 J905 C9112 C9801 C9107 R9101 D9101 SG9901 C9103 C9105 J926 C9914 L9902 L8601 R9126 R9125 C9913 C9902 L8602 T9101 Q9121 U9102 C8601 CN9902...
  • Page 45 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 45 10-2-4 Power layout bottom C8605 R9113 R8603 C8608 R8604 C9106 R9107 R9104 C8611 R8610 R9103 R8608 R9108 C8613 R8607 R8612 R9127 C9125 R9128 C9172 JR904 C9171 R8602 R9174 R9184 C8617 R9185 R9175 R8623 R8621...

  • Page 46: B 715G7805 Ssb

    Circuit Diagrams and PWB Layouts TPM16.3L LA EN 46 10.3 B 715G7805 SSB 10-3-1 System Power System Power +5V Switch 3V3SB +5V_SW 4,5,6,7,8,9,10,11,12,13,14,15,16,17,18 +5VSB 90mil 12V_AMP 12V_AMP CN701 FB703 120R R738 CO-LAY +12V +12V +12V 4.7K 1/16W +5V_SW 9,10,11,12,15 +5V_SW Pre_12V Pre_12V +5VSB...
  • Page 47 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 47 10-3-2 Peripheral Peripheral U401B NAND Flash DVDD3V3 3,5,6,7,8,9,10,11,12,13,14,15,16,17,18 PDD0 OSCL0 U405 PDD0 OSCL0 PDD1 OSDA0 W29N01GVSIAA PDD1 OSDA0 PDD2 OSCL1 3V3SB PDD2 OSCL1 3,8,10,13,14,15 3V3SB PDD3 OSDA1 DVDD3V3 PDD3 OSDA1 3,5,6,8,9,10,11,13,15,16,17,18 DVDD3V3 PDD4 PDD4...
  • Page 48 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 48 10-3-3 Audio A-in/I2S/HP Audio A-in/I2S/HP C687 22PF 50V FB405 120R 3,4,6,7,8,9,10,11,12,13,14,15,16,17,18 SPDIF_OUT U401C DVDD3V3 3,4,6,8,9,10,11,13,15,16,17,18 DVDD3V3 AIN_R0 ASPDIFO AIN_L0 ARC_SPDIF Y PBPR_R_IN FB406 120R ASPDIFI AIN_R1 I2C & UART Interface Y PBPR_L_IN AIN_L1 AOMCLK R601...
  • Page 49 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 49 10-3-4 Speaker Amp Speaker Amp 3,4,5,7,8,9,10,11,12,13,14,15,16,17,18 12V_AMP DVDD3V3 PVDD PVDD AMP3V3 12V_AMP 12V_AMP FB602 3,4,5,8,9,10,11,13,15,16,17,18 DVDD3V3 DVDD3V3 FB603 120R C614 C615 50mil 120R C612 C610 C613 C611 C690 GPIO & I2C Control C617 10UF 6.
  • Page 50 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 50 10-3-5 VGA IN (V/T) 3,4,5,6,8,9,10,11,12,13,14,15,16,17,18 TP1109 R1207 12V_AMP 12V_AMP R1204 C1203 VGA_R VGA_RIN +12V 3,10 +12V NC/ 0R 05 1/ 16W NC/ 100R 1/16W 1% NC/ 10N 50V +5V_SW 3,9,10,11,12,15 +5V_SW +5VSB +5VSB 3,9,16...
  • Page 51 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 51 10-3-6 Video YPbPr/CVBS Video YPbPr/CVBS Merged Analog 3.3V Power Analog 1.2V Power 3,4,5,6,7,9,10,11,12,13,14,15,16,17,18 AVDD1V2 3V3SB 3V3SB 3V3SB 3,4,10,13,14,15 3V3SB U401D 20mil AVDD1V2 3,13,15 AVDD1V2 VGA_SCL R1301 33R 1/16W 5% 20mil 20mil 3,4,5,6,9,10,11,13,15,16,17,18 DVDD3V3 DVDD3V3...
  • Page 52 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 52 10-3-7 SPDIF/ Mute contorl SPDIF/ Mute contorl DVDD3V3 Audio Mute for SCART D602 10mil AC OFF 3,4,5,6,7,8,10,11,12,13,14,15,16,17,18 +5VSB 3,4,5,6,8,10,11,13,15,16,17,18 DVDD3V3 DVDD3V3 DVDD3V3 R657 BAS316WS 10K +-1% 1/ 16W +5VSB DC OFF 3,7,16 +5VSB 10mil...
  • Page 53 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 53 10-3-8 LVDS_Keypad_IR LVDS_Keypad_IR U401G 3,4,5,6,7,8,9,11,12,13,14,15,16,17,18 TX_AO0P AO0P TX_AO0N +12V AO0N Panel_VCC +12V DEMOD_RST TX_AO1P LVDSVDD FB401 +5V_SW TCON0 AO1P 3,9,11,12,15 +5V_SW TX_AO1N 3V3SB TCON1 AO1N 3,4,8,13,14,15 3V3SB HP_MUTE TX_AO2P DVDD3V3 TCON2 AO2P 3,4,5,6,8,9,11,13,15,16,17,18 DVDD3V3...
  • Page 54 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 54 10-3-9 TUNER TUNER 3,4,5,6,7,8,9,10,12,13,14,15,16,17,18 +5V_SW 3,9,10,12,15 +5V_SW DVDD3V3 3,4,5,6,8,9,10,13,15,16,17,18 DVDD3V3 DVDD3V3 IF Interface FAT_IN- ADCINN_DEMOD 8 FAT_IN+ Tuner on board for SA/AP ADCINP_DEMOD 8 D_IFP R159 D_IFP D_IFN 2.2K 1% D_IFN R160 2.2K 1% Control Interface...
  • Page 55 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 55 10-3-10 DDR3 DDR3 3,4,5,6,7,8,9,10,11,13,14,15,16,17,18 +5V_SW 3,9,10,11,15 +5V_SW DDRV Main Chip Ref Voltage. U401A DRAM POWER DDRV +5V_SW DDRV DDRV DDRV DDRV U411 L401 DDRV DDRV 2.2UH DDRV R456 C425 DDRV R455 NC/100N 16V 33K 1/ 16W 1% RVREF...
  • Page 56 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 56 10-3-11 HDMI/MHL HDMI/MHL 3,4,5,6,7,8,9,10,11,12,14,15,16,17,18 +5V_SW 3,9,10,11,12,15 +5V_SW 3,7,9,16 +5VSB +5VSB 3V3SB 3,4,8,10,14,15 3V3SB 3,4,5,6,8,9,10,11,15,16,17,18 DVDD3V3 DVDD3V3 AVDD1V2 3,8,15 AVDD1V2 REAR HDMI 2 (with ARC) I2C & UART Interface 100ohm differential impedance for TMDS traces.
  • Page 57 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 57 10-3-12 GPIO GPIO 3,4,5,6,7,8,9,10,11,12,13,15,16,17,18 3V3SB 3,4,8,10,13,15 3V3SB LVDS_PWR_EN LVDS_PWR_EN 10 BL_ON/OFF BL_ON/OFF USB_PWR_EN0 3V3SB USB_PWR_EN0 15 U401I SY S_EEPROM_WP SY S_EEPROM_WP 4 LED_POWER_RED OPCTRL0 LED_PWR_Blue LVDS_PWR_EN BL_DIMMING OPCTRL1 GPIO0 BL_DIMMING HTV_OPCTRL2 BL_ON/OFF LED_POWER_RED LED_POWER_RED 4,10...
  • Page 58 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 58 10-3-13 USB/ HTV USB/ HTV U401F 3,4,5,6,7,8,9,10,11,12,13,14,16,17,18 USB_DM_P0 USB_DM0 USB_DP_P0 USB_DP0 3,9,10,11,12 +5V_SW +5V_SW USB_DM1 3,4,5,6,8,9,10,11,13,16,17,18 DVDD3V3 DVDD3V3 USB_DP1 3V3SB 3,4,8,10,13,14 3V3SB 2.5 = > NORMAL AVDD1V2 3,8,13 AVDD1V2 R1114 < 2.0 = >OC +5V_SW 10K +-1% 1/16W TP410...
  • Page 59 +5VSB 1Y 0 +12V Debug mode NC BAS316 C408 NC 74H C4052PW NC 100NF 16V R493 HDMI_SCL2/RX HDMI_SCL2 For Philips: 0R05 1/16W HDMI_SDA2/TX HDMI_SDA2 R493 and R494 use 0ohm 5/31 R494 0R05 1/16W DVDD3V3 10mil DVDD3V3 R468 10K +-1% 1/16W...
  • Page 60 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 60 10-3-15 VCCK & DVSS VCCK & DVSS U401J VCC3IO 3,4,5,6,7,8,9,10,11,12,13,14,15,16,18 DVDD3V3 3,4,5,6,8,9,10,11,13,15,16,18 DVDD3V3 DVSS VCC3IO VCCK VCCK DVSS VCC3IO 3.3V IO Power DVSS VCC3IO DVSS VCCK DVSS DVDD3V3 VCC3IO DVSS DVSS VCCK DVSS VCCK...
  • Page 61 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 61 10-3-16 DEMOD_Toshiba TC90537 DEMOD_Toshiba TC90537 XT_O DVDD3V3 DVDD3V3 3,4,5,6,7,8,9,10,11,12,13,14,15,16,17 R136 XT_I 1M 1/ 10W 5% R138 close with TC90537 3,4,5,6,8,9,10,11,13,15,16,17 DVDD3V3 DVDD3V3 R111 R126 to avoid spurious. DEMOD_TSCLK NC/ 10K+-5%1/16W DEMOD_TSCLK NC/ 10K+-5%1/16W DEMOD_TSVAL DEMOD_TSVAL...
  • Page 62 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 62 10-3-17 SSB layout top CN403 R785 R483 CN408 L701 Q405 FB404 C480 R404 Q705 ZD702 FB408 C403 C401 SEN4 U403 R788 R787 C412 FB402 C707 SCREW1 R780 R778 C479 C475 SEN1 R440 C478 SW401...
  • Page 63 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 63 10-3-18 SSB layout bottom SEN10 SEN11 SEN12 SEN15 LAYOUT BOTTOM 715G7805 20010_521.eps back to 2016-Mar-18 div.table...

  • Page 64: J 715G8009 Ir/Led Panel

    Circuit Diagrams and PWB Layouts TPM16.3L LA EN 64 10.4 J 715G8009 IR/LED Panel 10-4-1 IR & LED & Light Sensor IR & LED & Light Sensor Light Sensor St andby LED 3V3SB CN201 LED_R DVD3V3 DVD3V3 C222 NC/ 1uF 10V RC-IR R224 R223...
  • Page 65 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 65 10-4-2 IR/LED board layout Layout IR/LED panel (top side) CN201 U201 Q201 Layout IR/LED panel (bottom side) R224 R223 LED201 2015-08-27 IR/LED panel 715G8009 layout top/bottom 20010_523.eps back to 2016-Mar-18 div.table...

  • Page 66: E 715G7088 Keyboard Control Panel

    Circuit Diagrams and PWB Layouts TPM16.3L LA EN 66 10.5 E 715G7088 Keyboard control panel 10-5-1 JOYSTICK Direction switch Key functionResistance Voltage Center 2-5 short Menu Right 1-5 short 0.5V CN01 KEY 1 Left 4-5 short 0.81V Down 3-5 short VOL- 1.65V CONN...
  • Page 67 Circuit Diagrams and PWB Layouts TPM16.3L LA EN 67 10-5-2 Key board layout Layout Keyboard control panel (top side) SW01 Layout Keyboard control panel (bottom side) 2014-06-06 Keyboard control panel 715G7088 layout top/bottom 19850_525.eps back to 2016-Mar-18 div.table...
  • Page 68 Styling Sheets TPM16.3L LA EN 68 11. Styling Sheets 11.1 5101 series 32" 5101 series 32" 1053 1184 0040 1184 1054 1057 0095 1056 Remarks Pos No. Description 0030 Bez 0040 Re ar cover 1050 0050L Stand Assy_L 0050R 0050R Stand Assy_R 0095 V0 SHEET...

  • Page 69: 5101 Series 43
