Summary of Contents for PowerPoint P06C2MDBL
- Page 1 Powerpoint Fr eestanding oven MODEL：P06C2MDBL Instructions for installation and use. Photos are only for reference, there might be di erence between models.
- Page 3 CONTENTS SAFETY WARNING INSTALLATION Unpacking Installation steps Leveling Your Appliance Electrical connection Connecting the power cable For equipment with a cooling fan Final check PRECAUTIONS BEFORE USE PRODUCT INTRODUCT Product components control panel ACCESSORIES POINTS FOR ATTENTION IN USE Instructions for the oven Tips for baking FUNCTION IS INTRODCED How to operate the top oven...
- Page 4 SAFETY WARNING Thank you for choosing us! Please read all instructions before using this appliance. This book contains valuable information about operation, care and service. Keep it in a safe place for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with appliance in order that new owner can be acquaint- ed with the functioning of the appliance and relevant warnings.
- Page 5 The user must not replace the supply cable of this appliance. Always call an after-sales servi ing centre authorized by Powerpoint in the case of cable damage or replacement. Always switch o the electrical supply to the cooker and allow it to cool down before carrying out any cleaning operations etc.
- Page 6 This appliance must be used for the purpose for which it was expressly designed. Any other use is considered to be improper and consequently dangerous. The manufacturer declines all responsibility for damage resulting from improper and irre- sponsible use. A number of fundamental rules must be followed when using instructions.
- Page 7 When the appliance is in use, the heating elements and some parts of the oven door become extremely hot. Make sure you don't touch them and keep children well away. If you use the power code for single phase, the minimum cross-sectional area is 4mm 2 .
- Page 8 WARNING:Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as use of inappropriate guards can cause accidents. Suitable or hob guards incorporat- ed in the appliance. The use of inappropriate guards can cause accidents.
- Page 9 INSTALLATION The following instructions should be read by a qualified technician to ensure that the appliance is installed, regulated and technically serviced correctly in compliance with current regulations. Important: remember to disconnect the appliance from electricity by turn o the mains before regulating the appliance or carrying out any maintenance work.
- Page 10 The cooker may be located in a kitchen, a diner or bed sitting room, but not in a bathroom or shower room. Kitchen cabinets installed next to the cooker that are taller than the top of the cooker hobs must be situated at least 20cm from the edge of the hobs. Hoods must be installed according to the requirements in the installation manual for the hoods themselves and in any case at a minimum distance of 65cm.
- Page 11 Electrical connection Connect the product to a grounded outlet/line protected by a fuse of suitable capacity as stated in the “Technical specifications” table. Have the grounding installation made by a qualified electrician while using the product with or without a transformer. Our company shall not be liable for any damages that will arise due to using the product without a If in any doubt please visit grounding installation in accordance with the local regulations.
- Page 12 IMPORTANT: Additional protection by a residual current circuit breaker is recommended. Install an approved circuit breaker with a minimum contact opening of 3 mm, between the appliance and the mains fuse box .（the earth wire should not be interrupted by the circuit breaker）...
- Page 13 PRECAUTIONS BEFORE USE When properly used your appliance is completely safe but as with any electrical product there are certain precautions that must be observed. Please read the precautions below before using your appliance. Turn controls OFF when you have finished cooking and when not in use.
- Page 14 Never leave children unsupervised where a cooking appliance is installed as all surfaces will be hot during and after its use. Do not allow children or persons who are not familiar with the appliance to use it, without supervision. Do not allow anyone to sit or stand on any part of the appli- ance.
- Page 15 Safety reminding: Caution, possibility of tilting Anti-tip restraints WARNING: In order to prevent tipping of the appliance, this stabilising means must be installed. Refer to instructions for installation.
- Page 16 PRODUCT INTRODUCTION Product components (Please select the icon according to the configuration) A: Cooktop B. Control Panel C. Oven Door Handle D. Oven Door E. Adjustable Feet control panel (Please select the icon according to the configuration) 1. Hob control knob 2.
- Page 17 ACCESSORIES Your appliance is accompanied by a range of accessories. Here, you can find an overview of the accessories included and information on how to use them correctly. Accessories included Your appliance is equipped with the following accessories: Wire Rack Baking Tray For ovenware, cake tins and ovenproof For tray bakes and small baked products.
- Page 18 POINTS FOR ATTENTION IN USE Instructions for the oven When you're done, wear heat-proof gloves and remove food and accessories. If food is cooking too fast, place it at the bottom of the baking pan. Do not place cookware with rough bases on the oven door. Ensure that there is at least 25mm space at top of oven when grilling larger foods or using tall cookware.
- Page 19 FUNCTION IS INTRODCED How to operate the top oven Turning on the oven Oven is operated with Function knob. Oven is turned o when the Function knob is in O (upper) position. 1. Close the oven door. 2. Set the oven temperature. ★Temperature light will turn o when the set temperature is attained.
- Page 20 oven(Only for model: 24EME4R106-1EDT0023） WARNING: This product is designed for OPEN DOOR GRILLlNG. WARNING: Hot surfaces may cause burns! Keep children away from the product. Oven door remains slightly inclined when opened full and thus，possible splashes to not reach you. There is no switch on the door.
- Page 21 How to operate the main oven IMPORTANT: Before you can use the main oven, the time must be set. If the time is not set, oven will not be operate. ( For models with the timer.) Product is equipped with two ovens. Overview section indicates the relevant knobs for each oven.
- Page 22 Display screen use For the cooker with 2 hour mechanical timer, you can use it to set it to set cooking time from 1-120minutes. To use the timer, the buzzer must be wound up by turning the knob one full turn clockwise; then turn it back to the desired time so that the number of minutes on the knob matches the reference mark on the panel.
- Page 23 End of cooking When the cooking is over, the oven will turn o automatically, the buzzer will emit a sound and the display screen will show the current time. Clock settings The programmer can also be used as an ordinary timer. Press the key and the display will show the figures 000 ;...
- Page 24 Hob introduce A/C: Single cycle cooking plate Size: 165mm Power: 1200W B/D: Single cycle cooking plate Size: 200mm Power: 1800W Hob knob Fire size boiling stewing simmering warming Location of cooking area Lowest setting (Keep food warm) Highest setting (quick heating up quick cooking, roasting) When cooking is complete, turn the knob back to the o position.
- Page 25 On the hob anywhere Glass ceramic surface is heatproof and is not a ected by big temperature di erences. Do not use the glass ceramic surface as a place of storage or as a cutting board. Use only the saucepans and pans with machined bottoms. Sharp edges create scratches on the surface.
- Page 26 CLEAN AND MAINTENANCE Before each operation, disconnect the cooker from the electricity. To assure the long life of the cooker, it shall be thoroughly cleaned frequently, keeping in mind that: Wait until the oven has cooled before removing the wire shelves, wash them separately in warm soapy water and dry thoroughly.
- Page 27 Removing the door for easier cleaning We recommend you have someone to assist you during removal of the door. To remove the door, open the door to the maximum angle.Then pull the buckle at the door hinge backward. Close the door to an angle approximately 30°. Hold the door with one hand on each side. Lift up and slowly pull the door out from the oven.
- Page 28 Oven Lamp Replacement Switch o and disconnect the power from the oven. Ensure that the internal parts are cool before touching internal parts. Remove the lamp cover by turning it counter-clockwise (note, it may be sti ), replace the bulb with a new one of the same type. Insert the new bulb, which should be resistant to 300oC.
- Page 29 TECHNICAL SPECIFICATIONS Model 24EME4R106-1EDX0023 24EME4R106-1EDT0023 Double Oven Twin Oven GENERAL External dimensions(height/width/depth) 900/600/600mm 900/600/600mm Voltage frequency 220-240V~ 50Hz 220-240V~ 50Hz Top power consumption 10.0 kW 9.1 kW Fuse min.32A min.32A When the user owns wiring, it When the user owns wiring, it Cable type / section can be equipped with H07RN-F can be equipped with H07RN-F...
- Page 30 TROUBLE SHOOTING Trouble shooting Before contacting the authorized service center in case of problems while using your cooker, check the problem quite below; there may be nothing wrong with your cooker. Problem Slight odour or small amount of smoke This is normal and should cease after a when using the cooker for the first time short period.
- Page 31 REFERS TO RATING LABEL This symbol on the product or in the instruction means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste. There are separate collection systems for recycling in the EU.For more information,please contact the local authority or your retailer where you purchased the product.
