YAMEE XL
User Manual
www.yameebike.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the XL and is the answer not in the manual?

Questions and answers

Related Manuals for YAMEE XL

Summary of Contents for YAMEE XL

  • Page 1 YAMEE XL User Manual www.yameebike.com...
  • Page 3 CONTENTS Part 1 Unboxing ..............Part 2 Display Instruction ............. Part 3 Common Problems & Solutions ........18 Part 4 Use and Maintenance ..........Part 5 After Sales and Warranty ..........
  • Page 4 Part 1 Unboxing The Yamee ebike comes with 95% assembled . *Display needs to be installed by the owner to avoid potential damaged during shipping. Only three steps to unfold: (1) Frame Unfolding Push the clamp to lock the frame solidly and make sure it is tight.
  • Page 5 (2) Handlebar 1.Turn the hinge upward until the handlebar is fixed. 2. Push and lock the clasp. 3. Make sure the clasp is locked.
  • Page 6 (3) Pedal Unfold Rotate the pedal up until the pedal is fully engaged. Fold Push pedal from the front, then rotate it downward.
  • Page 7 (4) Battery Removal and Charging When the charger light turns red, it means the battery is being charged; When the light turns green, it means the battery is fully charged. Location of the key hole: The key hole is at the bottom of the frame. Two ways to charge: Remove the battery and charge.
  • Page 8 (5) Transmission System 1. This function can only be adjusted while pedaling. 2. Depress this lever to shift to a higher gear. 3. Depress this lever to shift to a lower gear.
  • Page 9 Part 2 Display Instruction 1. Display Interface Speed Value Battery Indicator Light Motor Power Mileage PAS Level...
  • Page 10 (1) Press the “i” button to display different information. 1. Miles traveled 2. Total miles traveled 3. Maximum speed 4. Average speed 5. Total traveled time...
  • Page 11 (2) Driving Mode Switching. 1. Eco Mode Activates at a slow speeds providing low acceleration ( Low energy consumption). 2. Normal Mode Activates at a normal speeds providing normal acceleration ( Normal energy consumption). 3. Sport Mode Activates at a high speeds providing high acceleration ( Higher energy consumption).
  • Page 12 (3) Switching Walk-assistance Mode On/Off 1. Walk-assistance function may only be used when you walking the E-bike. 2. To activate the walk-assistance function, press the “-” button for 2s. 3. The walk-assistance function will be switched off as soon as you release the button.
  • Page 13 (2) Key-Disp App Guide 1. Download Download from apple store/google store by key words “Key-Disp”. App logo is as follow:...
  • Page 14 2. Sign Up & Log In Fill in the required information according to pictures below to sign up and log in. 3. App Connection App must connect with the ebike system to realize all its functions. When display is on, Add Device > Add > “+” Button > Done...
  • Page 15 4. App Operation & Indication Info Bluetooth connection icon, battery power, speed, trip distance, riding time and ODO. The app can be operated to control the headlight status of the whole bike and switch the assist levels on the display.
  • Page 16 5. Fast operations: unit set (metric vs imperial), speed limit set, wheel size set Remarks: if display complies with new EN standard, wheel size and speed limit are not settable on either display side or app side.
  • Page 17 6. Map Navigation, Ebike Check-Up 7. Riding Record If single trip distance is > 0.1km, the riding record will be saved.
  • Page 18 8. Help & Guide Click the icon to view FAQ and feedback. 9. Bluetooth Connection & Disconnection After the first time of connection, Bluetooth it will automatically connect to the app when you turn it on. *Note: mobile network must be connected for Bluetooth connection.
  • Page 19 *Solution for: app unable to search Bluetooth device When the device is powered on, press and hold the "i" and "-” for 2s at the same time, or make the display reset to factory settings. (3) Password Setting 1. This setting means power-on password setting when you turn on the display.
  • Page 20 (4) Cruise Control（CRU） 1. Cruise Control is to ride your bike at a constant speed. 2. Press the throttle at a constant speed you want for 5s. The bike will then maintain this speed at constant speed after releasing the throttle, which can help minimize the energy consumption of the motor.
  • Page 21 Part 3 Common Issues & Solutions The battery cannot be charged, the display shows an abnormal battery power. Use a multimeter to check if the battery still has voltage. Check if the charger indicator is normal (Red light means charging, green light means fully charged).
  • Page 22 When an error code appears on the display. Error Code Definition Current Abnormality Throttle Abnormality Motor Abnormality Motor Hall Signal Abnormality Brake Abnormality Communication Abnormality Error code 21 and 30 indicate controller issue.  Error code 25 indicates brake problem. Do following steps to confirm ...
  • Page 23 The bike can be disassembled and refitted. But our warranty will not cover any bike problems after the refit. Can I do some upgrades on the bike? We provide upgrade service for some accessories. Contact Yamee for more details. I need to return the bike, what should I do? We only accept returns with original package.
  • Page 24 Part 4 Use and Maintenance *Operating Safety 1. This E-bike will power off when braking. It ensures safety of riding. 2. Do not carry people on the rear seat. The weight limit of the rear seat is 30kg. 3. Do not ride exceed the speed limit set by the local traffic laws. 4.
  • Page 25 2. Check the brake disc regularly to prevent deform. If it is a hydraulic brake, check regularly to see if there is any oil leakage. 3. Clean the brake regularly. *Motor Maintenance Do not try to disassemble the motor. If there are any problems with the motor, contact Yamee with a video.
  • Page 26 *Tire Maintenance 1. Check regularly to prevent air leak. 2. Check spokes regularly. *Derailleur Maintenance 1. Check the rear derailleur regularly to see if it changed to every gear (contact us for the video about how to adjust the shifter). 2.
  • Page 27 Part 5 After Sales and Warranty *After sales Thanks for choosing Yamee bike as your green travel solution. Let’s ride together to keep our earth and home green. If you have any question about our products, or would like to get the...
  • Page 28 1. If there is something wrong with my electric bike, who I should go for help? Yamee: Take a video or some pictures, bring the order detail information of the bicycle, and then email info@yameebike.com 2. Can I modify the electric bike? Yamee: Yes, you can.
  • Page 29 5. If I lost the key, can I get one more from Yamee? Yamee: No, we do not have any copy of key for each of bike, that`s why we shipped with two keys, please take good care of the keys, if you...
  • Page 30 During the service ordering process, you must notify us of any unauthorized modifications, or any repairs or replacements not performed by Yamee, that have been made to your product. We will not be responsible for any damage to the product that occurs during the repair process that is a result of any unauthorized modifications, repairs or replacements not performed by YAMEE.
  • Page 31 3. The product has been in any accidents, such as traffic accidents. 4. The product has been in extreme environment (including extreme temperature or humidity), extreme physical or electrical stress or interference, fluctuation or surges of electrical power, lightning, static electricity, fire, acts of God or other external causes.
  • Page 32 Yamee Customer Support...
