Open Field Network
CC-Link Compatible Product Development
Reference Manual
CC-Link Remote I/O Station Communication LSI MFP2N
-A6GA-CCMFP2NN60FN
-A6GA-CCMFP2NN300FN

Advertisement

loading
Need help?

Need help?

Do you have a question about the MFP2N and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric MFP2N

Summary of Contents for Mitsubishi Electric MFP2N

  • Page 1 Open Field Network CC-Link Compatible Product Development Reference Manual CC-Link Remote I/O Station Communication LSI MFP2N -A6GA-CCMFP2NN60FN -A6GA-CCMFP2NN300FN...
  • Page 2 ・When disposing of a product that uses this product, treat it as industrial waste. ・The prior written approval of Mitsubishi is necessary to reprint or reproduce this manual in whole or in part. ・If you have any questions or concerns regarding the details described in this manual, consult your local Mitsubishi Electric representative.
  • Page 3 Conditions of Use for the Product Mitsubishi dedicated LSI ("the PRODUCT") shall be used in conditions; i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident; ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.
  • Page 4 10.1 Recommended Infrared Reflow Soldering Conditions (Including Hot Air Reflow and Infrared + Hot Air Reflow) .... 32 10.2 Precautions When Opening the Package ................................33 APPENDICES ..............................................34 Appendix 1 MFP2N Previous Specifications ................................34 Appendix 1.1 External appearance (before March 2020) ..........................34 Appendix 1.2 External appearance (before July 2014) ............................35 Appendix 2 Differences between PC03002N and PC18005E ..........................
  • Page 5 Revisions ................................................. 42 Warranty ................................................. 43 Trademarks ..............................................43...
  • Page 6 The intellectual property rights of the information provided in this manual belong to Mitsubishi Electric. Reprinting the information without the consent of Mitsubishi Electric and reproduction of the information for any purpose other than the development of a remote I/O station for CC-Link is prohibited.
  • Page 7 CC-Link Partner Association (1) Specifications The materials related to this manual include the specifications published by the CC-Link Partner Association below. For CC-Link details, download and refer to the following specifications from the CC-Link Partner Association website. Document title Document No. CC-Link Specification (Overview/Protocol) BAP-C2001ENG-001 CC-Link Specification (Implementation)
  • Page 8 LSI (MFP2N)" provided by Mitsubishi Electric. 1.1 Development Features The remote I/O station to be developed comprises CC-Link remote I/O station communication LSI (MFP2N) and a CC-Link communication circuit that incorporates peripheral circuits, as shown in the general block diagram below.
  • Page 9 Function Description Number of I/O points, Sets the number of I/O points and I/O type for MFP2N. I/O type setting Note that the same device numbers cannot be set for the input and output of the I/O combined type. 8-bit input, 8-bit output,...
  • Page 10 3. MFP2N SPECIFICATIONS 3.1 External Appearance The following is the external appearance of MFP2N as of April 2020. For the previous external appearance, refer to Appendix Unit: mm 16.00±0.40 14.00±0.10 51PIN 75PIN 76PIN 50PIN MFP2N PC18005E LOT NUMBER 100PIN 26PIN...
  • Page 11 3.2 Pin List Pin No. Pin name Pin No. Pin name Pin No. Pin name Pin No. Pin name IO_04 IO_19 FUSEL IO_05 IO_1A RSV53 IO_06 IO_1B RSV54 RSV79 IO_07 IO_1C RSV55 IO_08 IO_1D RSV56 SDGATEON IO_09 IO_1E LEDX0 IO_0A IO_1F RSV58 LEDX1...
  • Page 12 3.3 Pin Functions 3.3.1 Lists of pin functions Clock reset Pin No. Pin name Buffer type Application Remarks IBT_SP1 Clock input Input the crystal oscillator output (80 MHz). Reset range = All I/O buffer bits, transmission section, IBHP3_SP1 Reset input switch setting section, HDLC section Active "H"...
  • Page 13 Bit data I/O interface Pin No. Buffer type Application Processing when Output level after reset Remarks name not in use IO_00 BH3BT_SP1 Bit data I/O 0 IO_01 BH3BT_SP1 Bit data I/O 1 IO_02 BH3BT_SP1 Bit data I/O 2 IO_03 BH3BT_SP1 Bit data I/O 3 IO_04 BH3BT_SP1...
  • Page 14 (SDNRZ) OPEN For monitoring (Frequency SCLK OB1T Send clock determined by the baud rate) *1: A monitor pin for measuring delay of MFP2N external process I/O circuits *2: For the code details, refer to Chapter 9 "MONITOR PINS".
  • Page 15 Design the circuit (pattern and pad) so that the components shown in the figure below can be implemented to the pin number 70 "RSV70" and pin number 71 "RSV71" external. Resistors: 1/10 W or more, 10 kΩ Capacitors: 50 V or higher, 470 pF MFP2N 10 kΩ (Reserved) RSV70...
  • Page 16 3.3.4 Ratings for the input buffer type (T = -40 to +110°C, V = 5 V±10％) The sign indicates the polarity, and the direction of the current flowing into the pin is indicated by the positive sign. IBC_SP1 Item Condition Min.
  • Page 17 IBCP3_SP1 Item Condition Min. Typ. Max. Unit CMOS Level 1.65 CMOS Level + 0.3 Pull-up resistance 5 kΩ 12.9 kΩ = GND input leak current 0.348 1.00 3.3.5 Ratings for the output buffer type (T = -40 to +110°C, V = 5 V±10％) The sign indicates the polarity, and the direction of the current flowing into the pin is indicated by the positive sign.
  • Page 18 3.3.6 Ratings for the I/O buffer type (T = -40 to +110°C, V = 5 V±10％) The sign indicates the polarity, and the direction of the current flowing into the pin is indicated by the positive sign. BH3BT_SP1 Item Condition Min.
  • Page 19 3.4 Block Diagram To the LED circuit FUSEL SDNRZ Send data shift Switching NRZI Status shift register circuit modulation register (counter) generation circuit circuit To the LED Zero Flag shift circuit insertion register circuit From the Baud rate address/status setting division IO_00 B.RATE latch section...
  • Page 20 3.5 Electrical Characteristics 3.5.1 Absolute maximum ratings (Unless specified T = 25°C) Symbol Item Condition Rated value Unit Power supply voltage - 0.5 to +7.0 I/O voltage - 0.5 to V + 0.5 Output current = 3 mA type buffer ±30 = 6 mA type buffer ±30...
  • Page 21 3.5.3 DC characteristics (T = -40 to +110°C, V = 5 V±10%) Symbol Item Condition Specification value Unit Min. Typ. Max. Static supply current or GND µA Off-state output current or GND ±5 µA Input leak current or GND (Normal input) ±5 µA = GND (Pull-up 50 kΩ)
  • Page 22 4. RESET TIMING Symbol Item Condition Specification value Unit Min. Typ. Max. Reset pulse width Clock normal Design the reset signal (RST) so that it satisfies the timing below. 4.5 V Power supply voltage Reset After reset [Restrictions] The reset signal (RST) must be held at "H" for 3.3 ms or longer after the power supply voltage reaches 4.5 V or higher.
  • Page 23 5. REMOTE I/O STATION CIRCUIT DIAGRAM EXAMPLES This chapter provides remote I/O station circuit diagram examples. For measures to reduce noise, read the precautions described in Section 5.2 "CC-Link Communication Circuit Examples".
  • Page 24 5.1 Remote I/O Station Circuit Examples The following is a circuit example of the input 32-point type. To improve the noise immunity, isolate the CC-Link communication circuit. (Recommended) For details on the CC-Link communication circuit, refer to Section 5.2 "CC-Link Communication Circuit Examples". *1: For the CC-link communication circuit, refer to Section 5.2 "CC-Link Communication Circuit Examples".
  • Page 25 The following diagrams are the examples of the isolated CC-Link communication circuits. When a digital isolator is used RS485 tra nsceiver Digital isolat or Damping resistor 10 kΩ 10 kΩ VCC2 VCC1 Filter OUTA MFP2N OUTB 1 pin MFP2N 3300 pF 0.1 μF 50 V 8 pin GND2 GND1 11 pin 12 pin 0.1 μF...
  • Page 26 5.3 Precautions for Printed Circuit Board Design (5) Precautions for remote I/O station circuit (a) Make the traces between the crystal oscillator and MFP2N as short as possible so that a damping resistor can be surface mounted. (b) Keep as much distance between the crystal oscillator trace and other signal traces.
  • Page 27 For the model, manufacturer, and specifications of each component, refer to the CC-Link Specification (Implementation). 6.3 MFP2N MFP2N can be purchased from your Mitsubishi Electric dealer network. For prices, please ask your dealer. MFP2N is the lead- free/RoHS Directive compliant product.
  • Page 28 The bit data of LED can be turned on only for the number of points set by IOP0 and IOP1. I/O assignment The following are the data areas to be used by MFP2N within the data area (RX/RY: 32 bits) of one station. I/O type...
  • Page 29 7.2 Station Number and Baud Rate Settings The station number and baud rate settings are set at active "L". The settings are latched after reset (at the falling edge of RST). Station number setting value 1 to 64: Station number (normal) 0, 65 or higher: A station number switch setting error occurs.
  • Page 30 8. LED ON/OFF CONDITIONS POWER: Turns on when the internal 5 V is normal. L RUN: Turns on while the refresh data is being received normally, and turns off when data refresh is not performed for a certain period of time. (Y outputs are turned off at the same time.) L ERR.: Turns on when the data addressed to the own station has a CRC error or when an abort error occurs.
  • Page 31 I/O status LEDs MFP2N outputs the I/O status for the number of I/O points (32 points maximum) to the LEDs using the dynamic scanning method. LEDX0 LEDX1 LEDX2 LEDX3 LEDX4 LEDY0 "PW" LEDY1 "L RUN" LEDY2 "SD" LEDY3 "RD" LEDY4 "L ERR."...
  • Page 32 ・ SDNRZ : For send data before modulation ・ RDNRZ : For receive data after demodulation ・ IDT : For bit data I/O circuit (MFP2N external) delay ・ SCLK : For transmission clock (= frequency based on the baud rate setting) ・...
  • Page 33 10. HANDLING PRECAUTIONS 10.1 Recommended Infrared Reflow Soldering Conditions (Including Hot Air Reflow and Infrared + Hot Air Reflow) The following shows the recommended infrared reflow soldering conditions (for the moisture absorption control product). Opening of the aluminum moisture-resistant packaging Baking Storage period: Within 7 days (125°C±5°C, 20 to 36 hours)
  • Page 34 10.2 Precautions When Opening the Package Open the package immediately before soldering. Use the product within the moisture-resistant packaging storage period (within 12 months after sealing). This product requires moisture control. After opening, store the product in a moisture-proof environment (temperature: 30°C or lower, humidity: 70% RH or less), and mount the product within 7 days.
  • Page 35 APPENDICES Appendix 1 MFP2N Previous Specifications Appendix 1.1 External appearance (before March 2020) The following is the external appearance of MFP2N before March 2020. Unit: mm 16.00±0.20 14.00±0.20 MFP2N PC03002N LOT NUMBER Lead-free/RoHS Directive compliant identification mark (dot) 1.00 1.00 0.08...
  • Page 36 Appendix 1.2 External appearance (before July 2014) The following is the external appearance of MFP2N before July 2014. Unit: mm 16.00 ±0.20 14.00 ±0.20 Lead-free/RoHS Directive compliant identification mark (dot) MFP 2 N PC03002N LOT NUMBER 1.00 1.00 0.08 0.50 ＋0.05...
  • Page 37 Refer to this section when considering replacement. Appendix 2.1 Model names Item Discontinued model Alternative model Product PC03002N PC18005E Model (package unit: 60 pieces) A6GA-CCMFP2NN60F A6GA-CCMFP2NN60FN Model (package unit: 300 pieces) A6GA-CCMFP2NN300F A6GA-CCMFP2NN300FN Manufacturer Mitsubishi Electric Corporation Mitsubishi Electric Corporation...
  • Page 38 Appendix 2.2 External appearance Appendix 2.2.1 Package dimensions 51PIN 75PIN 50PIN 76PIN 26PIN 100PIN 1PIN 25PIN Ｃ θ Detailed package dimensions [Unit: mm unless otherwise specified] PC03002N PC18005E Symbol Min. Nom. Max. Min. Nom. Max. 13.8 14.0 14.2 13.9 14.0 14.1 13.8 14.0...
  • Page 39 Appendix 2.2.2 Print position specifications For the print position of PC18005E, refer to Section 3.1 "External Appearance". For the print position of PC03002N, refer to Appendix 1.1 "External appearance". Appendix 2.3 Electrical characteristics Appendix 2.3.1 Buffer types Buffer type PC03002N PC18005E Input Buffer (CMOS Level in) FI01...
  • Page 40 Appendix 2.3.4 DC characteristics PC03002N PC18005E Item Rated value Rated value Unit Symbol Symbol Min. Typ. Max. Min. Typ. Max. CMOS 0.7V + 0.3 V "H" input voltage 2.29 2.29 CMOS 0.3 V 1.65 "L" input voltage 0.77 0.77 Positive trigger CMOS 2.85 3.75...
  • Page 41 Appendix 2.3.5 AC characteristics PC03002N PC18005E Item Condition Rated value Rated value Unit Symbol Symbol Min. Typ. Max. Min. Typ. Max. Output rising time 1.23 = 15 pF Output falling time 1.62 Appendix 2.3.6 I/O capacitance PC03002N PC18005E Item Condition Rated value Rated value Unit...
  • Page 42 Appendix 2.5 Handling precautions Appendix 2.5.1 Recommended conditions Item PC03002N PC18005E After package opening Within 7 days Within 7 days Baking 125°C, 10 to 72 hours 125°C, 20 to 36 hours Maximum temperature (package surface 260°C or lower 260°C or lower temperature) Preheating time 160 to 180°C, 60 to 120 s...
  • Page 43 Security Precautions, Conditions of Use for the Product, Sections 1.1, 5.1, 5.2, 6.2 This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents in this manual.
  • Page 44 Warranty Please confirm the following product warranty details before using dedicated LSI. Gratis Warranty Term and Gratis Warranty Range If any faults or defects (hereinafter "Failure") found to be the responsibility of Mitsubishi occurs during use of the product within the gratis warranty term, the product shall be replaced at no cost via the sales representative or Mitsubishi Service Company.
  • Page 45 SH(NA)-080622ENG-K(2402)MEE MODEL: CC-LINK-MFP2N-R-E MODEL CODE: 13JV13 HEAD OFFICE: TOKYO BLDG., 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN NAGOYA WORKS: 1-14, YADA-MINAMI 5-CHOME, HIGASHI-KU, NAGOYA 461-8670, JAPAN When exported from Japan, this manual does not require application to the Ministry of Economy, Trade and Industry for service transaction permission.
