Open Field Network
CC-Link Compatible Product Development
Reference Manual
CC-Link Remote I/O Station Communication LSI MFP2AN
-A6GA-CCMFP2ANN60FN
-A6GA-CCMFP2ANN300FN

Advertisement

loading
Need help?

Need help?

Do you have a question about the MFP2AN and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric MFP2AN

Summary of Contents for Mitsubishi Electric MFP2AN

  • Page 1 Open Field Network CC-Link Compatible Product Development Reference Manual CC-Link Remote I/O Station Communication LSI MFP2AN -A6GA-CCMFP2ANN60FN -A6GA-CCMFP2ANN300FN...
  • Page 2 ・When disposing of a product that uses this product, treat it as industrial waste. ・The prior written approval of Mitsubishi is necessary to reprint or reproduce this manual in whole or in part. ・If you have any questions or concerns regarding the details described in this manual, consult your local Mitsubishi Electric representative.
  • Page 3 Conditions of Use for the Product Mitsubishi dedicated LSI ("the PRODUCT") shall be used in conditions; i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident; ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.
  • Page 4 10.1 Recommended Infrared Reflow Soldering Conditions (Including Hot Air Reflow and Infrared + Hot Air Reflow) .... 31 10.2 Precautions When Opening the Package ................................32 APPENDICES ..............................................33 Appendix 1 MFP2AN Previous Specifications ................................33 Appendix 1.1 External appearance (before March 2020) ..........................33 Appendix 1.2 External appearance (before September 2014) ........................34 Appendix 2 Differences between PC97007N and PC18006E ..........................
  • Page 5 Warranty ................................................. 42 Trademarks ..............................................42...
  • Page 6 The intellectual property rights of the information provided in this manual belong to Mitsubishi Electric. Reprinting the information without the consent of Mitsubishi Electric and reproduction of the information for any purpose other than the development of a remote I/O station for CC-Link is prohibited.
  • Page 7 CC-Link Partner Association (1) Specifications The materials related to this manual include the specifications published by the CC-Link Partner Association below. For CC-Link details, download and refer to the following specifications from the CC-Link Partner Association website. Document title Document No. CC-Link Specification (Overview/Protocol) BAP-C2001ENG-001 CC-Link Specification (Implementation)
  • Page 8 LSI (MFP2AN)" provided by Mitsubishi Electric. 1.1 Development Features The remote I/O station to be developed comprises CC-Link remote I/O station communication LSI (MFP2AN) and a CC-Link communication circuit that incorporates peripheral circuits, as shown in the general block diagram below.
  • Page 9 Function Description Number of I/O points, Sets the number of I/O points and I/O type for MFP2AN. I/O type setting Note that the same device numbers cannot be set for the input and output of the I/O combined type. 8-bit input, 8-bit output,...
  • Page 10 3. MFP2AN SPECIFICATIONS 3.1 External Appearance The following is the external appearance of MFP2N as of April 2020. For the previous external appearance, refer to Appendix Unit: mm 14.00±0.40 12.00±0.10 60PIN 41PIN 61PIN 40PIN MFP2AN PC18006E LOT NUMBER 80PIN 21PIN...
  • Page 11 3.2 Pins Pin No. Pin name Pin No. Pin name Pin No. Pin name Pin No. Pin name RSV02 IO_00 LEDY7 RSV03 IO_01 LEDY6 IOS0 IO_02 LEDY5 IOS1 IO_03 LEDY4 IO_04 SW10 RSV07 IO_05 SW20 RSV08 IO_06 LEDY3 SW40 RSV09 IO_07 LEDY2 RSV69...
  • Page 12 3.3 Pin Functions 3.3.1 Lists of pin functions Clock reset Pin No. Pin name Buffer type Application Remarks IBT_SP1 Clock input Input the crystal oscillator output (80 MHz). Reset range = All I/O buffer bits, transmission section, IBHP3_SP2 Reset input switch setting section, HDLC section Active "H"...
  • Page 13 OPEN (SDNRZ) For monitoring (Frequency SCLK OB1T_SP2 Send clock determined by the baud rate) *1: A monitor pin for measuring delay of MFP2AN external process I/O circuits *2: For the code details, refer to Chapter 9 "MONITOR PINS".
  • Page 14 Design the circuit (pattern and pad) so that the components shown in the figure below can be implemented to the pin number 77 "RSV77" and pin number 78 "RSV78" external. Resistors: 1/10 W or more, 10 kΩ Capacitors: 50 V or higher, 470 pF MFP2AN 10 kΩ (Reserved) RSV77...
  • Page 15 3.3.4 Ratings for the input buffer type (T = -40 to +110°C, V = 5 V±10%) The sign indicates the polarity, and the direction of the current flowing into the pin is indicated by the positive sign. IBH_SP1 Item Condition Min.
  • Page 16 IBS_SP1 Item Condition Min. Typ. Max. Unit TTL Level (Schmitt) 0.77 TTL Level (Schmitt) 2.29 kΩ or GND (normal input) input leak current ±5 µA 1.38 2.55 0.64 1.33 0.64 3.3.5 Ratings for the output buffer type (T = -40 to +110°C, V = 5 V±10%) The sign indicates the polarity, and the direction of the current flowing into the pin is indicated by the positive sign.
  • Page 17 3.3.6 Ratings for the I/O buffer type (T = -40 to +110°C, V = 5 V±10%) The sign indicates the polarity, and the direction of the current flowing into the pin is indicated by the positive sign. BH4BT_SP2 Item Condition Min.
  • Page 18 3.4 Block Diagram To the LED circuit FUSEL SDNRZ Send data shift Switching NRZI Status shift register circuit modulation register (counter) circuit generation circuit To the Zero Flag shift insertion register circuit circuit From the Baud rat e address/status IO_0 setting B.RATE latch section...
  • Page 19 3.5 Electrical Characteristics 3.5.1 Absolute maximum ratings (Unless specified T = 25°C) Symbol Item Condition Rated value Unit Power supply voltage - 0.5 to +7.0 I/O voltage - 0.5 to +7.0 Output current = 4 mA type ±30 = 8 mA type ±30 = 12 mA type ±30...
  • Page 20 3.5.3 DC characteristics (T = -40 to +110°C, V = 5 V±10%) Specification value Symbol Item Condition Unit Min. Typ. Max. Off-state output current or GND ±5 µA or GND (Normal input) ±5 µA ＝ GND (Pull-up 50 kΩ) Input leak current 131.6 366.7 µA...
  • Page 21 4. RESET TIMING Symbol Item Condition Specification value Unit Min. Typ. Max. Reset pulse width Clock normal Design the reset signal (RST) so that it satisfies the timing below. 4.5 V Power supply voltage Reset After reset [Restrictions] The reset signal (RST) must be held at "H" for 3.3 ms or longer after the power supply voltage reaches 4.5 V or higher.
  • Page 22 5. REMOTE I/O STATION CIRCUIT DIAGRAM EXAMPLES This chapter provides remote I/O station circuit diagram examples. For measures to reduce noise, read the precautions described in Section 5.2 "CC-Link Communication Circuit Examples".
  • Page 23 5.1 Remote I/O Station Circuit Examples The following is a circuit example of the 8-point I/O combined type. To improve the noise immunity, isolate the CC-Link communication circuit. (Recommended) For details on the CC-Link communication circuit, refer to Section 5.2 “CC-Link Communication Circuit Examples”. *1: For the CC-link communication circuit, refer to Section 5.2 "CC-Link Communication Circuit Examples".
  • Page 24 The following diagrams are the examples of the isolated CC-Link communication circuits. When a digital isolator is used RS485 tra nsceiver Digital isolat or Damping resistor 10 kΩ 10 kΩ VCC2 VCC1 Filter OUTA MFP2AN OUTB 1 pin MFP2ANS 3300 pF 0.1 μF 50 V 8 pin GND2 GND1 11 pin 12 pin 0.1 μF...
  • Page 25 5.3 Precautions for Printed Circuit Board Design (1) Precautions for remote I/O station circuit (a) Make the traces between the crystal oscillator and MFP2AN as short as possible so that a damping resistor can be surface mounted. (b) Keep as much distance between the crystal oscillator trace and other signal traces.
  • Page 26 For the model, manufacturer, and specifications of each component, refer to the CC-Link Specification (Implementation). 6.3 MFP2AN MFP2AN can be purchased from your Mitsubishi Electric dealer network. For prices, please ask your dealer. MFP2AN is the lead-free/RoHS Directive compliant product.
  • Page 27 The LEDs are turned on using the dynamic scanning method. I/O assignment The following are the data areas to be used by MFP2AN within the data area (RX/RY: 32 bits) of one station. I/O type Input type Output type...
  • Page 28 7.2 Station Number and Baud Rate Settings The station number and baud rate settings are set at active "L" as shown in the table below. The settings are latched after reset (at the falling edge of RST). Station number setting value 1 to 64: Station number (normal) 0, 65 or higher: A station number switch setting error occurs.
  • Page 29 8. LED ON/OFF CONDITIONS POWER: Turns on when the internal 5 V is normal. L RUN: Turns on while the refresh data is being received normally, and turns off when data refresh is not performed for a certain period of time. (Y outputs are turned off at the same time.) L ERR.: Turns on when the data addressed to the own station has a CRC error or when an abort error occurs.
  • Page 30 I/O status LEDs MFP2AN outputs the I/O status for the number of I/O points (16 points maximum) to the LEDs using the dynamic scanning method. LEDX0 LEDX1 LEDX2 LEDY0 "PW" LEDY1 "L RUN" LEDY2 "SD" LEDY3 "RD" LEDY4 "L ERR."...
  • Page 31 MFP2AN has the following monitor pins. ・SDNRZ : For send data before modulation ・RDNRZ : For receive data after demodulation : For bit data I/O circuit (MFP2AN external) delay ・IDT : For transmission clock (= frequency based on the baud rate setting) ・SCLK...
  • Page 32 10. HANDLING PRECAUTIONS 10.1 Recommended Infrared Reflow Soldering Conditions (Including Hot Air Reflow and Infrared + Hot Air Reflow) The following shows the recommended infrared reflow soldering conditions (for the moisture absorption control product). Opening of the aluminum moisture-resistant packaging Baking Storage period: Within 7 days (125°C±5°C, 20 to 36 hours)
  • Page 33 10.2 Precautions When Opening the Package Open the package immediately before soldering. Use the product within the moisture-resistant packaging storage period (within 12 months after sealing). This product requires moisture control. After opening, store the product in a moisture-proof environment (temperature: 30°C or lower, humidity: 70% RH or less), and mount the product within 7 days.
  • Page 34 APPENDICES Appendix 1 MFP2AN Previous Specifications Appendix 1.1 External appearance (before March 2020) The following is the external appearance of MFP2N before March 2020. Unit: mm 14.00±0.20 12.00±0.20 MFP2AN PC97007N LOT NUMBER Lead-free/RoHS Directive compliant identification mark (dot) 1.25 Pin tip shape diagram 1.25...
  • Page 35 Appendix 1.2 External appearance (before September 2014) The following is the external appearance of MFP2AN before September 2014. Unit: mm 14.00±0.20 12.00±0.20 Lead-free/RoHS Directive compliant identification mark (dot) MFP2AN PC97007N LOT NUMBER 1.25 Pin tip shape diagram 1.25 0.22 0.50 0.08...
  • Page 36 Refer to this section when considering replacement. Appendix 2.1 Model names Item Discontinued model Alternative model Product PC97007N PC18006E Model (package unit: 60 pieces) A6GA-CCMFP2ANN60F A6GA-CCMFP2ANN60FN Model (package unit: 300 pieces) A6GA-CCMFP2ANN300F A6GA-CCMFP2ANN300FN Manufacturer Mitsubishi Electric Corporation Mitsubishi Electric Corporation...
  • Page 37 Appendix 2.2 External appearance Appendix 2.2.1 Package dimensions 60PIN 41PIN 61PIN 40PIN 21PIN 80PIN 1PIN 20PIN Ｃ θ Detailed package dimensions [Unit: mm unless otherwise specified] PC97007N PC18006E Symbol Min. Nom. Max. Min. Nom. Max. 11.80 12.00 12.20 11.90 12.00 12.10 11.80 12.00...
  • Page 38 Appendix 2.2.2 Print position specifications For the print position of PC18006E, refer to Section 3.1 "External Appearance". For the print position of PC97007N, refer to Appendix 1.1 "External appearance (before March 2020)". Appendix 2.3 Electrical characteristics Appendix 2.3.1 Buffer types Buffer type PC97007N PC18006E...
  • Page 39 Appendix 2.3.4 DC characteristics PC97007N PC18006E Item Rated value Rated value Unit Symbol Symbol Min. Typ. Max. Min. Typ. Max. 0.7V "H" input voltage (Min.: 3.15) CMOS 0.3 V "L" input voltage 1.65 (Max.: 1.65) "H" input voltage 2.29 "L" input voltage 0.77 Positive trigger voltage 4.05...
  • Page 40 Appendix 2.3.5 AC characteristics PC97007N PC18006E Item Condition Rated value Rated value Unit Symbol Symbol Min. Typ. Max. Min. Typ. Max. Output rising time = 15 pF Output falling time Appendix 2.3.6 I/O capacitance PC97007N PC18006E Item Condition Rated value Rated value Unit Symbol...
  • Page 41 Appendix 2.5 Handling precautions Appendix 2.5.1 Recommended conditions Item PC97007N PC18006E After package opening Within 7 days Within 7 days Baking 125°C, 10 to 72 hours 125°C, 20 to 36 hours Maximum temperature (package surface 260°C or lower 260°C or lower temperature) Preheating time 160 to 180°C, 60 to 120 s...
  • Page 42 This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents in this manual.
  • Page 43 Warranty Please confirm the following product warranty details before using dedicated LSI. Gratis Warranty Term and Gratis Warranty Range If any faults or defects (hereinafter "Failure") found to be the responsibility of Mitsubishi occurs during use of the product within the gratis warranty term, the product shall be replaced at no cost via the sales representative or Mitsubishi Service Company.
  • Page 44 SH(NA)-080623ENG-K(2402)MEE MODEL: CC-LINK-MFP2AN-R-E MODEL CODE: 13JV14 HEAD OFFICE: TOKYO BLDG., 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN NAGOYA WORKS: 1-14, YADA-MINAMI 5-CHOME, HIGASHI-KU, NAGOYA 461-8670, JAPAN When exported from Japan, this manual does not require application to the Ministry of Economy, Trade and Industry for service transaction permission.
