Your Sewerooter T-4 is designed to
give you years of trouble-free, profitable
service. However, no machine is better
than its operator.
Read, understand and follow all
safety warnings and instructions provid-
ed with the product. Failure to follow
the warnings and instructions may re-
sult in
electric shock and/or serious
injury. Save all warnings and instruc-
tions for future reference.
SAVE THESE INSTRUCTIONS!
Sewerooter T-4™
Operating Instructions
For 3" through 10" lines
(75mm—250mm)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for General Pipe Cleaners Sewerooter T-4
Summary of Contents for General Pipe Cleaners Sewerooter T-4
- Page 1 Sewerooter T-4™ Operating Instructions For 3” through 10” lines (75mm—250mm) Your Sewerooter T-4 is designed to give you years of trouble-free, profitable service. However, no machine is better than its operator. Read, understand and follow all safety warnings and instructions provid- ed with the product.
- Page 2 These operation and maintenance items could become wrapped around the procedures for Sewerooter T-4. cable and cause serious injury. Always wear safety glasses and rub- ber soled, non-slip shoes. Use of this...
- Page 3 Sewerooter T-4™ GENERAL POWER TOOL SAFETY WARNINGS* 3. Prevent unintentional starting. Ensure the switch is in the off- position before connecting to power source and/or BATTERY WARNING pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power tools that have the Read all safety warnings, instructions, illustrations and specifica- switch on invites accidents.
- Page 4 Sewerooter T-4™ Specific Safety Information for Sewerooter T-4 Service 1. Only wear leather gloves. Never use any other type of glove, 1. Have your power tool serviced by a qualified repair person such as cloth, rubber, or coated gloves. Never grasp a rotating using only identical replacement parts.
- Page 5 Sewerooter T-4™ Ground Fault Circuit Interrupter (GFCI) Cable Application Chart (Table 1) Your machine is equipped with a ground fault circuit interrupter, which protects you against shock if a short circuit should occur. Check that Cable Pipe Typical Max. receptacle is properly grounded. Test the GFCI before each use.
- Page 6 Sewerooter T-4™ OPERATION INSTALLING THE GUIDE TUBE HOLDER Set-Up To install the Guide Tube Holder, follow the assembly shown in the diagram below. Place the Guide Tube Holder on the mount- MAKE SURE THE MOTOR SWITCH IS IN THE ing knob, then thread it onto the bolt to secure the Power Cable ‘OFF’...
- Page 7 Sewerooter T-4™ Operation If you still can't get around the bend, you're probably using too large a cable. Switch to a smaller cable (See Cable Application Before stepping on the foot pedal, pull cable from the drum and Chart—Table 1), or use the optional flexible leader.
- Page 8 Sewerooter T-4™ MAINTENANCE HOW TO INSTALL CABLES IN DRUM DISCONNECT MACHINE FROM POWER SOURCE DISCONNECT MACHINE FROM POWER SOURCE BEFORE PERFORMING MAINTENANCE! BEFORE INSTALLING CABLES OR DRUMS! To keep your machine operating smoothly, it is essential that all bear- ings be lubricated. Oiling moving parts is particularly important where Connect the male end of cable to machine comes in contact with sand, grit and other abrasive material.
- Page 9 Sewerooter T-4™ In order to help align the Spacers and Bearings, insert a pencil point or similar object through the un-threaded end of the Axle hole in the Carrier. After removing the pencil point, continue to maintain the alignment of the components.
- Page 10 Sewerooter T-4™ TROUBLE SHOOTING GUIDE Problem Probable Cause Solution Operator forcing the cable. Do not force cable! Let the cutter do the work. Too much slack between machine and drain. Allow a distance of no more than two feet between machine and drain.
- Page 11 Sewerooter T-4™ This page intentionally left blank.
- Page 12 Sewerooter T-4™ General Wire Spring Co. 1101 Thompson Avenue McKees Rocks, PA 15136 412-771-6300 www.drainbrain.com © General Wire Spring Co. 2022 C-T4OI-0322...
