Page 1 HOW TO USE THIS MANUAL BEFORE USE DVD AUDIO SYSTEM SETTINGS OWNER’S MANUAL AUDIO RTURZ0SH003401 APPS VEHICLE INFORMATION HANDSFREE STEERING WHEEL BUTTONS REAR CAMERA RTURZ0SH004001 REFERENCE No.DVDAUD-IE-2431 Printed in Thailand...
Page 2 • We recommend that you also read the separate instructions for the equipment on your vehicle that was installed by your Isuzu Dealer. • Your Isuzu Dealer will be glad to answer any questions you may have about the information in this manual.
Page 3 Symbols Used in This Manual WARNING • Failure to follow these instructions identified by this symbol could result in a fire inside your vehicle in addition to death or serious injury to you and/or other people. CAUTION • Failure to follow these instructions identified by this symbol could result in injuries or an accident.
Page 4 "Symbols Used in This Manual". • Please read all materials, such as instruction manuals and warranties provided with the product. ISUZU will not be responsible for unsatisfactory product performance due to failure to comply with these instructions. • Changes to product specifications may result in differences between the content of the instruction manual and features of the product.
Page 5 CHAPTER DESCRIPTION HOW TO USE THIS MANUAL ....... 1 BEFORE USE ..........2 SETTINGS ............3 AUDIO ............4 APPS .............. 5 VEHICLE INFORMATION ......6 HANDSFREE ..........7 STEERING WHEEL BUTTONS ..... 8 REAR CAMERA ..........9 REFERENCE ..........10...
Page 7 HOW TO USE THIS MANUAL ● How to Use This Manual ● How to Find a Specific Topic...
Page 8 HOW TO USE THIS MANUAL How to Use This Manual Chapter index tab Chapter/section titles Use this for quick access to These titles are useful for getting the your desired chapter. gist of the content at a glance. 4-12 AUDIO USB Music File Player Using the USB music file player This unit can play music files saved in a USB flash drive.
Page 9 HOW TO USE THIS MANUAL How to Find a Specific Topic Search for the page describing the specific topic by using the general table of contents under CHAPTER DESCRIPTION, the CHAPTER INDEX, and/or the TABLE OF CONTENTS on the first page of each chapter.
Page 10 HOW TO USE THIS MANUAL...
Page 11 BEFORE USE ● Operating Precautions ● How to Use This Unit ● How to Use the Home Screen 2-11 ● Customising the Home Screen 2-15...
Page 12 • The volume must be set at an appropriate level to avoid hearing damage when the unit is turned on. • Do not disassemble or modify the product as its internal structure is designed precisely. If you need any technical assistance, please contact your nearest ISUZU dealer. ADVICE •...
Page 13 • The driver should not operate or focus on the screen while driving. If the driver wants to operate the unit, stop the vehicle in a safe location first. Turn on the vehicle engine. • Shortly after, the ISUZU logo is displayed for a few seconds, followed by the CAUTION screen.
Page 14 BEFORE USE Part names and functions <9 inch Display: Hi-grade models> <8 inch Display: Mid-grade models> <8 inch Display: Basic grade models> Panel button Hi-grade models Left hand drive cars Mid/Basic grade models Hi-grade models Right hand drive cars Mid/Basic grade models...
Page 15 BEFORE USE Button Function Press: • Touch to turn audio on/off. Turn: • Turn to change the volume. − Turning to the right raises the volume, while turning to the left lowers it. Press and hold: • Press and hold to turn off the screen display. −...
Page 16 BEFORE USE Button Function Turn: • Move up/down the frequency 1 step. • Moves tracks/files up or down. Press: • When audio is off: This displays the Audio menu screen. • When audio is on (when not on the audio top screen): This displays the Audio screen.
Page 17 BEFORE USE USB terminals CAUTION • The USB connection cable connection cable must be placed where it does not interfere with safe driving. Connect (or disconnect) the USB flash drive or smartphone to the USB terminal with the USB connection cable. •...
Page 18 BEFORE USE Operating with gestures You can operate this unit with touch gestures. CAUTION • Touch the touch screen buttons with your finger. Operating touch screen buttons with the point of hard objects, such as ballpoint pens and mechanical pencils, may damage the screen.
Page 19 BEFORE USE Using the common touch screen buttons You can operate this unit by touching the marks and items displayed on the screen directly with your fingers. • To prevent damage to the touch screen, do not press down hard on the touch-panel keys.
Page 20 2-10 BEFORE USE Operating the on-screen keyboard Function Displays the entered characters. Enters the touched character in the text field. The button display will change as follows depending on the keyboard. • : Switches between symbol keypads and numeric keypad. •...
Page 21 2-11 BEFORE USE How to Use the Home Screen Home screen Buttons, information and widgets are displayed on the home screen. Touch the buttons or drag the screen to open screens and access functions. <Left hand drive cars screen> <Right hand drive cars screen> (5)(6) (7) (5)(6) (7) Function...
Page 22 2-12 BEFORE USE Function Page Connect widget • Touch to display the Connect menu screen. • : Touch to display the Apple CarPlay screen. • : Touch to display the Android Auto screen. • : Touch to display the Miracast screen. Setting widget •...
Page 23 2-13 BEFORE USE Status bar The status bar consists of two areas. (1) (2) Function Status display area: • Shows the status of the unit functions. : Indicates that a device is connected to the USB terminal. Indicates that an overcurrent has occurred in the device connected via the USB terminal.
Page 24 2-14 BEFORE USE Smartphone connect menu screen Drag down the menu bar at the top of the home screen to display the Smartphone connect menu screen, where each source can be selected. Function Page Phone USB music: 4-12 USB video: 4-15 iPod: 4-19 Bluetooth Audio 4-23...
Page 25 2-15 BEFORE USE Customising the Home Screen Widget Add frequently used functions to the home screen as widgets. Selecting a widget on the Home screen Widgets can be selected by flicking the clock/calendar widget or Vehicle widget to the left or right. Function Page Clock/Calendar widget...
Page 26 2-16 BEFORE USE Clock/calendar widget If you touch an area of the widget other than a touch screen button, the clock/calendar widget appears in the full screen. <Widget screen> <Full screen> Function Time Calendar • Full screen: Flick left or right to switch calendar months. −...
Page 27 SETTINGS ● Displaying the Settings Screen ● System Settings ● Audio Settings 3-11 ● Display Settings 3-15 ● Bluetooth Settings 3-17 ® ● Wi-Fi Settings 3-25 ● Camera Settings 3-27...
Page 28 SETTINGS Displaying the Settings Screen Display the settings menu to configure all of the settings on this device. Touch Setting Touch a settings button on the left-hand side of the screen to view an option. • System settings (See page 3-3) •...
Page 29 SETTINGS System Settings This allows you to change system settings. On the settings screen, touch System Touch the setting you want to change. • System Language (See page 3-3) • Clock Setting (See page 3-4) • Select Time Zone (See page 3-5) •...
Page 30 SETTINGS Clock settings This allows you to change the settings of clock display. On the System settings screen, touch Clock Setting • The clock settings screen will be shown. Clock format settings This allows you to change the type of clock format. Set Use 24-hour Format to •...
Page 31 SETTINGS Time zone settings On the System settings screen, touch Select Time Zone Touch your time zone. • See the table below for details on region settings. Default Markets Time zone settings setting Greenwich Greenwich, Central, East, Manual Asia GMT+7 GMT+7, GMT+8, GMT+9, Manual Central America, South America GMT-4...
Page 32 SETTINGS Daylight saving time settings You can configure daylight saving time. On the System settings screen, set Daylight Saving Time to • When set to on, the current time is advanced by one hour. Phone name order settings Select whether to sort the phone book by First name or Last name. On the System settings screen, touch Phone Name Order...
Page 33 SETTINGS System reset This allows you to delete all registered data/system settings and restore the unit to its factory defaults. On the System settings screen, touch Reset • The system reset screen will be shown. Reset the Wi-Fi password The saved Wi-Fi password can be reset by using Access Point Mode in the Wi-Fi settings.
Page 34 SETTINGS Initialising system settings This allows you to delete all system settings and restore the device to its factory defaults. On the Reset settings screen, touch Restore Factory Default Touch Touch NOTE • Always carry out one of these operations when transferring, reselling or disposing of the vehicle.
Page 35 SETTINGS Software updates Software updates can be performed by connecting a USB flash drive containing the downloaded update data to the USB terminal. CAUTION • Do not turn the engine switch or appliance off while software is updating. Connect a USB flash drive to the USB terminal.
Page 36 3-10 SETTINGS Viewing system data On the System settings screen, touch About System information On the About screen, touch System Information • The System information screen is displayed. • See "Open Source License Information" on page 10-33 for details about the open source license.
Page 37 3-11 SETTINGS Audio Settings This allows you to change audio settings. On the settings screen, touch Audio Touch the setting you want to change. Fader / Balance settings On the Audio settings screen, touch Fader / Balance Touch or drag the cursor to the position you want.
Page 38 3-12 SETTINGS Mid settings The mid range can be enhanced or attenuated. On the Audio settings screen, touch Touch or drag the cursor to the position you want. • Adjustable range is –5 to +5. • The default setting is 0. •...
Page 39 3-13 SETTINGS Compressor settings Decreasing the difference between soft and loud sounds allows listeners to enjoy music at a stable volume. On the Audio settings screen, set Compressor to Beep sound settings On the Audio setting screen, set Beep Sound to Phone volume settings On the Audio settings screen, touch Phone Volume...
Page 40 3-14 SETTINGS Guide sound output settings This allows you to set the right or left speaker to output guide sounds. On the Audio settings screen, touch Prompt Speaker Setting Touch the desired speaker output. System restart sound settings After the ignition switch has been put in the OFF (LOCK) position, if the engine is started or the ignition switch is put in the ACC position, the volume is adjusted to an appropriate level (8 to 40).
Page 41 3-15 SETTINGS Display Settings This allows you to change display settings. On the settings screen, touch Display Touch the setting you want to change. Home screen settings You can also select from two types of home screen layout. On the Display settings screen, touch Home Screen Layout Touch the desired layout.
Page 42 3-16 SETTINGS Screen settings Choose from three screen display modes, which can be adjusted. On the Display settings screen, touch Image Adjustment Touch the mode to configure, from , and General PhoneMirror Camera • Image quality can be adjusted for each mode.
Page 43 3-17 SETTINGS Bluetooth Settings ® The Bluetooth settings screen allows you to add/remove mobile phones or portable ® devices, connect or disconnect, change passcodes (passkeys), and view detailed Bluetooth settings. ® WARNING • Do not add or adjust Bluetooth settings while driving. Stop your vehicle in a safe ®...
Page 44 3-18 SETTINGS Bluetooth on/off ® This allows you to turn Bluetooth features on and off. ® On the Bluetooth settings screen, set Bluetooth to NOTE • To enable Android Auto Bluetooth is automatically turned on when a device is connected via USB. Paired device list It is possible to check paired mobile phones and portable devices, and to delete them.
Page 45 3-19 SETTINGS Adding a mobile phone or portable device You can add up to 5 mobile phones or portable devices to this unit. • Make sure the Bluetooth setting on the adding mobile phone or portable device is ® − On your smartphone, navigate to Settings Bluetooth and turn on the Bluetooth toggle switch.
Page 46 3-20 SETTINGS Pair from this device Touch Search Device Touch the mobile phone or portable device you want to add. Check the PIN code displayed the unit and on your mobile phone or portable device, and follow the instructions displayed on the screen of your mobile phone or portable device.
Page 47 3-21 SETTINGS Pair from a mobile phone or portable device Turn on Bluetooth on your mobile ® phone or portable device. Touch Pair from Mobile Phone • The pairing process differs depending on the mobile phone or portable device. Please pair as required by the device.
Page 48 3-22 SETTINGS Delete a device On the Bluetooth settings screen, touch Paired Device List Touch by the mobile phone or portable device to delete. Touch NOTE • If a mobile phone is deleted, all data associated with the device is also deleted, including call history and address book data.
Page 49 3-23 SETTINGS Auto-reject settings This allows you to automatically reject incoming phone calls. On the Bluetooth settings screen, set Auto Rejecting to • Setting this to will cause incoming calls to be automatically rejected. Bluetooth details ® On the Bluetooth settings screen, touch Paired Device List Touch the mobile phone or...
Page 50 3-24 SETTINGS Switching devices If two or more mobile phones or portable devices are paired, you can switch between the mobile phone and portable device you want to use. On the Paired Device List screen, touch the mobile phone or portable device you want.
Page 51 3-25 SETTINGS Wi-Fi Settings For Wi-Fi supported standards, see "Specifications" on page 10-34. ADVICE • This unit is designed for use in current country of residence only. • If Wi-Fi connection used when you visit to any other country should local law accordingly.
Page 52 3-26 SETTINGS Turning Miracast on or off On the Wi-Fi settings screen, touch the Miracast Enable the Miracast function on your smartphone. • For information on how to use your smartphone, please refer to the user manual for your smartphone. •...
Page 53 3-27 SETTINGS Camera Settings Rear camera guide line display settings Set whether or not camera guide lines are displayed while reversing. If equipped with dynamic guide line rear camera On the settings screen, touch Camera Press the toggle button for the desired setting.
Page 54 3-28 SETTINGS...
Page 55 AUDIO ● Audio Menu ● Radio ● DAB (If Equipped) ● USB Music File Player 4-12 ● USB Video File Player 4-15 ● iPod Player 4-19 ● Bluetooth Audio 4-23 ®...
Page 56 AUDIO Audio Menu The following mode can be selected from the audio menu. Touch Touch your desired mode. Icon Function Page Radio Displays the Radio / DAB screen. DAB (If Equipped) Music File Player 4-12 Displays the USB music / video or Video File Player 4-15 iPod screen.
Page 57 AUDIO Radio Using the radio Models with RDS <AM screen> <FM screen> (14) (15) (13) (12) (11) (11) (10) (10) (6) (5) (1) Band button *1 (9) Auto preset button (2) Text scroll button*2, *3 (10) Tune up/down buttons (3) Preset buttons (11) Currently receiving frequency (4) Audio settings button (12) Radio text information*2...
Page 58 AUDIO Radio tuner reception frequency Country or region Reception frequency Tuning step Auto tuning step 522–1,611 kHz 9 kHz 9 kHz 87.50–108.00 MHz 0.05 MHz 0.10 MHz 531–1,629 kHz 9 kHz 9 kHz Asia, Africa, Pacific 87.50–108.00 MHz 0.05 MHz 0.05 MHz 530–1,710 kHz 5 kHz...
Page 59 AUDIO Automatic storing Touch Auto-P • To cancel existing auto presets, touch Cancel • The tuner searches for stations starting from the lowest frequency and progressing toward higher frequencies. When a station with a sufficiently strong signal is found, it will be assigned to the preset 6 button for the current band. When this process is complete, the tuner will return to the first stored station.
Page 60 AUDIO About RDS (Radio Data System) RDS (Radio Data System) can receive the name of the currently receiving station, title, artist, album, and traffic information via FM radio. This function is not available in some countries or areas. Selecting a station from the list Touch Touch the desired station.
Page 61 AUDIO FM alternative frequency (AF) setting When the AF function is on, the frequency will automatically switch to the optimum receiving frequency for the station you are currently listening to. In some regions, stations may broadcast the same programme on different frequencies. This function is not available in some countries or areas.
Page 62 For more details, such as information about DAB/DAB+ services that can only be used in certain regions, please contact your ISUZU dealer. For the purpose of in this chapter, DAB or DAB+ will be described as DAB.
Page 63 AUDIO Selecting a ensemble Touch the ensemble seek buttons, or turn the button. • The tuner moves automatically to the station closest to the frequency currently displayed on the screen and stops. To cancel auto tuning while it is operating, touch the button again.
Page 64 4-10 AUDIO Enlarging the slideshow display You can enlarge the received slideshow display. This function is not available in some countries or areas. Touch • Touch to cancel the enlarged view. NOTE • If the slideshow can no longer be displayed due to changes in the received information, it will switch to an icon.
Page 65 4-11 AUDIO DAB alternative frequency (DAB-AF) setting The DAB-AF function can be turned on/off. When this function is turned on, the system will automatically search for a better reception if the reception is poor, so that the user can listen to the same programme without interruption. Touch the toggle button in DAB Alternative Frequency.
Page 66 4-12 AUDIO USB Music File Player Using the USB music file player This unit can play music files saved in a USB flash drive. Only MP3/WMA/WAV/AAC/ Flac/ALAC/OGG Vorbis playback is supported. (11) (10) (1) Progress bar (7) List button (2) File up/down and fast forward/fast (8) Audio settings button reverse buttons (3) Folder selection buttons...
Page 67 4-13 AUDIO NOTE • Once a USB flash drive has been connected, it will take a small amount of time to scan the drive and fetch all the file information. Please refrain from storing any unnecessary data, such as folders or files other than music or video files, on your USB flash drive.
Page 68 4-14 AUDIO Selecting a file from the file list Touch • Select a track from a genre or folder. Touch the file you want. • When touching the structure name, the touched page will be displayed. • : Displayed if there are multiple folder layers. Touch to scroll through the display.
Page 69 4-15 AUDIO USB Video File Player Using the USB video file player WARNING • For your safety, you cannot view a video while the vehicle is in motion. • For watching the video file, be sure to stop your vehicle in a safety location and apply the parking brake.
Page 70 4-16 AUDIO Watching a USB video file Connect a USB flash drive to the USB terminal. On the Audio screen, touch • The playback starts. • Touch button to switch from video mode to music mode. • Touch the video image to enter full-screen mode.
Page 71 4-17 AUDIO Selecting a folder Touch • : Return to the first file in the previous folder. • : Advance to the first file in the next folder. Selecting a file Selecting a file Touch , or turn • – Touching once will return to the start of the current file. –...
Page 72 4-18 AUDIO Repeat playback Touch • To cancel repeat playback, touch again. Random playback Touch • To cancel random playback, touch again. Playback in slow motion Press and hold for more than 0.5 seconds. • Touch again to change the playback speed in 4 stages. •...
Page 73 4-19 AUDIO iPod Player Using the iPod player WARNING • Do not remove the iPod connection cable or operate the iPod while driving. This may cause accident or injury. CAUTION • The iPod connection cable must be placed where it will not interfere with safe driving.
Page 74 4-20 AUDIO NOTE • If you start playing back your iPod using an iPod connection cable while the engine switch is OFF and you later turn it to ACC or ON, sound may stop. If the sound stops, remove the iPod connection cable from the device, reconnect it and then switch the source button to iPod.
Page 75 4-21 AUDIO Listening to an iPod Connect an iPod to the USB terminal. On the Audio screen, touch NOTE • The album images are displayed only when the data is contained in the iPod. Pausing playback Touch • To resume playback, touch Fast forwarding and fast reversing Continue to touch •...
Page 76 4-22 AUDIO Selecting a file from the file list Touch Select the desired file from the categories in the list. • The selected file will start to play. • : Displayed if there are multiple folder layers. Touch to scroll through the display.
Page 77 4-23 AUDIO Bluetooth Audio ® Using Bluetooth audio ® Before using Bluetooth audio ® You can use a Bluetooth ® compatible portable audio player (portable device) via Bluetooth wireless communication technology as the source for the device. To use a ®...
Page 78 4-24 AUDIO NOTE • For more details of Bluetooth operations on the portable device, see the ® instruction manual supplied with the portable device or mobile phone. • Factors in the surrounding environment may negatively affect the connection status and prevent Bluetooth audio operations on the unit.
Page 79 4-25 AUDIO Listening to a portable device On the Audio screen, touch Bluetooth Audio • The playback starts. NOTE • If playback does not start automatically, touch • If playback does not start when you touch on this unit, press the play button on your portable device.
Page 80 4-26 AUDIO Selecting a track from a list Touch Touch the track you want. • : Displayed if there are multiple folder layers. Touch to scroll through the display. • : Appear if the characters of the name on the list exceed the display limit. Touch the buttons to scroll the display.
Page 81 APPS ● Before Using Application ● Connect Menu ● Apple CarPlay ● Android Auto 5-10 ● Miracast 5-17 ®...
Page 82 APPS Before Using Application Before using application Precautions to be aware of when using applications are shown below. In this chapter, iPhone or Android smartphone will be referred to as a smartphone. WARNING • Do not connect or operate the smartphone while driving. •...
Page 83 APPS NOTE • When connecting the device via Bluetooth , the communication speed may ® become slower than via USB. • If an application does not run smoothly or becomes unstable, please disconnect your smartphone from the Bluetooth ® or USB connection and reconnect. If the problem persists, please restart your smartphone.
Page 84 • If you lose the data in a smartphone or other device while using it with the system, no compensation will be given for the lost data. • ISUZU MOTORS LIMITED does not guarantee content provided by the application. • The application may not work due to factors on smartphones, smartphone...
Page 85 APPS Connect Menu You can select the Miracast, Apple CarPlay or Android Auto modes from the connect menu. Touch Connect Touch your desired mode. NOTE • The Apple CarPlay or Android Auto button is only available if an iPhone or Android smartphone is connected.
Page 86 APPS Apple CarPlay About the Apple CarPlay function You can use Apple CarPlay when an Apple CarPlay compatible iPhone is connected to this device via Bluetooth or USB. ® • When using this function via a wireless connection, the iPhone must be paired in the Bluetooth ®...
Page 87 APPS Using the Apple CarPlay function This function can be used with iPhones that support Apple CarPlay. Remove any iPods, iPhones, Android smartphone or USB devices connected to this device before connecting via Apple CarPlay. Settings cannot be changed while devices are connected.
Page 88 APPS Wirelessly connecting an iPhone When using this function via a wireless connection, the iPhone must be paired in the Bluetooth settings. See "Adding a mobile phone or portable device" on page 3-19 for ® details about Bluetooth ® settings. Your phone's Wi-Fi setting must be turned on in order to connect wirelessly.
Page 89 APPS The Apple CarPlay screen appears. • If another screen is displayed, touch on the Audio, Apple CarPlay Connect, or Smartphone connect menu screens. Connect to this unit from an iPhone On the System settings screen, touch Apple CarPlay Setting Touch Selecting from Apple CarPlay Device...
Page 90 5-10 APPS Android Auto About the Android Auto function You can use Android Auto when an Android Auto compatible Android smartphone is connected to this device via Bluetooth or USB. ® To use Android Auto, you must install the Android Auto application on your Android smartphone.
Page 91 5-11 APPS Using the Android Auto function Remove any iPods, iPhones, Android smartphone or USB devices connected to this unit before connecting via Android Auto. Settings cannot be changed while devices are connected. Turning the Android Auto function on or off You can turn the Android Auto function on and off and configure Android Auto wireless settings.
Page 92 5-12 APPS Connecting an Android smartphone via USB cable Connect your Android smartphone to the USB terminal. Touch on the Audio, Android Auto Connect, or Smartphone connect menu screen. The caution screen is only display the first time connection on the screen.
Page 93 5-13 APPS Wirelessly connecting an Android smartphone Your Android smartphone's Wi-Fi setting must be turned on in order to connect wirelessly. On your Android smartphone, go to Settings Wi-Fi and turn the Wi-Fi toggle switch to on. Connect to an Android smartphone from this unit On the System settings screen, touch Android Auto Setting...
Page 94 5-14 APPS The caution screen is only shown the first time you connect. Read the caution message carefully and then touch I agree The Android Auto screen will be displayed. • If another screen is displayed, touch on the Audio, Android Auto Connect, or Smartphone connect menu screens.
Page 95 5-15 APPS Make sure that the unit and the Android smartphone are showing the same matching code and then touch Pair* on the Android smartphone. • *The button may differ depending on your model of Android smartphone. Touch The caution screen is only shown the first time you connect.
Page 96 5-16 APPS Deleting a connected device You can delete a connected device. On the System settings screen, touch Android Auto Setting Touch Connected Device Touch by the Android smartphone to delete. Touch...
Page 97 5-17 APPS Miracast ® About Miracast This application is for Wi-Fi connections only. It allows you to mirror your Android smartphone's screen on this unit via Wi-Fi, letting you operate applications either via this unit's touch screen or via your Android smartphone. WARNING •...
Page 98 5-18 APPS Using Miracast Connecting an Android smartphone via Wi-Fi On the settings screen, touch Wi-Fi On the Wi-Fi settings screen, touch Miracast The Connection Waiting screen will be displayed. On your Android smartphone, set Miracast application to on. Select CAR AUDIO displayed on your Android phone.
Page 99 VEHICLE INFORMATION ● About Vehicle Information...
Page 100 VEHICLE INFORMATION About Vehicle Information WARNING • Do not try to set up or operate the vehicle link function while driving. • Make sure that the vehicle is parked in a safe location before setting up or operating the vehicle link function. Vehicle widget Swipe or touch the Vehicle widget on the home screen to go to the vehicle information screen.
Page 101 HANDSFREE ● About Bluetooth Handsfree ® ● Using the Handsfree Function ● Making a Call ● Receiving a Call 7-10 ● Operations During a Call 7-10 ● Editing to Set the Bluetooth ® Handsfree 7-13...
Page 102 HANDSFREE About Bluetooth Handsfree ® Bluetooth handsfree system ® The handsfree system allows you to connect your mobile phone and make or receive a call without taking your hands off the steering wheel. This unit supports Bluetooth standalone operation. Bluetooth is a wireless data ®...
Page 103 HANDSFREE NOTE • The unit may not function in the following conditions: − The mobile phone is turned off. − The current location is outside the communication area. − The mobile phone is not connected. − The mobile phone has a low battery. •...
Page 104 HANDSFREE Reception level indicator This indicates the reception level. • If there is no carrier service, an icon will be displayed. • The reception level indicator may not match the display of the mobile phone. Depending on the model, it may not be possible to display the reception level. NOTE •...
Page 105 HANDSFREE Using the Handsfree Function Displaying the phone NOTE • In this chapter, phone will be referred to handsfree. Touch Phone Display the handsfree screen.
Page 106 HANDSFREE Making a Call You can make a call from the unit by entering a telephone number, using a stored number in the phone book or speed dial, or calling from the incoming, missed or outgoing call history. WARNING • Do not make a call while driving. Be sure to park the vehicle in a safe location and apply the parking brake before making a call.
Page 107 HANDSFREE Calling from the phone book On the handsfree screen, touch Contact Select the person you want to call. • (1) Sort tab: Touch to sort the phonebook. If System Language is set to Arabic, Thai, or Russian, you can touch to switch between the sort languages.
Page 108 HANDSFREE Searching the phone book Touch Search Enter a desired keyword and touch Select the desired name from the list. Calling from call histories On the handsfree screen, touch History Select from the Missed tabs. Outgoing Incoming • Shows an overview of information from the Missed , Outgoing and Incoming tabs.
Page 109 HANDSFREE NOTE • Swipe the screen up or down: Scroll the list. • Up to 90 items per mobile phone can be saved in the incoming and outgoing calls history. When the number of items exceeds 90, the oldest items in the history are deleted and the most recent items are saved.
Page 110 7-10 HANDSFREE Receiving a Call When a call arrives, a ringtone sounds and the incoming call screen appears. When the call is received, the screen is switched to the talking screen automatically. <Incoming call> Touch if the phone rings. • : Hang up and reject the incoming call.
Page 111 7-11 HANDSFREE Switching call audio output You can switch between your car speaker system and your mobile phone. In mobile phone mode, you can only use your mobile for calls. <Operating from the unit> Touch • Touch to switch to handsfree call. <Operating from the mobile phone>...
Page 112 7-12 HANDSFREE Call waiting/Three-way calling If you receive another call during a phone call, you can receive the new call while holding the current call on the talking screen. Touch on the talking screen if the phone rings. • Touch to end call waiting.
Page 113 7-13 HANDSFREE Editing to Set the Bluetooth Handsfree ® NOTE • Charge the mobile phone to prevent the mobile phone battery from running out during transfer. • This function is available for mobile phones supporting PBAP (Phone Book Access Profile). •...
Page 114 7-14 HANDSFREE Transferring the phone book data from a mobile phone You can transfer the telephone numbers (phone book data) saved in the mobile phone to the unit. In the phone book of this unit, you can save up to 1,000 persons and up to 5 telephone numbers for each person.
Page 115 7-15 HANDSFREE Registering speed dial You can save phone numbers to speed dial from your phone book or call history. A maximum of six phone numbers can be stored on each mobile phone registered on this device. Registering from the phone book On the phone book screen, touch the desired item.
Page 116 7-16 HANDSFREE Registering from histories Press and hold the desired item on the history screen for more than 1 second. Touch the desired number in the speed dial list (1-6). Touch Registering from the speed dial list Touch Speed Dial Touch the desired empty number (1-6) on the speed dial list screen.
Page 117 7-17 HANDSFREE Touch , and then Contact History press and hold the desired item for more than 1 second. Touch the desired number from the speed dial list (1–6). Touch Deleting speed dial Press and hold the number for deletion (1-6) on the speed dial list screen for more than 1 second.
Page 118 7-18 HANDSFREE...
Page 119 STEERING WHEEL BUTTONS ● Steering Wheel Buttons Operation...
Page 120 STEERING WHEEL BUTTONS Steering Wheel Buttons Operation The steering wheel switches can be used to perform the primary audio operations and handsfree operations. There are a number of different designs depending on the model of your vehicle. Volume buttons To operate the following, press or press and hold the button.
Page 121 STEERING WHEEL BUTTONS NOTE • You cannot change to an audio mode which is unavailable. Seek button To operate the following, press or press and hold the button. • Radio (AM, FM, DAB) mode: – Press this button to navigate preset up or preset down.
Page 122 STEERING WHEEL BUTTONS Phone button Press this button when you receive a call to answer or end/ reject call. *1: Receiving a call *2: Ending or Rejecting call NOTE • The phone button can only be used if a connection with a mobile phone has been established.
Page 123 REAR CAMERA ● Before Use ● Dynamic Guide Line Rear Camera ● Rear Camera ● Parking Aid & Rear Cross Traffic Alert 9-12...
Page 124 REAR CAMERA Before Use Equipment varies depending on your model, grade, options, etc. Please check the following before using. WARNING • For checking the rear camera image, be sure to stop your vehicle in a safety location and apply the parking brake. Rear camera image Explanation ■...
Page 125 REAR CAMERA Dynamic Guide Line Rear Camera Important points regarding the rear camera system CAUTION • Do not rely too much on this feature when driving. It might not be possible to park the vehicle in the predicted position due to factors such as road characteristics, surface conditions, variations in driving technique and the calibration status of the steering angle sensor.
Page 126 ACC or LOCK position and restart the engine, then check that it displays correctly. If you continue to have the same issues, contact your local ISUZU dealer. NOTE • Due to the characteristics of the camera lens, people and obstacles shown on screen will appear to be at different positions and distances to where they actually are.
Page 127 REAR CAMERA Parking Important points when near standing objects The guide lines on the screen are intended for flat surfaces (such as roads). When near objects with overhanging portions (such as tail lifts on vans or lorries) make sure to check your rear and your surroundings directly when reversing. In cases such as the following image, the tail lift is outside of the trajectory lines, so it seems as though the vehicle won't hit it.
Page 128 REAR CAMERA Function Line colour The predicted reversing trajectory is displayed using Dynamic Guide Line (trajectory lines). Red, Yellow, Green line • They appear wider than in reality. • They are linked to the movement of the steering wheel. Distance guide lines are displayed behind the vehicle (from the tip of the rear bumper).
Page 129 REAR CAMERA Parking using Dynamic Guide Line Displays Dynamic Guide Line (trajectory lines) linked to the steering wheel to allow you to check the vehicle's trajectory when parking. • If parking in the opposite direction to the following explanation, the steering wheel directions will be reversed.
Page 130 REAR CAMERA When the rear of the vehicle has entered the parking space, rotate the steering wheel so that the Static Guide Line (vehicle width extension lines) and the partition lines at the sides of the parking space are roughly the same distance apart.
Page 131 REAR CAMERA Rear Camera The rear camera displays the video image behind the vehicle a few seconds after shifting into the reverse gear. WARNING • The rear camera displays a mirror-reversed video image to give the same view as the rear or side mirror. The way to view the image varies depending on the vehicle model.
Page 132 ACC or LOCK position and restart the engine, then check that it displays correctly. If you continue to have the same issues, contact your local ISUZU dealer. NOTE • Due to the characteristics of the camera lens, people and obstacles shown on screen will appear to be at different positions and distances to where they actually are.
Page 133 9-11 REAR CAMERA Displaying the rear camera Image Shift into reverse gear. • The screen changes to the rear camera screen. • When you shift to a gear other than reverse, the screen returns to the screen displayed before the Check surroundings for safety Check surroundings for safety rearward image.
Page 134 − Do not subject the area around the sensor to impact. In the event of an impact, have the vehicle checked by an authorised ISUZU dealer. If it is necessary to remove or replace the bumper or grill, please consult an authorised ISUZU dealer.
Page 135 9-13 REAR CAMERA Parking aid The Parking aid function uses ultrasonic sensors to determine the approximate distance between the vehicle and obstacles such as walls before alerting the driver through buzzer sounds and distance indications on the rear camera screen. If you want to change the Parking aid settings, refer to vehicle information in the vehicle owner's manual.
Page 136 9-14 REAR CAMERA...
Page 137 REFERENCE ● If the Following Messages Appear 10-2 ● When You Think There is a Malfunction 10-3 ● Media 10-4 ● Copyright and Trademarks 10-11 ● About Certification 10-13 ● Open Source License Information 10-33 ● Specifications 10-34...
Page 138 There is communication error off and on. USB Communication Timeout to another unit. If the message continued, Error. contact your ISUZU dealer. Connect a device supported by Connecting an unsupported this unit. Unsupport device Error device. For supported devices, see "USB"...
Page 139 When You Think There is a Malfunction Some operating conditions of the unit may appear to be malfunctions. Please check the items in the following table first. If the problem remains after taking the appropriate action, contact your ISUZU dealer for an inspection. Condition...
Page 140 10-4 REFERENCE Media Radio Adjust the aerial length to improve reception. A shorter aerial is usually better in large cities, whereas for long-distance reception it is better to have the maximum length. (Aerial length may not be adjustable in some car models.) To prevent damage to the antenna, make sure it is retracted before running your vehicle through an automatic car wash.
Page 141 NOTE • ISUZU cannot guarantee compatibility with all USB mass storage devices and assumes no responsibility for any loss of data on media players, iPhone, smartphone, or other devices while using this unit.
Page 142 10-6 REFERENCE About USB devices Supported USB flash drive standards • File system format: FAT 16/32 • Audio formats: MP3/WMA/WAV/AAC/FLAC/ALAC/OGG Vorbis • Maximum current: 3.0 A • Compatibility: USB 2.0 High Speed • Does not support USB hubs or multi card readers. USB Audio formats MP3 (.mp3) •...
Page 143 10-7 REFERENCE AAC (.m4a) • Bit rate: 8 kbps to 256 kbps (AAC-LC), 8 kbps to 384 kbps (HE-AAC mono), 16 kbps to 768 kbps (HE-AAC stereo) • Sampling frequency: 8 kHz to 96 kHz FLAC (.flac) • Bit rate: Unlimited •...
Page 144 10-8 REFERENCE Item Specifications File format File extension .mkv .avi .3gp MPEG-4 MPEG-4 MPEG-4 MPEG-2 Video format H.264 MPEG-1 MPEG-1 H.263 XVID Audio format MPEG-4: 64 x 64 to 1920 x 1080 H.264: 64 x 64 to Resolution ratio 64 x 64 to 1920 x 1080 2048 x 1088 H.263: 128 x 96, 176 x 144,...
Page 145 10-9 REFERENCE NOTE • The tag information encoding formats supported by this unit are as follows. − ASCII (ISO-8859-1) − Unicode16 − UTF-8 • This unit does not support playback of the following files. − DRM (Digital Rights Management) file −...
Page 146 10-10 REFERENCE iPod, iPhone About supported iPod, iPhone This unit supports the following iPods and iPhones: Firmware/ Firmware/ Type Type OS version OS version iPod touch (6G) iOS 8.0.0 or later iPhone Xs Max iOS 7.0.0 or later iPod touch (7G) iOS 8.0.0 or later iPhone X iOS 7.0.0 or later...
Page 147 10-11 REFERENCE Copyright and Trademarks • USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum • Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple products identified in the badge, and has been certified by the developer to meet Apple performance standards.
Page 148 10-12 REFERENCE • The Bluetooth word mark and logos are registered trademarks owned by Bluetooth ® SIG, Inc. and any use of such marks by DENSO TEN Limited is under license. Other trademarks and trade names are those of their respective owners. •...
Page 149 10-13 REFERENCE About Certification 9 inch display Hi-grade model Information of the radio device: Type TN0040A 1. Name and postal address of the manufacturer Name: DENSO TEN Limited Address: 2-28, Gosho-dori 1-chome, Hyogo-ku, Kobe, 652-8510 Japan 2. Simplified EU declaration of conformity С...
Page 150 10-14 REFERENCE Hiermit erklärt DENSO TEN Limited, dass der Funkanlagentyp TN0040A der Richtlinie 2014/53/EU entspricht. Der vollständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: https://www.denso-ten.com/support/regulation/eu_doc/ Funktion Betriebsfrequenzband Maximale Hochfrequenzleistung Bluetooth 2402 - 2480 MHz 4.22 dBm 2412 - 2462 MHz 14.22 dBm WLAN 5745 - 5805 MHz...
Page 151 10-15 REFERENCE DENSO TEN Limited vakuuttaa, että radiolaitetyyppi TN0040A on direktiivin 2014/53/EU mukainen. EU-vaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa internetosoitteessa: https://www.denso-ten.com/support/regulation/eu_doc/ Toiminto Toimintataajuuskaista Maksimi radiotaajuusteho Bluetooth 2402 - 2480 MHz 4.22 dBm 2412 - 2462 MHz 14.22 dBm WLAN 5745 - 5805 MHz 9.67 dBm Le soussigné, DENSO TEN Limited, déclare que l'équipement radioélectrique du type TN0040A est conforme à...
Page 152 10-16 REFERENCE Hér með, lýsir DENSO TEN Limited því yfir að gerð útvarpsbúnaðarins TN0040A samræmist tilskipun 2014/53/EU. Allur texti ESB-samræmisyfirlýsingarinnar er aðgengilegur á eftirfarandi veffangi: https://www.denso-ten.com/support/regulation/eu_doc/ Aðgerð Notkunartíðni hljómsveit Hámarks útvarp-tíðni vald Bluetooth 2402 - 2480 MHz 4.22 dBm 2412 - 2462 MHz 14.22 dBm WLAN 5745 - 5805 MHz...
Page 153 10-17 REFERENCE Ovim, DENSO TEN Limited izjavljuje da je tip radio opreme TN0040A u skladu sa Direktivom 2014/53/EU. Cjelokupan tekst EU deklaracije o usklađenosti dostupan je na sljedećoj internet adresi: https://www.denso-ten.com/support/regulation/eu_doc/ Funkcija Operativni frekvencijski opseg Maksimalna jačina radio frekvencije Bluetooth 2402 - 2480 MHz 4.22 dBm 2412 - 2462 MHz...
Page 154 10-18 REFERENCE O(a) abaixo assinado(a) DENSO TEN Limited declara que o presente tipo de equipamento de rádio TN0040A está em conformidade com a Diretiva 2014/53/UE. O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet: https://www.denso-ten.com/support/regulation/eu_doc/ Função Faixa de freqüência operacional Potência máxima de radiofreqüência...
Page 155 10-19 REFERENCE Ovim, DENSO TEN Limited izjavljuje da је ovaj tip radijske opreme TN0040A u skladu sa odredbama Direktive 2014/53/EU. Kompletan tekst EU deklaracije o konformitetu je dostupan na sledećoj internet adresi: https://www.denso-ten.com/support/regulation/eu_doc/ Funkcija Radni frekvencijski pojas Maksimalna rediofrekvencijska snaga Bluetooth 2402 - 2480 MHz 4.22 dBm...
Page 156 MIDI EUROPE S.R.L. Via Crosaron di Calcara, 33-21, 37053 Cerea VR, Italy Wageningselaan 10 3903 LA Veenendaal, The Isuzu Benelux N.V. - Nederland Netherlands Isuzu Sales Österreich (Zweigniederlassung der Mayrwiesstr. 15, 5300 Hallwang bei Salzburg, Austria Isuzu Sales Deutschland GmbH)
Page 157 148 00 Praha 4 - Kunratice pobočka Česká republika Česká republika Baronessens Kvarter 5 ISUZU DANMARK A/S DK-7000 Fredericia Danmark Isuzu Sales Deutschland GmbH (ISD) Schieferstein 11A Isuzu Sales Deutschland GmbH 65439 Floersheim am Main Germany AW Distribution KFT. 2040 Budaörs, Szabadsäg utca 117. HUNGARY...
Page 158 Isuzu (UK) Limited The Gate Isuzu (UK) Limited International Drive Solihull B90 4WA ANADOLU ISUZU OTOMOTİV SAN. TİC. A.Ş. ANADOLU ISUZU OTOMOTİV SAN. TİC. A.Ş. Şekerpınar Mah. Otomotiv Cad. No:2 41435 Çayırova / Kocaeli Saevarhofoa 2 BL ehf. 110 Reykjavik Iceland Via Della Posta 2CH - 6900 Lugano - P.I.
Page 159 10-23 REFERENCE 8 inch display Mid/Basic grade models Information of the radio device: Type TN0040B 1. Name and postal address of the manufacturer Name: DENSO TEN Limited Address: 2-28, Gosho-dori 1-chome, Hyogo-ku, Kobe, 652-8510 Japan 2. Simplified EU declaration of conformity С...
Page 160 10-24 REFERENCE Hiermit erklärt DENSO TEN Limited, dass der Funkanlagentyp TN0040B der Richtlinie 2014/53/EU entspricht. Der vollständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: https://www.denso-ten.com/support/regulation/eu_doc/ Funktion Betriebsfrequenzband Maximale Hochfrequenzleistung Bluetooth 2402 - 2480 MHz 4.55 dBm 2412 - 2462 MHz 13.45 dBm WLAN 5745 - 5805 MHz...
Page 161 10-25 REFERENCE DENSO TEN Limited vakuuttaa, että radiolaitetyyppi TN0040B on direktiivin 2014/53/EU mukainen. EU-vaatimustenmukaisuusvakuutuksen täysimittainen teksti on saatavilla seuraavassa internetosoitteessa: https://www.denso-ten.com/support/regulation/eu_doc/ Toiminto Toimintataajuuskaista Maksimi radiotaajuusteho Bluetooth 2402 - 2480 MHz 4.55 dBm 2412 - 2462 MHz 13.45 dBm WLAN 5745 - 5805 MHz 10.41 dBm Le soussigné, DENSO TEN Limited, déclare que l'équipement radioélectrique du type TN0040B est conforme à...
Page 162 10-26 REFERENCE Hér með, lýsir DENSO TEN Limited því yfir að gerð útvarpsbúnaðarins TN0040B samræmist tilskipun 2014/53/EU. Allur texti ESB-samræmisyfirlýsingarinnar er aðgengilegur á eftirfarandi veffangi: https://www.denso-ten.com/support/regulation/eu_doc/ Aðgerð Notkunartíðni hljómsveit Hámarks útvarp-tíðni vald Bluetooth 2402 - 2480 MHz 4.55 dBm 2412 - 2462 MHz 13.45 dBm WLAN 5745 - 5805 MHz...
Page 163 10-27 REFERENCE Ovim, DENSO TEN Limited izjavljuje da je tip radio opreme TN0040B u skladu sa Direktivom 2014/53/EU. Cjelokupan tekst EU deklaracije o usklađenosti dostupan je na sljedećoj internet adresi: https://www.denso-ten.com/support/regulation/eu_doc/ Funkcija Operativni frekvencijski opseg Maksimalna jačina radio frekvencije Bluetooth 2402 - 2480 MHz 4.55 dBm 2412 - 2462 MHz...
Page 164 10-28 REFERENCE O(a) abaixo assinado(a) DENSO TEN Limited declara que o presente tipo de equipamento de rádio TN0040B está em conformidade com a Diretiva 2014/53/UE. O texto integral da declaração de conformidade está disponível no seguinte endereço de Internet: https://www.denso-ten.com/support/regulation/eu_doc/ Função Faixa de freqüência operacional Potência máxima de radiofreqüência...
Page 165 10-29 REFERENCE Ovim, DENSO TEN Limited izjavljuje da је ovaj tip radijske opreme TN0040B u skladu sa odredbama Direktive 2014/53/EU. Kompletan tekst EU deklaracije o konformitetu je dostupan na sledećoj internet adresi: https://www.denso-ten.com/support/regulation/eu_doc/ Funkcija Radni frekvencijski pojas Maksimalna rediofrekvencijska snaga Bluetooth 2402 - 2480 MHz 4.55 dBm...
Page 166 MIDI EUROPE S.R.L. Via Crosaron di Calcara, 33-21, 37053 Cerea VR, Italy Wageningselaan 10 3903 LA Veenendaal, The Isuzu Benelux N.V. - Nederland Netherlands Isuzu Sales Österreich (Zweigniederlassung der Mayrwiesstr. 15, 5300 Hallwang bei Salzburg, Austria Isuzu Sales Deutschland GmbH)
Page 167 Isuzu (UK) Limited The Gate Isuzu (UK) Limited International Drive Solihull B90 4WA ANADOLU ISUZU OTOMOTİV SAN. TİC. A.Ş. ANADOLU ISUZU OTOMOTİV SAN. TİC. A.Ş. Şekerpınar Mah. Otomotiv Cad. No:2 41435 Çayırova / Kocaeli Saevarhofoa 2 BL ehf. 110 Reykjavik Iceland Via Della Posta 2CH - 6900 Lugano - P.I.
Page 168 10-32 REFERENCE Importer name Importer address RUTEBILEIERNES STANDARDISERINGS– AKSJESELSKAP (RSA) RUTEBILEIERNES STANDARDISERINGS– Ovre Eikervei 77 Gulskogen AKSJESELSKAP (RSA) N-3005 Drammen Norway Carpenter Motors (Vanuatu) Ltd. Elluk Road, Namba Tri, Port Vila, Vanuatu Corner of Cameron Road & Waigani Drive, Gordon, PO Carpenter Automotive &...
Page 169 10-33 REFERENCE Open Source License Information This unit uses software based on an open source software license. See the open source software license for details. On the System screen, touch About Touch Open Source License...
Page 170 10-34 REFERENCE Specifications Display Wi-Fi 9 inch display Hi-grade Supported IEEE802.11 a/b/g/n/ac model: standards Liquid crystal 9 inch HD (1280 × 720) Security WPA2, WPA3 panel 8 inch display Mid/Basic protocols grade models: 8 inch WVGA (800 × 480) Amplifier Maximum Radio tuner 45 W...

Isuzu D-MAX Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Isuzu D-MAX

Summary of Contents for Isuzu D-MAX
