Cuisinart Outdoors CGG-9020 Manual

28” outdoor griddler - 2-in-1 griddle & broiler
Hide thumbs Also See for CGG-9020:
Table of Contents

Advertisement

Quick Links

Download this manual
• For Outdoor Use Only (outside
any
enclosure).
• This instruction manual
contains important information
necessary for proper assembly
and safe use of this appliance.
• Read and follow all warnings
and instructions before
assembling and using the
appliance.
• Follow all warnings and
instructions when using the
appliance.
• Keep this manual for future
reference.
DANGER
• If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open the lid.
4. If the odor continues, keep
away from the appliance and
immediately call your fire
department.
WARNING
• Do not store or use gasoline
or other flammable liquids or
vapors in the vicinity of this or
any other appliance.
• An LP cylinder not connected
for use shall not be stored in
the vicinity of this or any other
appliance.
Customer Service Hotline
1-866-994-6390
ANSI Z21.58-2018 • CSA 1.6-2018
DO NOT RETURN PRODUCT TO THE STORE
Before visiting your local retailer, please email outdoors@
cuisinart.com or call our customer service department at
1-866-994-6390 to chat with a representative. To best serve
you, our representatvies are available to answer calls Monday
to Friday 9 AM to 5 PM EST.
28" Outdoor Griddler -
2-in-1 Griddle & Broiler
MODEL NO: CGG-9020
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CGG-9020 and is the answer not in the manual?

Questions and answers

Related Manuals for Cuisinart Outdoors CGG-9020

Summary of Contents for Cuisinart Outdoors CGG-9020

  • Page 1 28” Outdoor Griddler - 2-in-1 Griddle & Broiler MODEL NO: CGG-9020 • For Outdoor Use Only (outside enclosure). • This instruction manual contains important information necessary for proper assembly and safe use of this appliance. • Read and follow all warnings...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents Safety Information What’s In The Box Assembly Instructions Setup Instructions Operating Instructions for Griddler Care and Maintenance Match Light Instructions Trouble Shooting Exploded View & Parts List Warranty & Replacement Parts Back Cover...

  • Page 3: Safety Information

    SAFETY INFORMATION SAVE THESE INSTRUCTIONS FOR OUTDOOR HOUSEHOLD USE ONLY • The installation must conform with local codes or, in the absence of local codes either ANSI Z223.1/NFPA 54, CSA B149.1, or CSA B149.2 • This outdoor cooking gas appliance must only be used outdoors and must not be used in a building, garage, or any other enclosed area •...
  • Page 4 SAFETY INFORMATION The Fuel System • Gas appliances are used safely by millions of people when following simple safety precautions. This appliance is configured for liquid propane, do not use a natural gas supply. • The components in the fuel system including the pressure regulator and hose are designed for operation with this Griddle/Broiler.

  • Page 5: What's In The Box

    WHAT’S IN THE BOX PART COMPONENT DESCRIPTION PART COMPONENT DESCRIPTION Front Left Leg Broiler Rack Griddle Back Left Leg Grease Chute Front Right Leg Grease Cup Tray Back Right Leg Left Side Table Lower Brace Right Side Table Upper Left Brace Ignitor Bracket Upper Right Brace Griddle Plate...

  • Page 6: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Before beginning assembly, installation or operation of product, make sure all parts are present. Compare parts with package contents list. If any part is missing or damaged, do not attempt to assemble, install or operate the product. Contact customer service for replacement parts. Estimated asembly time: Tools you will need: 2 hours...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP 2 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 4 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Attach the Upper Right Brace (7) to the right leg assembly using 4 A Screws.
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 6 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 7 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 8 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP 10 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP 12 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP 14 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 15 ASSEMBLY INSTRUCTIONS STEP 15 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP 17 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP 18 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 18 ASSEMBLY INSTRUCTIONS STEP 20 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 19 ASSEMBLY INSTRUCTIONS STEP 22 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 20 ASSEMBLY INSTRUCTIONS STEP 24 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Reinstall the C Screw that was removed from the top of the control panel in Step 22.
  • Page 21 ASSEMBLY INSTRUCTIONS STEP 25 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 22 ASSEMBLY INSTRUCTIONS STEP 26 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 23 ASSEMBLY INSTRUCTIONS STEP 28 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 24 ASSEMBLY INSTRUCTIONS STEP 29 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Install the lid hinges to the back corners of the griddle plate.
  • Page 25 ASSEMBLY INSTRUCTIONS STEP 30 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 26 ASSEMBLY INSTRUCTIONS STEP 32 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 27 ASSEMBLY INSTRUCTIONS STEP 34 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...

  • Page 28: Setup Instructions

    SETUP INSTRUCTIONS CONNECTING THE LIQUID PROPANE (LP) CYLINDER - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...

  • Page 29: Leak Test Procedure

    SETUP INSTRUCTIONS LEAK TEST PROCEDURE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Although gas connections on the griddle are leak tested prior to shipment, we recommend conducting a leak test after initial setup and every time an LP cylinder is attached.

  • Page 30: Getting Started- Operation

    OPERATING INSTRUCTIONS GETTING STARTED- OPERATION - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - OUTDOOR USE ONLY / NEVER LEAVE UNATTENDED 1.
  • Page 31 OPERATING INSTRUCTIONS HOW TO SEASON YOUR GRIDDLE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A properly seasoned griddle surface creates a naturally non-stick cook top and helps prevent rusting. Season- ing your griddle surface is essential for optimal performance and longevity.

  • Page 32: Care And Maintenance

    CARE AND MAINTENANCE CLEANING AND CARE - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Griddle Plate •...

  • Page 33: General Care

    CARE AND MAINTENANCE General Care • All painted and stainless steel surfaces can be cleaned with warm soapy water and a soft sponge. We do not recommend harsh scrubbers like steel wool on any of the surfaces as this can damage the paint and scratch the stainless steel.
  • Page 34 CARE AND MAINTENANCE REPLACING YOUR BURNERS STEP 1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 35 CARE AND MAINTENANCE STEP 3 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 36 CARE AND MAINTENANCE STEP 5 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...
  • Page 37 CARE AND MAINTENANCE STEP 6 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - •...

  • Page 38: Match Light Instructions

    MATCH LIGHT INSTRUCTIONS If for any reason you want to use a match to start this product please follow these instructions: • Open the lid • Verify the propane tank is installed and when turning the burner valve, gas flows through the burner. •...

  • Page 39: Trouble Shooting

    TROUBLE SHOOTING WARNING Spiders and insects can nest inside the burners of the Griddle and disrupt gas flow. This very dangerous condition could cause a fire behind the valve panel, thereby damaging the Griddle and making it unsafe for operation. Inspect the Griddle at least twice a year. When to Look for Spiders You should inspect the burner at least twice a year or immediately after any of the following conditions occur: •...
  • Page 40 TROUBLE SHOOTING Problems What To Do • Griddle smokes excessively • Ensure that you’re using the correct cooking oil (high smoke point oils like canola or peanut oil are preferred). • Clean the griddle after each use to remove any leftover grease or food particles that can burn and cause smoke.

  • Page 41: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST 15 16 17...
  • Page 42 EXPLODED VIEW & PARTS LIST For replacement parts, call our customer service department 866-994-6390, 9 a.m.-5 p.m., EST, Monday-Friday or email outdoors@cuisinart.com NOTE: Not all parts are replaceable. Part Description Quantity Lid assembly 1 pc Lid handle assembly 1 pc Lid hinges A 2 pc Lid hinges B...
  • Page 43 EXPLODED VIEW & PARTS LIST Part Description Quantity Pulse ignitor (1 out 3) 1 pc Grease guiding fixing plate 1 pc Grease cup 2 pc Grease box bracket B 1 pc Maintain cover 1 pc Broiler left side panel 1 pc Broiler left side inner panel assembly 1 pc Alex wheel...

  • Page 44: Warranty & Replacement Parts

    Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 866-994-6390, 9 a.m.-5 p.m., EST, Monday-Friday or email outdoors@cuisinart.com Visit our website: www.cuisinart.com 2410 Model#CGG-9020 Cuisinart Outdoors a division of Conair LLC Newton, MA 02466...
