Avita BPM925-LJB Instruction Manual

Arm type blood pressure monitor
Hide thumbs

Advertisement

Quick Links

Download this manual
Arm Type Blood Pressure Monitor
Model:
INSTRUCTION MANUAL
PLEASE READ THIS INSTRUCTION MANUAL COMPLETELY
BEFORE OPERATING THIS UNIT
EN
BPM925-LJB
MDSS GmbH
Schiffgraben 41
30175 Hannover Germany
AViTA Corporation
9F., No. 78, Sec. 1, Kwang Fu Rd.,
San Chung Dist., New Taipei City 24158, Taiwan, China
China, AViTA(WUJIANG)
Importer
Distributor
RoHS REACH

Advertisement

loading
Need help?

Need help?

Do you have a question about the BPM925-LJB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avita BPM925-LJB

Summary of Contents for Avita BPM925-LJB

  • Page 1 Arm Type Blood Pressure Monitor Model: BPM925-LJB INSTRUCTION MANUAL PLEASE READ THIS INSTRUCTION MANUAL COMPLETELY BEFORE OPERATING THIS UNIT RoHS REACH MDSS GmbH Schiffgraben 41 30175 Hannover Germany AViTA Corporation 9F., No. 78, Sec. 1, Kwang Fu Rd., San Chung Dist., New Taipei City 24158, Taiwan, China...
  • Page 2 Contents Intended Use........................1 Important Information before Use ................4 Product Identification ..................... 6 Description of LCD Display ................... 7 Battery Installation ......................8 Instruction for USB-C ...................... 9 Setting the Date and Time ..................10 Placement of the Pressure Sleeve................11 Measurement of Pulse Rate and Blood Pressure ..........
  • Page 3 Intended Use The product automatically measures human being‟s Systolic, Diastolic blood pressure and pulse rate by oscillometric method. The measurement results are displayed on the LCD. Measurement position is at human being‟s upper arm. The intended use of this over-the-counter device is for adults with upper arm circumference ranging from 220 mm to 420 mm (Approx.8.7 ~ 16.5 inches) and for home use.
  • Page 4 • If you are prone to hematoma, do not put on a cuff nor carry out a blood pressure measurement. Consult your doctor before measuring your own blood pressure if… • If you have any of the following conditions, it is essential you consult your doctor before using the device: cardiac arrhythmia, Cardiovascular disease, very low blood pressure, diabetes, circulatory problems, diabetes, liver function disorders or narrowing...
  • Page 5 malfunctions remove the cuff from the arm. • The blood pressure monitor is made from precision and electronic components. The accuracy of the measurements and service life of the device depend on its careful handling. • Do not drop the device. •...
  • Page 6 Important Information before Use 1. Blood pressure measurements should only be interpreted by a physician or a trained health care professional who is familiar with your medical history. Through regular use of this device and recording of your measurements, you can keep your physician informed of the changes in your blood pressure.
  • Page 7 (every 3 years). To obtain the service please contact AViTA Corp. for the address of the repair location. Enclose with the Proof of Purchase. Include $10.00 USD for the return shipping and handling.
  • Page 8 Product Identification Air socket Memory button ( M key) Set button (S key) Start/Stop BP mode measuring button (BP Power key) Start/Stop AF mode measuring button (AF Power key) Display Cuff Cuff connector Cuff tube...
  • Page 9 Description of LCD Display Low battery indicator WHO indicator Date & Time Irregular Heartbeat Symbol AF Symbol Memory Symbol and Memory Set Heartbeat Symbol Pulse rate Pressurize Release air User 1 User 2 Systolic Pressure Diastolic Pressure...
  • Page 10 Battery Installation Low battery warning: It is necessary to replace the batteries when the Low Battery symbol “ ” appears on the display, or when the display does not turn on after the POWER key is pressed. Replacing the Battery: 1.
  • Page 11 Instruction for USB-C Optional Parts USB-C adapter: Input: 100-240V~; 50/60HZ; 0.3A Max Output: 5V ; 1A Using the Optional USB-C Adapter: 1. Plug the USB-C end of the adapter into the USB-C port on the device of the main unit. 2.
  • Page 12 Setting the Date and Time It is necessary to set the date and time for the unit every time batteries are initially installed or replaced. To set the date and time, proceed as follows: • While in power off mode, press and hold the “S” key for at least 3 seconds to enter Date and Time setting procedure and the Year value will begin to flash.
  • Page 13 Placement of the Pressure Sleeve It is important to avoid smoking, eating, taking medication, alcohol consumption or physical activity 30 minutes prior to taking a reading. If for any reason you are unable to or should not use your left arm, please modify the instructions for cuff application to your right arm.
  • Page 14 4. Position the cuff on a solid surface with the tubing facing up and away from you. The metal ring/bar on the cuff should be to the left of the tubing. 5. Open the cuff by pulling or rolling the bottom of the cuff to the right. This should open the cuff without fully unrolling it, creating a cylinder.
  • Page 15 7. The bottom edge of the cuff should be positioned approximately one inch above the elbow joint. 8. Please reaching underneath your left arm with your right hand, pull the end of the cuff towards your body to tighten the cuff. Wrap and secure the cuff, making sure in place as shown.
  • Page 16 10. Insert the cuff into the monitor. Note: If you are not comfortable with applying your cuff, please seek the assistance of another member of your household or work with your physician to practice the cuff application. Incorrectly applied cuffs may result in inaccurate readings.
  • Page 17 Measurement of Pulse Rate and Blood Pressure To set the user and memory zone, proceed as follows: While in power off mode, press the “S” key to select user. Confirm your selection with the Power key to turn the power on and start to measure your blood pressure.
  • Page 18 The unit will automatically shut-off approximately 2 minutes. Note: 1. Users are recommended to use BPM925-LJB daily at a fixed time, frequency of usage from 1 to 3 times can be suggested from physician or doctor‟s advice. 2. Base on individual body condition the typical operation time takes...
  • Page 19 Hypertension Indicator This unit features our unique Hypertension Indicator. The World Health Organization has established globally accepted standards for the assessment of high or low blood pressure readings. The below chart should be considered only as a guideline, always consult with your physician or health care professional to interpret your individual results.
  • Page 20 Irregular Heartbeat Detector Your digital blood pressure monitor features an Irregular Heartbeat Detector. This feature allows users to accurately monitor blood pressure even if an irregular heartbeat should occur. When an irregular heartbeat “ ”is detected, the icon will appear on the display. Note: Please consult with your physician or trained healthcare professional for further information regarding an irregular heartbeat and if this symbol...
  • Page 21 Atrial Fibrillation (AFIB) This device is a blood pressure monitor that also analyses heart rate variability during measurement. While in power off mode, press Start/Stop AF mode measuring button (AF Power key) to measure your blood pressure and analyses heart rate variability. This feature allows users to accurately monitor blood pressure even if atrial fibrillation should occur.
  • Page 22 Memory Function Recalling Measurements in Memory: You can recall up to 100 measurements for each user, plus those average values stored measurements in memory to share with your physician or trained healthcare professional. If you press the M key, the unit will first display the average of last 3 currently stored measurements.
  • Page 23 When the number of readings exceeds 100, the oldest data will be replaced with the new record. Press the Power key to turn the unit off at any time when you check the stored measurements Clearing Measurements from Memory: From the memory mode, press and hold down the M key until the display shows CLr.
  • Page 24 Data Transferring This product is a arm type blood pressure monitor. Design without entering personal information. The device has a transmission function. During the transmission process, the measurement data is designed to be encrypted, and will not be tampered with unauthorized access nor retrieve user-related information.
  • Page 25 Error Codes Err Code Meaning Corrective Action No pulse or detect Take off heavy clothes and Err 00 pulses not enough. retry again. The cuff is not fastened correctly, The Arm cuff is not fastened cuff pressure leakage properly. Re- apply the cuff, Err 01 or inflation too low or and take a measurement...
  • Page 26 Troubleshooting Problem Probable Cause Recommended Action Nothing appears in Batteries are drained. Replace all batteries with the display even new ones. when the power is Battery are not correctly Reinsert batteries in the turned on. aligned with terminals. correct position. Low Battery Batteries are drained.
  • Page 27 Cleaning and Disinfecting • Only use a soft, damp cloth to clean the monitor. Please do not use thinner, alcohol, detergents or solvents. • The cuff can be cleaned carefully using a slightly damp cloth and mild soap solution. Do not completely immerse the cuff in water. •...
  • Page 28 Technical Specification • Measuring range : Blood Pressure : 40~255 mmHg Pulse Rate : 40~199 beats/min • Calibration Accuracy: Blood Pressure : ± 3 mmHg Pulse rate : ± 4% of reading • Operating environment : 10°C~40°C 15% to 85% relative humidity (non-condensing) 700-1060 hPa ambient pressure •...
  • Page 29 EMC Tables BPM925-LJB is intended for use in the electromagnetic environment specified below. The customer or the user of BPM925-LJB must make sure that it is used in such an environment. Guidance and manufacturer‟s declaration - Electromagnetic emissions CISPR 11...
  • Page 30 RF communications equipment (transmitters) and the BPM925-LJB can be requested from supplier using the contact information provided in this manual. However, it is advisable to keep the equipment at an adequate distance of, at least, 0.5 m...
  • Page 31 Explanation of Symbols Symbol Definition The CE marking with the Registration Number of the Notified Body. This denotes the compliance of Regulation (EU) 2017/745 Medical Device Manufacturer Authorized representative in the European Community Date of manufacture (YYYY-MM-DD or YYYY-MM) Batch code (YYMMWWWW) Serial number (YYMWWWXXXXX)
  • Page 32 Humidity limitation Atmospheric pressure limitation Caution Consult the instruction for use Disposal information: Should you wish to dispose of the article, do so in accordance with current regulations. Details are available from your local authority. WEEE 2012/19/EU Directives This product fulfilling the requirements of the RoHS Directive RoHS 2011/65/EU.
  • Page 33 You are legally required to dispose of the batteries. Importer Distributor Model Number Country of Manufacturer Unique Device Identifier Keep away from sunlight Electronic IFU available at http://www.avita.com.tw BPM925-LJBP-23042AV 2023-4-10...
