Summary of Contents for FLEETFLIX AI+ PRO
- Page 4 FleetFlix AI+ FleetFlix AI+ FleetFlix AI+...
- Page 5 FleetFlix AI+ FleetFlix AI+ FleetFlix AI+...
- Page 6 Calibrate/ Alert Button Alert Button The FleetFlix AI+ comes with a short record button on the rear panel of the camera. When pushed briefly, the FleetFlix AI+ camera will capture media from the internal and external cameras. When pushed for more than 3 seconds, an audio alert will be triggered.
- Page 7 FleetFlix AI+ FleetFlix FleetFlix AI+ Truck Mount Clip and Adhesive Tape Mounting Brackets FleetFlix AI+ Truck Mount Clip FleetFlix AI+ Truck Mount Clip and Adhesive Tap FleetFlix AI+ Truck Mount Clip...
- Page 8 (If camera comes pre-installed with SD and SIM cards skip to installing the cables.)
- Page 9 The FleetFlix AI+ dash cam supports automatic video recording to a Micro SD card after startup. The camera must use a Micro SD card provided by Fleet Hoster. If another SD card is used, the camera will not work. The SD card typically comes pre-loaded within the FleetFlix device but can be accessed if...
- Page 10 (If camera comes pre-installed with SD and SIM cards skip to installing the cables.) FleetFlix AI+...
- Page 11 Reference the vehicle's user manual to find the location of the OBD II connector. Locate the OBD port of the vehicle and directly connect with the port.
- Page 12 Tt-lOSTE� Fuse Box FLEETFLIX /\I+ INST/\LL/\TIDN GUIDE Connecting the OBD II Power Cable to the blade fuse holder cable Connect the other end of the OBD II Power Cable to the Blade Fuse Holder cable as shown in the diagram below.
- Page 13 *If utilizing one of our 4WOBDK or 4W9POBDK harnesses please reference the below layout guide for the correct port/plug installation* 4WOBDK Blue- Left Open for Diagnostics Green- For OBD Tracker/GO9 Purple- For FleetFlix Camera Red- To Vehicle Port 4W9POBDK Blue- Left Open for Diagnostics Green- For OBD Tracker/GO9...
- Page 14 � i=L __ Tt-lOSTE� FLEETFLIX /\I+ INST/\LL/\TIDN GUIDE Remove the right panel I/O cover. For details, refer to section 3.1. Feed the 12-pin connector of the 0BD II Power Cable through the hole on the right panel 1/0 cover. Feeding the 12-pin connector cable through the hole on the 1/0 cover Plugging in the 12-pin connector of the 0BD II Power Cable Reinstall the right pan el 1/0 cover.
- Page 16 Attach the adhesive tape mounting bracket onto the FleetFlix AI+. FleetFlix AI+ FleetFlix AI+ Truck Mount Clip Install the device in the center of the windshield below the rearview mirror. (it is recommended to use FleetFlix AI+ Alcohol to clean the glass before mounting the device.)
- Page 17 After installation is complete, the following measurements are needed: • Length from Camera Mount to Front of Vehicle (in) – the distance from the front lens of the camera and the front bumper • Width of Vehicle (in) – the total width of the vehicle at its widest point in front of the camera (typically wheel arch to wheel arch •...
- Page 18 Entering Measurements into FleetFlix AI+ Add-in Once the proper measurements are gathered, enter the measurements into the FleetFlix Add-in under the “Measurements” tab in the Cameras settings. To get to the “Measurements” tab, click “Cameras” under the Geotab FleetFlix Add-in.
- Page 19 CALIBRATION IS REQUIRED To Start Calibration The vehicle should be driven on the following road parameters: • Good contrast for lane markers • Capable of supporting 30+ mph for 3-5 minutes • Avoids hills or turns • Reasonable weather • Light traffic Step 1 While driving down the road, press and hold the calibrate/alert button (pictured below) on the camera for 3 seconds.
