BAIC BJ2030 2020 Series User Manual

page of 324

/ 324
Bookmarks

Advertisement

Quick Links

Download this manual

Foreword

Thank you for your purchase.

Please read the Manual carefully prior to the use of the vehicle for the first time. The Manual is applicable to BJ2030 series light-weight

off-road vehicles and their derived vehicles. The Manual will help you get familiar with the structure of the vehicle, various functions and

modes of use as well as the relevant provisions of the company as soon as possible. The user will lose the right to claim for any losses

arising from his use due to the failure to comply with the guiding opinion of the Manual or from the refit without the approval of the compa-

ny, and any application for warranty will be refused by the service provider authorized by the company. The contents included in the manu-

al will help you understand how to drive and maintain your vehicle correctly, allowing you to fully enjoy the fun of driving.

The Manual aims at providing the user with the guiding instructions relating to use and maintenance of BJ2021 and BJ2030 series light-

weight off-road vehicles and their derived vehicles. For specific configuration of the vehicle you purchased, please read your purchase

contract for more information. If you have any questions about this car and this manual,

please contact the authorized dealer of BAIC

In view of our company continuous retrofit and improvement of vehicles, the equipment and performance of subsequent models will be

changed without prior attention. Please do not compare the equipment and performance of vehicle purchased by you with those as de-

scribed in the User Instructions of any other version nor make any requests for supplementary equipment based on the differences be-

tween their both. If you have any questions about this car and this manual, please contact the BAIC authorized dealer

Drivers should strictly observe all laws and regulations relating to motor vehicles. The relevant laws and regulations currently in effect have

been fully considered and complied with when the Manual is prepared. However, some clauses herein may comply with the latest revised

laws and regulations when you purchase the vehicle.

When you resell the vehicle, please keep the manual in the vehicle where the manual is stored and remind the purchaser so that he/she

can obtain the relevant information in the manual.
