- Page 1 Airvine WaveCore Configuration Guide Part No: 800-00263-001 Revision: Oct 2024 2.6 SW Release 1.0.0.121...
- Page 2 Copyright Notice and Proprietary Information Copyright 2024. Airvine Scientific. All rights reserved. No part of this documentation may be used, reproduced, transmitted, or translated, in any form or by any means, electronic, mechanical, manual, optical, or otherwise, without prior written permission of Airvine Scientific. (“Airvine”), or as expressly provided by under license from Airvine.
- Page 3 Using Single Sign On (SSO) to Manage Both Radios ................. 14 Monitoring ............................... 16 Monitoring/Viewing General Device Status ..................16 Monitoring/Viewing Ethernet Port Status ..................18 Monitoring/Viewing WaveCore Wireless Radio Status ..............19 Monitoring/Viewing Management Wi-Fi Status ................. 21 Monitoring/Event ..........................22 Monitoring/Statistics......................... 23 Device Configuration ..........................
- Page 4 Configuration/User/User Management (add/change user accounts) ..........34 Configuration/User/Change Password ..................... 35 System ..............................36 System/Operations/Troubleshooting/Ping Tab ................. 36 System/Operations/Troubleshooting/Traceroute Tab ............... 36 System/Operations/Troubleshooting/Traffic Test ................37 System/Operations/Firmware Update ....................38 System/Operations/Firmware Update................... 40 SYSTEM/Operations/System Operations ..................41 Airvine WaveCore Configuration Guide Page 3...
- Page 5 WaveCore Configuration Guide: A guide that gives an overview of the device user interface • and explains the step-by-step procedures to configure, manage and monitor the device by using a Graphical User Interface.
- Page 6 CAUTION statements alert a possibility of damage to the system, software, or individual items or parts of equipment withing a system. However, this damage presents no danger to a person. NOTE A NOTE provides a tip, guidance, or advice and can emphasize important information. Airvine WaveCore Configuration Guide Page 5...
- Page 7 WaveCore devices are shipped with standard 3-inch mounting brackets. Optional 5-inch mounting brackets can be separately ordered along with other optional accessories listed later in this manual. The WaveCore devices are powered by 12 VDC, PoE, or both. This allows for power supply redundancy to support failsafe operation.
- Page 8 WaveCore Deployment Scenarios There are many deployment scenarios that WaveCore is designed to handle, many of which involve making wireless connections through walls or ceilings. Cement and concrete walls and floors are commonly used in many commercial buildings. Deploying new networks or expanding existing ones in these environments often involves high costs and significant delays due to the need to run network cables through obstacles and across long interior spans.
- Page 9 WaveCore Models There are currently two versions of the WaveCore product. Part Number Description WC-1000RH-US This is a complete point-to-point wireless bridge link that contains two 1000RH-US Wireless Radio Devices, and two SHORT Wall/Ceiling Mounting Brackets. This model is designed to be operated only in the US and Canada.
- Page 10 Factory-Resetting a WaveCore Resetting Using the Reset Button The WaveCore has a recessed reset button next to the RJ45 Ethernet port. Use this button to reset the WaveCore: Press for less than five seconds to soft reboot the WaveCore. Press for longer than five seconds to factory-reset the WaveCore.
- Page 11 The WaveCore uses an intuitive Web-Based GUI for configuration and monitoring. A standard Internet browser running on a PC, Notebook, or mobile device is all that is needed to manage a WaveCore device. To access the VineManager Web GUI, enter the applicable Management IP Address into the browser address bar.
- Page 12 Note 1: The Web GUI supports both http and https connections. For https connections, the web server of the WaveCore device uses a self-signed certificate. Thus, you need to ignore the security warnings on the browser to bypass the validation.
- Page 13 (example: Germany) and reboot the system by navigating to System- Operations-System Operations pane and click “Reboot”. Selecting a country of operation is an important first step as it configures the radio to operate in accordance with radio regulatory requirements for that specific country. Airvine WaveCore Configuration Guide Page 12...
- Page 14 The highlighted Tab indicates current menu / screen Wireless Link Status “<” indicates sub-menus Content Pane for the selected menu on the Navigation Pane Ethernet Port throughput history Main Navigation Pane Wireless throughput history Airvine WaveCore Configuration Guide Page 13...
- Page 15 VineManager allows management of both sides of the wireless link with a single sign-on to one of the radios. Once a wireless connection is made between two WaveCore radios, it is possible to log on to one radio (Near End Radio) and then manage the other Far End Radio over the wireless link without having to manually re-logon to the Far End Radio).
- Page 16 To select the other device to manage from main dashboard screen, either select the other device’s MAC address from the top center drop down menu (a4:f9:e4:20:00:ao) or mouse click on the other device ICON on the WaveCore Network Connection Dashboard. Once the other node is selected, you are now managing the other device (a4:f9:e4:20:00:a0 / 192.168.0.251) and that device’s ICON will now be underlined RED indicating that it is now being...
- Page 17 Monitoring The Monitoring Tabs allow you to view (but not change) the WaveCore system parameters and to view WaveCore performance metrics. Monitoring/Viewing General Device Status Navigate to MONITORING/General to view general device configurations and status. Airvine WaveCore Configuration Guide Page 16...
- Page 18 Port Target device logging server port NTP Settings Status Network Time Protocol—enabled or disabled Primary Server Selected NTP primary server name Backup Server Selected NTP backup server name TimeZone Customer-selected uniform standard time zone Airvine WaveCore Configuration Guide Page 17...
- Page 19 Monitoring/Viewing Ethernet Port Status Navigate to MONITORING/Ethernet to view Wired Ethernet Port and VLAN Settings. Airvine WaveCore Configuration Guide Page 18...
- Page 20 Number of errored packets sent Drop In Number of received packets dropped Drop Out Number of received packets sent Monitoring/Viewing WaveCore Wireless Radio Status Navigate to Monitoring/Device/Wireless to view important WaveCore Wireless Link settings and real-time statistics. Airvine WaveCore Configuration Guide Page 19...
- Page 21 RX Received Signal Power. Higher (less negative) numbers indicate a stronger signal and higher over-the-air data rates TX Power WaveCore systems have 4 transmitters. This value indicates the TX Power Setting for each of the 4 transmitters. Device Type Indicates Device Type of the unit: Controller Node (CN) or Subordinate Node (SN) Connected Time Total duration of time that the wireless connection has been made in seconds.
- Page 22 IP Address used to access VineManager Web GUI when connected to the WaveCore management Wi-Fi radio. Once connected to the WaveCore management Wi-Fi radio, enter this URL into your web browser navigation bar and you will be presented with the VineManager log on screen.
- Page 23 Monitoring/Event Navigate to Monitoring/Device/Event page to view WaveCore event/alarm log and sort by date, category, severity, type, and message. Airvine WaveCore Configuration Guide Page 22...
- Page 24 Monitoring/Statistics Navigate to MONITORING/Statistics to view historical transmit and receive data throughput on each of three data interfaces: Main Wireless Link, Ethernet Port RJ45, and Ethernet Port SFP+. Airvine WaveCore Configuration Guide Page 23...
- Page 25 The system can be rebooted by either navigating to SYSTEM/System Operations screen and pressing the “Reboot” button or by pressing the WaveCore physical reset button located under the removeable interface bay cover for less than 5 seconds.
- Page 26 Enter a WaveCore location (optional) Country Code Select the country code from the drop-down list (required) Note: Certain WaveCore models like 1000RH-US will not allow changes to the country code. Note The country code must be set identically on both radios (CN and SN).
- Page 27 Select Enable or Disable (default) SYSLOG server logging Click “Save”. Server Enter the IP address for the syslog server Protocol Select UDP or TCP for the syslog server connection Port Enter the port number for the syslog server connection (optional) Airvine WaveCore Configuration Guide Page 26...
- Page 28 Select the time zone from the drop-down menu Note: The WaveCore node displays the current local date and time at the bottom of the NTP Settings screen. Note: If a NTP server is not configured, the system will adopt the time of your local client device that is accessing the system.
- Page 29 Configuration/Network/Ethernet In the Network sections, you can configure and change the management IP of the WaveCore device, define a management VLAN, and change Ethernet Port and VLAN settings. Configuration/Network/Ethernet/Management IPv4 Settings Navigate to CONFIGURATION/Network/Ethernet/Management IPv4 Settings Tab to update the WaveCoremanagement IP settings.
- Page 30 Configuration/Network/Ethernet/Port and VLAN Settings Navigate to CONFIGURATION/Network/Ethernet/Port and VLAN Settings Tab to update the WaveCore wired Ethernet Port and VLAN setting. To update these settings, select or enter the required parameter values. The main Port and VLAN Settings tab indicates the current settings status of each wired Ethernet port.
- Page 31 Setting WaveCore Ethernet Parameters Management IPV4 Settings Management IP Type IP address assignment type - Static or DHCP Management IP Management IP address (required) Address Subnet Mask Management IP subnet mask (optional) Default Gateway Default gateway (optional) Primary domain name server (optional)
- Page 32 WaveCore devices are sold as a complete link. Each radio is configured in the factory to communicate with the other radio so this parameter should always be configured. In the case one of the radios becomes defective and needs to be replaced, the replacement radio will not be pre-configured and as such, each radio in the link will need to be configured with the MAC address of the other node in order to re-establish the link.
- Page 33 6745 6585 6625 6665 6585 6625 6745 6665 6705 6745 6585 6745 6905 6745 6785 6825 6745 6785 6905 6825 6865 6905 6745 6905 7065 6905 6945 6985 6905 6945 7065 6985 7025 7065 Airvine WaveCore Configuration Guide Page 32...
- Page 34 Configuration/Network/Wi-Fi (2.4 GHz Local Mgmt. Radio) Navigate to CONFIGURATION/Network/Wi-Fi to update the settings for the local management Wi-Fi radio. The local management Wi-Fi radio is used to locally access and manage the WaveCore device. The maximum range of the Wi-Fi radio is about 20 meters.
- Page 35 To change the password of a different account (from the one you are currently logged in as), you must first log out, then log on to that account and navigate to CONFIGURATION/User/Change Password to change the password. Airvine WaveCore Configuration Guide Page 34...
- Page 36 Configuration/User/Change Password Navigate to CONFIGURATION/User/Change Password to change the current account password. Airvine WaveCore Configuration Guide Page 35...
- Page 37 To run, enter remote device’s IP, and click “Test”. System/Operations/Troubleshooting/Traceroute Tab Navigate to SYSTEM/Operations/Troubleshooting/Traceroute Tab to run the internal traceroute utility to test connections to a remove device’s IP. To run, enter remote device’s IP, and click “Test”. Airvine WaveCore Configuration Guide Page 36...
- Page 38 Test traffic utilizes the TCP protocol. Running the traffic test can be a useful diagnostic before and after installing the WaveCore units. To run, enter the Direction of the traffic test and Duration of the test then click “Start Wireless Traffic”.
- Page 39 System/Operations/Firmware Update Navigate to SYSTEM/System/Operations/Firmware Update to upgrade and manage the firmware. Up to two images of VineOS firmware can be locally stored in the WaveCore device (a Primary Image and a Backup Image). The Current Firmware Information screen shows which VineOS images are stored in the device;...
- Page 40 “Set as Primary”. The table will now show the “Inactive” image as “Primary”. When you reboot, that Inactive image will now show as “Active” and “Primary” in the table. Airvine WaveCore Configuration Guide Page 39...
- Page 41 System/Operations/Firmware Update To upload a new VineOS firmware image to the device, WaveCore allows two methods: 1. Upload an image from a remote site/server using: HTTP/HTTPS, TFP, or TFTP. 2. Upload an image as a Local File directly from your connected device (typically a PC or Laptop).
- Page 42 • saved or to write VineOS firmware images into permanent system memory. Factory reset the system which resets the WaveCore to factory default configuration settings. • While factory resetting the system will result in losing all of your configuration settings but will boot back up and run the current Primary firmware image.
