- Page 1 Preset12, Preset18, Preset24 OWNERS MANUAL Doug Fleenor Design 396 Corbett Canyon Road Arroyo Grande, CA 93420 (805) 481-9599 Software Version 1.2 January 2024...
- Page 2 PRODUCT DESCRIPTION The Preset12 product line consists of Preset12, Preset18, and Preset24. Throughout this manual, the Preset12 name refers to all three models with variations called out where appropriate. Preset12 is a lighting control station that uses the DMX512 control protocol to capture and play back up to twelve, eighteen, or twenty-four static looks.
- Page 3 0.156” ( ”) countersunk holes for #6 screws. Preset12: Two holes on 3.281” (3 ”) vertical centers. Preset18, Preset24: Four holes on 3.281” (3 ”) vertical by 1.812” (1 ”) horizontal centers. 6-32 x 7/8” oval head machine screws are included.
- Page 4 INSTALLATION WIRING Signal and power are connected to Preset12’s flying leads. Five Wago Lever Nuts are provided for this purpose. The supplied 3-position nuts are rated for 12 to 22 gauge wires. Wires are to be stripped to 7/16” (11mm) before insertion into the nut, with the lever up. Closing the lever secures the wire connection.
- Page 5 SET UP Prior to installation, power may be supplied to Preset12 via the bottom mounted USB connector. Smart chargers that try to communicate with the device being charged might not work, try a different charger, or use a power-only cable. Entering set up requires a power up reset of the processor.
- Page 6 Action upon loss of external DMX512 One of the attractions of Preset12 is the ability to sense the presence of an external DMX512 source and back off when one is present. Upon the loss of an external DMX512 signal, Preset12 may be configured to hold the last look generated by the external source or fade to the last look generated by Preset12 (prior to the external source taking over).
- Page 7 To Set Canceling Groups to Predefined Options Enter set up mode. Press and release button 1. LEDs will stop chasing. Press and release the button for one of the following predefined options: 1) All presets grouped together. Buttons are ‘radio’ buttons; only one preset may be on at a time.
- Page 8 To Set Lock Status for Individual Presets Enter set up mode. Press and release button 9. LEDs will stop chasing. Press and release the preset button for which the lock mode is to be set. Press and release the button for one of the following configurations: 1) This preset is unlocked.
- Page 9 OPERATION Buttons There are twelve, eighteen, or twenty-four preset buttons. The buttons are non-tactile switches (no discernable ‘click’) with about a hundredth of an inch of travel; they are not touch sensitive. They must be pushed, not just touched. Each button has four functions. Quick Press Upon initial press, the current look is saved for future use.
- Page 10 The red ‘offline’ LED will blink when Preset12 is holding the external source’s last look, until a Preset12 button is pressed. The blue LEDs indicate certain operations: Blue LEDs chasing: Preset12 is in set up mode. All blue LEDs flash for ½ second: confirms preset has been recorded. Left column of blue LEDs flash followed by the second column (uh-uh): preset is locked.
- Page 11 Fleenor Design (at the customer’s expense) for service. Doug Fleenor Design will repair the unit and return it to the customer (at Doug Fleenor Design’s expense). If a trip is necessary to the customer’s site to solve a problem, the expenses of the trip must be paid by the customer. Note that this warranty covers Manufacturing Defects.
- Page 12 Preset12 Cheat Sheet To Enter Set Up Remove power. Press firmly and hold buttons 1 and 7. Apply power. Release buttons. LEDs will chase to confirm set up mode. To Set Preset12 to Factory Defaults Press 12 then press 7. This does not erase the presets. To Set Predefined Grouping Options (Factory default is all in the same group) Press 1 then: Press 1 to set all presets to the same group (Original Preset 10 functionality).
