WINE CELLAR

User's Guide

Please read this guide thoroughly before operating and

keep it handy for reference at all times.

VIN CAVE

Guide d'utilisation

Lire le manuel en entier avantd'utiliser l'appareil et gardez

le manuel pour référence ultérieure.

VINO SÓTANO

Guía para el Uso y Cuidado

Lea detenidamente estas instrucciones antes utilizar el

frigorífico y guárdelas como referencia para el futuro.

Models / Modèles / Modelos

GR-W141BXG/GR-W101BXG/GR-W061BXH

P/No.MFL38422621

Need help?

Do you have a question about the GR-W141BXG and is the answer not in the manual?

Questions and answers

Summary of Contents for LG GR-W141BXG

Page 1 Lire le manuel en entier avantd’utiliser l’appareil et gardez le manuel pour référence ultérieure. VINO SÓTANO Guía para el Uso y Cuidado Lea detenidamente estas instrucciones antes utilizar el frigorífico y guárdelas como referencia para el futuro. Models / Modèles / Modelos GR-W141BXG/GR-W101BXG/GR-W061BXH P/No.MFL38422621...
Page 2 Temperature regulation and related indication..........14 Correct Way to Wine Storage................16 Cleaning Cleaning ......................18 Confirmation These are Not Faults..................19 Please confirm the following before calling for service........20 Reference Tips to help you enjoy your refrigerator.............21 Energy-Saving Method..................22 Product Specifications..................22 Thank you for purchasing LG products.
Page 3 Safety Instruction Safety notes are given for safe and correct use of the product. • Safety notes are divided into “warning” and “caution” as described below. • After reading, keep this manual in a convenient location for easy reference. • w is an indication of a dangerous condition under specific conditions.
Page 4 w w Warning (For Power Connection) Clean dust off the power plug regularly to Do not place any foreign objects into the reduce the risk of fire. ventilation louvers. This could result in an electric shock or injury. Do not damage, puncture, kink, stretch, or Do not modify or extend the Power Cord.
Page 5 w w Warning (For Refrigerator Operation) Do not store drugs or chemicals in the Keep refrigerator away from fire. refrigerator. The Wine Cellar is not intended for the preservation of such temperature sensitive items. Deterioration or undesirable reactions may occur. Do not use flammable or explosive sprays If you detect a gas leak, do not touch the near the refrigerator.
Page 6 Warning (Important Safety Instruction) Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
Page 7 w w Caution When removing the power plug, grasp the Do not use this product when the power cord plug firmly and pull from the socket. Never or plug are damaged or fit loosely in the pull the cord. socket hole is loose. These conditions may cause a short circuit resulting in fire.
Page 8 Installation 1. Choose a Good Location Keep proper space Maintain proper distances between the refrigerator and items around it. More than • To ensure proper air circulation around the fridge- 5cm to back freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall.
Page 9 Installation 3. Grounding (Earth Ground) Grounding must be done to prevent electric shock. 220 volts AC Grounded Outlet (earth ground) connections • If the 220V outlet has a properly wired ground connection, no additional grounding is needed. grounding line Connections without Grounded Outlets (earth ground) •...
Page 10 Movement, transportation and voltage change Moving the refrigerator Before moving 1. Remove all contents from the refrigerator. 2. Disconnect the power plug. 3. Secure loose parts, such as shelves, with tape. 4. Raise the refrigerator a little and screw the adjustable feet in as far as possible. During transportation 1.
Page 11 Part identification GR-W141BXG Glass hanger Wine Bottle holder Operation panel Light bulb • Light bulb inside the wine cellar can be turned on or off by pressing the button on the operation panel. • Light bulb inside the wine Wine shelf cellar will automatically turn off after one hour.
Page 12 Part identification GR-W101BXG Light bulb Operation panel • Light bulb inside the wine cellar can be turned on or off by pressing the button on the operation panel. Wine shelf • Light bulb inside the wine cellar will automatically turn off after one hour. Top/Bottom Separation Panel •...
Page 13 If this happens When cooling capability weakens When light bulb malfunctions When a large amount of wine is placed into the Contact with the shop or after-sales service refrigerator, more time is needed to reach the center. desired temperature and get stabilized. (Sudden changes in temperature are the main reason for damage to wine flavor) When power is off...
Page 14 Temperature regulation and related indication • GR-W061BXH This model is not a power button. The regulated temperature range is 6°C to 18°C Lighting bulb button Push for ON, Push again for OFF (Light wil automatically turn temperature Indication of wine off after one hour.) control button category...
Page 15 Temperature regulation and related indication • GR-W101BXG/W141BXG The regulated temperature range is 6°C to 18°C Lighting bulb button Lock/Unlock Function Indication of Push for ON, Push again for Indication of “TOP” “BOTTOM” set To change the temperature, press OFF (Light wil automatically turn set temperature temperature the button for 3 seconds.
Page 16 Correct Way to Store Wine Before Storage At the Time of Setting... First clean the Thoroughly clean the refrigerator interior. refrigerator interior thoroughly Store wine Put wine into the refrigerator around 4 hours after 4 hours later power is turned on. When outdoor temperature is high, as in summer, the cooling time may exceed 4 hours.
Page 17 • Bottom Shelf: Bottom shelf can hold 4 bottles, maximum 9 bottles. Wine Storage in the Decoration Cabinet GR-W141BXG • Bottles with remaining wine inside should be recorked for storage. • Bottles may break if the cork is forced into them.
Page 18 Cleaning Clean the shelves and the refrigerator interior thoroughly once every year with power plug disconnected. 1. Before cleaning Power plug must be pulled out first to secure the cleaning. 2. Please do not use the following articles for cleaning Please do not use articles that can damage the refrigerator surface and its accessories, which include abrasive grain, petroleum, benzene, chlorohydric acid,...
Page 19 These Are Not Faults There are abnormal noises inside the refrigerator • Sound of coolant flowing. There are cooling pipes in the rear, which often make noises. But that is not a fault. Bulb is off when the door is either closed or opened •...
Page 20 Please confirm the following before calling for service Situation Please check Measures The refrigerator • Is power supply cut? • Check if other electric appliances does not operate operate or not. • Is power plug inserted into socket? • Re-insert the plug properly. •...
Page 21 Tips to help you enjoy your refrigerator At the time of power failure When top decoration cloth cover is used: Please do not open and close the door frequently. When top decoration cloth cover is used at the refrigerator top, make sure the cloth corners are not squeezed by the refrigerator door.
Page 22 Product Specifications The items (appearance and specifications) listed in this guide may vary due to constant product improvements. Type GR-W061BXH GR-W101BXG GR-W141BXG Category Efficient Capacity 135 l 214 l 283 l Capacity Storage 41bottles (56bottles)

This manual is also suitable for:

Gr-w101bxg Gr-w061bxh
