BUILT-INOUTDOO

OUTDOOR GRILL

Installation Instructions

s andUse &CareGuide

essories or service, call: 1-300-799-787 MON-FRI, 9:30am-3:00pm

For questions about features, operation/performance, parts, acce

or visit our website at www.Kitch

tchenaidgrills.com.au

740/750-0780GH

Need help?

Do you have a question about the 740-0780GH and is the answer not in the manual?

Questions and answers

Summary of Contents for KitchenAid 740-0780GH

Page 1 BUILT-INOUTDOO OUTDOOR GRILL Installation Instructions s andUse &CareGuide essories or service, call: 1-300-799-787 MON-FRI, 9:30am-3:00pm For questions about features, operation/performance, parts, acce or visit our website at www.Kitch tchenaidgrills.com.au 740/750-0780GH...
Page 2 T ABLE OFCONTENTS CONTENTS Check and Adjust the Burners ……………………………………. 18 OUTDOOR GRILL SAFETY ……………………………………… 3 OUTDOOR GRILL USE ………………………………………….. 19 INSTALLATION REQUIREMENTS ……………………………… 5 Using Your Outdoor Grill ………………………………………… 19 Tools and Parts …………………………………………………… Using Your Rotisserie Burner …………………………………… 21 Location Requirements.
Page 3 OUTDOOR GRILL GRILL SAFETY WARNING DANGER 1. Do not store or use gasoline or other If you smell gas: flammable liquids or vapors in the 1. Shut off gas to the appliance. vicinity of this or any other appliance. 2. Extinguish any open flame. 3.
Page 4 IMPORTANT SAFETY SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electrical shock, The LP gas supply cylinder to be used must be: ■ injury to persons, or damage when using the outdoor cooking Gas bottles with a “POL” low pressure connection are to be gas appliance, follow basic precautions, including the used with this BBQ.
Page 5 INS T ALL A TION R REQUIREMENT S Tools and Parts Location Requirements Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed WAR NIN G here. Tools Needed Tape measure Pipe wrench ■...
Page 6 ProductDimensions Built-InOutdoor Grill Enclosure WARNING Fire Hazard Do not install grill on or near combustible materials. Doing so can result in death or fire. The enclosure for the built-in outdoor grill is to be a minimum of 11" (28.0 cm) high x 23" (58.4 cm) deep x 30" (76.2 cm) wide This built-in outdoor grill is only for installation in a built-in enclosure constructed only of noncombustible materials.
Page 7 Cabinet Cutout Dimens Dimensions The illustration below includes cutout dimensions and minimum spacing req quirements. The illustration is for reference. The design of your cabinet layout can be personalized, but the dimensions for the cutouts a and minimum spacing must be followed. Center or support surfaces must be level.
Page 8 To ensure that the grill operates properly, it is recommended ■ that the island have ventilation on all 4 sides as shown in the Natural Gas Conversion following illustration. The ventilation holes should be as diagrammed to ensure adequate ventilation for your grill and Natural Gas Pressure Regulator Location Measurements island.
Page 9 Refer to the model/serial rating plate for information on the type Any brand of 9 kg LP gas fuel tank is acceptable for use with the grill of gas that can be used. If this information does not agree with provided they are compatible with the grill tank tray.
Page 10 REPLACEMEN REPLACEMENT P ARTS...
Page 11 Part Part (description) Warranty Quantity Part Part (description) Warrant Quantity Number Coverage Number Coverage Main lid Main lid bracket, right module Main lid screw with screw Flange, right cover Main lid handle tube Front baffle Temperature gauge housing Heat shied bracket Temperature gauge Grease cup Warming rack...
Page 12 INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS UnpackGrill 9. Install the two battery as shown in below WAR NIN G Excessive Weight Hazard Use two or more people to move and install grill. Failure to do so can result in back or other injury. Unpack Grill 1.
Page 13 Grease Cup Bracket Installation InstallGrill 1. Loosen and remove the 4 screws preassembled on the grease Place grill into outdoor enclosure, but leave enough room in the back to cup bracket. connect to the gas supply. LP Gas Installation 1. Check that the LP gas pressure regulator/hose assembly is positioned under the grill (as shown in the following illustration) and is not pinched or kinked.
Page 14 MakeGasConnection Connection NOTE: If grill is to be converted to Natural gas, follow instructions in To Connect the 9kgLP Gas Fuel Tank: the “Gas Conversions” section. 1. Check that the 9kg LP gas fuel tank is in the “Off” position. If not, turn the valve clockwise until it stops.
Page 15 GAS CONVERSIONS CONVERSIONS 5. Use an adjustable wrench to remove the LP gas pressure regulator/ Gas Connection to Natural Gas hose assembly from the 90° brass adapter. WARNING Explosion Hazard Use a new CSA International approved “outdoor” gas supply line. Install a shut-off valve.
Page 16 3. Connect the quick connector on the other end of the 10 ft (3.0 m) PVC flexible gas supply hose to the rigid Natural gas supply pipe (B). A. Main burner orifice IMPORTANT: Check that the orifice is properly installed inside of the gas valve.
Page 17 2. Remove the access cover at the back of the grill by removing the 6 5. Take out the orifice support, and then use a 6 mm socket and wrench screws at the back of firebox. or 6 mm nut driver to remove the LP orifice at the end of the supply pipe.
Page 18 CheckandAdjus Adjust the Burners The burners are tested and factory-set for most efficient operation. If flame is noisy or lifts away from burner (too much air), turn air However, variations in gas supply and other conditions may make minor shutter adjustment screw clockwise. adjustments to air shutter or low flame setting necessary.
Page 19 OUTDOOR GRIL GRILL USE This manual covers several different models. The grill you have purchased ma may have some or all of the features listed. The locations and appearances of the features shown here may not match those of your model. Control Panel D.
Page 20 Prepare the Gas Supply Manually Lightingthe Main Grill 1. Open the hood completely. Do not light burners with the hood 1. Do not lean over the grill. closed. 2. Remove the manual lighting extension (see following illustration) and attach a match to the split ring. Turn the Gas Supply On 1.
Page 21 5. Push in and turn the control knob to IGNITE/ON. Hold this knob in for 10 seconds after the burner is lit. You will hear the “snapping” UsingY our RotisserieBurner sound of the spark until after the knob is released. A Rotisserie kit can be purchased as an accessory for the grill.
Page 22 ROTISSERIE CHART Shorten the preheat time when grilling high-fat cuts of meat or Use a portable meat thermometer to check internal doneness of the food. • poultry, such as chicken thighs. This will help reduce Turn off rotisserie burner when meat thermometer reads 5°F/3°C lower flare-ups.
Page 23 Diagrammatical Representation of “OUTDOOR AREAS OUTDOOR AREAS” This appliance shall only be used in an above ground open-air situation with natural natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and and natural convection. Any enclosure in which the appliance is used shall comply with one of the following: An enclosure with walls on all sides, but at least one permanent opening at ground level and...
Page 24 Grilling gChart When 2 temperatures are listed, for example: Medium to Medium- Knobs have High, Medium and Low settings for flame adjustment. ■ ■ Low, start with the first and adjust based on cooking progress. Heat settings indicated are approximate. ■...
Page 25 COOKING METHOD/ TIME FOOD INTERNAL TEM TEMP. SPECIAL INSTRUCTIONS BURNER SETTING (total minutes) Fillets, Steaks, Chunks DIRECT 4-6 per Grill, turning once. Brush grill with Halibut,Salmon, Swordfish, 8 Medium oil to keep fish from sticking. ½" (1.3 cm) Remove when inside is opaque and oz (0.25 kg) thickness of fish flaky with skin easily removed.
Page 26 OUTDOOR GRIL GRILLCARE GRILL GRATES Replacingthe IgniterBattery If igniters stop sparking, the battery should be replaced. IMPORTANT: To avoid damage to grill grates, do not use a steel or fiber scraper. Immediately after you are finished cooking, loosen food 1. Unscrew igniter button cap counterclockwise to remove. soil with a brass bristle brush.
Page 27 BURNERS ROTISSIERE BURNER Cleaning Method: Cleaning Method: 1. Light the rotisserie burner. See the “Using Your Rotisserie Burner” Clean the exterior of the burner with a wire brush. ■ section. Clear any clogged burner ports with a straightened paper clip. ■...
Page 28 Low heat TROUBLESHOOTING LP Gas: For outdoor grills using a 9 kg LP gas fuel tank, slowly open the tank Grill will not light valve. NOTE: If flow limiting device activates, your grill may not light. If your Is the 9 kg LP gas fuel tank valve turned off? ■...
Page 29 LIMITED W W ARRANTY Nexgrill warrants to the original consumer-purchaser only that this product ( (Model #740/750-0780GH) shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for home use for the periods indicated below beginning on the date of purchase. The manufacturer reserves the right to require photographic evidence of damage , or that defective parts be returned, postage and or freight pre-paid by the consumer, for review and examination.
Page 30 All consumer returns, parts orders, general questions, and troubleshooting assistance assistance can be acquired by calling 1-300-799-787 ®/™ ©2016 KitchenAid KitchenAid. All rights reserved. 740/750-0780GH 9 / 16 Manufactured under license by Nexgrill Nexgrill Industries, Inc., Chino, CA. © 2016.
