Printed Matter No. 9839 0757 01
Publication Date 2020-03-03
Valid from Serial No. A3650001
WP 30-12
WP 30-20
WP 30-30
WP 30-45
WP 30-60
WP 30-75
WP 30-90
Read all safety warnings and instructions
Failure to follow the safety warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
8202078100
8202078101
8202078102
8202078103
8202078104
8202078105
8202078106
WARNING
WP-30
Product Instructions
Balancer
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Atlas Copco WP-30
Summary of Contents for Atlas Copco WP-30
- Page 1 WP-30 Printed Matter No. 9839 0757 01 Balancer Publication Date 2020-03-03 Valid from Serial No. A3650001 Product Instructions WP 30-12 8202078100 WP 30-20 8202078101 WP 30-30 8202078102 WP 30-45 8202078103 WP 30-60 8202078104 WP 30-75 8202078105 WP 30-90 8202078106 WARNING...
- Page 2 Installing the balancer................ 9 Service ........................ 10 Maintenance Instructions................ 10 Servicing and inspection.............. 10 Replacing the spring assembly............... 10 Replacing the wire drum ................. 11 Replacing the balancer housing .............. 12 Replacement kits .................... 12 Replacing the wire .................. 13 © Atlas Copco Industrial Technique AB - 9839 0757 01...
- Page 3 ■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions.
- Page 4 Atlas Copco website. Please visit: www.atlascopco.com. Safety Data Sheets MSDS/SDS The Safety Data Sheets describe the chemical products sold by Atlas Copco. Please consult the Atlas Copco website for more information www.atlascopco.com/sds. Country of Origin For the Country of Origin, please refer to the information on the product label.
- Page 5 Static test coefficient = 1.5 Lifting capacity Cable/hose travel Weight Product no. 8202078100 12-20 14.8 8202078101 20-30 15.2 8202078102 30-45 16.9 8202078103 45-60 17.3 8202078104 60-75 18.7 8202078105 75-90 19.7 8202078106 90-100 19.9 © Atlas Copco Industrial Technique AB - 9839 0757 01...
- Page 6 Product Information WP-30 Technical Product Data Technical Product Data can be found on either ServAid, or the Atlas Copco website. Please visit: https://servaid.atlascopco.com or www.atlascopco.com. © Atlas Copco Industrial Technique AB - 9839 0757 01...
- Page 7 Locking the wire drum The drum lock blocks the wire drum. When the wire drum is locked it is possible to replace the wire with- out decreasing the spring tension. © Atlas Copco Industrial Technique AB - 9839 0757 01...
- Page 8 Put the clamp back on the wire wedge. Tighten the wire end with the supplied ferrule or a clamp in accordance with DIN 3093 Pts. 1 to 3. Cut the remaining wire end straight off. © Atlas Copco Industrial Technique AB - 9839 0757 01...
- Page 9 Make sure that the auxiliary chain is not too long or too short to interfere with the balancer across its entire working area. Attach the workload to the snap hook at the cable end. Adjust the workload, see “Adjusting the workload”. © Atlas Copco Industrial Technique AB - 9839 0757 01...
- Page 10 Remove the balancer housing cover. Remove the small gear wheel cover above the endless screw. Remove the wire drum cover. Remove the circlip at the gear wheel using a circlip pliers. © Atlas Copco Industrial Technique AB - 9839 0757 01...
- Page 11 If applicable, adjust the position of the feather key by turning the gear wheel. Make sure that the shaft ring groove is visible. Put the circlip back in position on the shaft ring groove using a circlip pliers. © Atlas Copco Industrial Technique AB - 9839 0757 01...
- Page 12 Damaged or worn parts may cause injury or damage. Replace worn or damaged parts. Only use original parts from approved distributors or service centres. ► Always follow the product instructions when replacing parts! © Atlas Copco Industrial Technique AB - 9839 0757 01...
- Page 13 WARNING Risk of Injury A change of the workload weight can cause unexpected movements and injury. Do not change the workload weight when replacing the wire. ► 11. Unlock the wire drum. © Atlas Copco Industrial Technique AB - 9839 0757 01...
- Page 16 Original instructions © Copyright 2020, Atlas Copco Industrial Technique AB. All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. Atlas Copco Industrial This applies in particular to trademarks, model denominations, part numbers Technique AB and drawings.
