- Page 1 WP-10 Printed Matter No. 9839 0755 01 Balancer Publication Date 2020-03-03 Valid from Serial No. A3650001 Product Instructions WP 10-3 8202077900 WP 10-4.5 8202077901 WP 10-6 8202077902 WP 10-9 8202077903 WP 10-13 8202077904 WP 10-16 8202077905 WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
-
Page 2: Table Of Contents
Adjusting the wire extension length ............ 8 Service ........................ 9 Maintenance Instructions.................. 9 Servicing and inspection................ 9 Replacing the wire drum ................... 9 Replacing the spring .................. 10 Replacing the balancer housing .............. 10 Replacement kits .................... 11 Replacing the wire .................. 11 © Atlas Copco Industrial Technique AB - 9839 0755 01... -
Page 3: Product Information
■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions. -
Page 4: Servaid
For further Technical Information, please contact your local Atlas Copco representative. Safety Data Sheets MSDS/SDS The Safety Data Sheets describe the chemical products sold by Atlas Copco. Please consult the Atlas Copco website for more information www.atlascopco.com/sds. Country of Origin For the Country of Origin, please refer to the information on the product label. -
Page 5: Main Components
WP-10 Product Information Main components Nameplate Suspension hook Auxiliary chain attachment Auxiliary chain Wire stop buffer Wire clamp Wire wedge Ferrule Endless screw Drum lock © Atlas Copco Industrial Technique AB - 9839 0755 01... -
Page 6: Technical Data
8202077902 6-10 8202077903 9-14 8202077904 13-17 8202077905 16-21 Technical Product Data Technical Product Data can be found on either ServAid, or the Atlas Copco website. Please visit: https://servaid.atlascopco.com or www.atlascopco.com. © Atlas Copco Industrial Technique AB - 9839 0755 01... -
Page 7: Installation
Unlock the wire drum by turning the drum lock fixing pin back to the start position. Make sure that the workload is attached and the spring tension is adjusted before unlocking the drum. © Atlas Copco Industrial Technique AB - 9839 0755 01... -
Page 8: Installing The Balancer
WARNING Risk of Wire Damage Risk of wire damage if the wire extension length is extended too far. Do not pull on the wire when the end stop is reached. ► © Atlas Copco Industrial Technique AB - 9839 0755 01... -
Page 9: Service
If necessary, use a rubber hammer to drive the shaft through the gear wheel. 10. Remove the brass washer. 11. Unwind and remove the wire. 12. Replace the wire drum. © Atlas Copco Industrial Technique AB - 9839 0755 01... -
Page 10: Replacing The Spring
Use new washers for the housing cover and apply a small amount of threadlocker to the screws. Adjust the spring tension, see “Adjusting the load”. Replacing the balancer housing Dismantling Retract the wire. © Atlas Copco Industrial Technique AB - 9839 0755 01... -
Page 11: Replacement Kits
Make sure that the wire drum is correctly locked. ► Remove the workload. Pull out the wire end through the balancer housing slot by pushing the opposite wire end. © Atlas Copco Industrial Technique AB - 9839 0755 01... - Page 12 WARNING Risk of Injury A change of the workload weight can cause unexpected movements and injury. Do not change the workload weight when replacing the wire. ► 11. Unlock the wire drum. © Atlas Copco Industrial Technique AB - 9839 0755 01...
- Page 16 Original instructions © Copyright 2020, Atlas Copco Industrial Technique AB. All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. Atlas Copco Industrial This applies in particular to trademarks, model denominations, part numbers Technique AB and drawings.
