- Page 1 OPERATION MANUAL FOR CHARGE STATION MYCS-ID80 MYCS-80 MYCS-ID80-D ANLIDAR INDUSTRIAL CO., LTD. http://www.anlidar.com Y2F110-2E-003...
- Page 3 Icon Explanation Read manual Caution Double insulation Indoor use only No humidity No fire No disassemble No disposal CE Certification ETL Certification Caution Please read all instructions carefully before operate the rechargeable battery and charger. Also please follow all the instructions and pay attention to all the warring. Important Notification Please operate under the correct voltage to the charger in according with the operation manual.
- Page 4 Caution 1. Please match the correct Lithium-ion rechargeable battery for this charger,Do not apply different type or brand of battery on this charger, otherwise may cause error or danger. 2. Please match the charger with the battery models The use of other than genuine KILEWS replacement parts or battery may result in decreased tool performance and increased maintenance, and may invalidate all warranties.
- Page 5 2. Current protection 3. Shortage protection (fuse implement) 4. Battery reverse current protection 5. MYCS-ID80/MYCS-ID80-D Built-in ID recognition feature protection 6. Temperature protection Temperature protection detail explanation (1) When the battery temperature is between 0-10℃, the charger will use low current to pre-charge the battery until the battery temperature higher than 10℃...
- Page 6 MYCS-ID80/MYCS-ID80-D Display Description Light Display Yellow Green Description Beeps light light light Cell balance Flash Charging under 80% Flash Charging over 80%~99% N/A Flash Light Display and Warning Beep Charging Complete100% Three long beeps Charging Error Continuous short beeps Flash...
- Page 7 Specification Charger Station Model MYCS-ID80 MYCS-80 MYCS-ID80-D Battery Identification Input Voltage 100V – 240VAC / 0.5A~1.2A Output Voltage 21VDC Output Current W ＊ L ＊ H 145mm＊115mm＊80mm Dimension Weight 530g Battery Type Li-ion Applicable Battery Charging Time Battery Capacity Charger Model...
- Page 9 MYCS-ID80 MYCS-80 MYCS-ID80-D NO PARTS NO PARTS NAME-E PARTS NAME-C Q'ty NO PARTS NO PARTS NAME-E PARTS NAME-C Q'ty NO PARTS NO PARTS NAME-E PARTS NAME-C Q'ty AA50002 America Plug 美式電源線 AA50002 America Plug 美式電源線 AA50002 America Plug 美式電源線 AA50002-1 Australia Plug 澳式電源線...
