- Page 1 Instruction Manual High accuracy Handheld Thermometer HRM-150E First edition (Jan. 2024) AE-100303 Anritsu Meter Co., Ltd. 2-4-5 Shimomeguro, Meguro-ku, Tokyo, 153-0064, Japan TEL: +81-3-3491-9181 FAX: +81-3-3493-6729...
-
Page 3: Safety Information
Safety information Caution To safely operate and service the thermometer and to prevent any product damage and/or maintain the precise temperature measurement results, please carefully follow the instructions below: Do not use this product for any purpose other than taking temperature measurements. - Page 4 Compliance This product has a built-in reader/writer module that uses radio waves with a transmission frequency of 13.56 MHz. Compliance with NCC Rules CCAQ23LP0670T0 『取得審驗證明之低功率射頻器材,非經核准,公司、商號或使用者均不得擅自變更頻率、 加大功率或變更原設計之特性及功能。 低功率射頻器材之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應立即停 用, 並改善至無干擾時方得繼續使用。 前述合法通信,指依電信管理法規定作業之無線電通信。 低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。』 Compliance in Japan Standard number: ARIB STD-T82 Designated type number: FC-20001 This product contains a reader/writer module that is certified with a designated type of radio wave, which is provided by the Radio Law of Japan.
- Page 5 ■ This instruction manual has been prepared with absolute care. Please free feel to contact our company or your retailer should you discover any omissions or mistakes. ■ In no event is Anritsu Meter liable to anyone for any indirect, special, or consequential damages as a result of using this product.
- Page 6 Note: Our thermocouple probes are consumables and are not covered by the warranty. ● After-sales Service - If you think the product is not correctly working, please refer to this instruction manual. Should any issue persist, please contact our company or your retailer. - Repairs during the warranty period are subject to the content of the warranty sheet.
-
Page 7: Table Of Contents
Table of Contents General ....................1 Unpacking ..................1 2.1. Unpacking ....................1 2.2. Repacking ....................1 Name and Explanation of Each Part ..........2 3.1. External View ..................... 2 3.2. LCD Display ....................3 Preparations Before Taking Measurements ........4 4.1. - Page 8 11.3. Battery Voltage Drop Indication .............. 20 Maintenance ..................21 12.1. Storage ...................... 21 12.2. When the Case of the Instrument Gets Dirty .......... 21 Troubleshooting: Before Contacting Support ........22 HRM-150E Specifications ..............24...
-
Page 9: General
1. General This product is a handheld thermometer for high accuracy, reliability and usability. Based on the HR Series, this product is highly accurate and supports probes with an IC tag. The IC tag records errors unique to thermocouple probes. By reading the IC tag, errors will be automatically corrected, thereby enabling even higher accuracy measurements. -
Page 10: Name And Explanation Of Each Part
3. Name and Explanation of Each Part 3.1. External View (HRM-150E) ① Probe input connector ② USB connector ③ LCD display ④ Key switch panel ⑤ Battery housing ⑥ AC adaptor jack ⑦ Hand strap... -
Page 11: Lcd Display
3.2. LCD Display ② ① ③ ④ ⑤ ⑥ ⑦ ⑧ ⑪ ⑨ ⑩ ⑫ Description HOLD segment ① A-OFF segment ② Battery segment ③ CAL segment ④ Main display ⑤ °C segment ⑥ P segment ⑦ ⑧ MEM segment Sub display 1 ⑨... -
Page 12: Preparations Before Taking Measurements
4. Preparations Before Taking Measurements 4.1. How to Install the Batteries Make sure to turn the power off when replacing batteries. (1) Loosen both (2) Pay attention to screws and the orientation of open the cover the batteries. of the battery housing. -
Page 13: How To Use The Ac Power Supply
AC adaptor to the main unit as follows: Note: The AC adaptor is available as an option. Please use one as specified by Anritsu Meter. 4.4. How to Set the Probe Set the probe to the main unit as shown in the illustration below. It is designed so that if the probe orientation is incorrect, it cannot be fully inserted. -
Page 14: Operations And Functions
5. Operations and Functions 5.1. Power ON/OFF Pressing the POWER key will illuminate all the indicators for about three seconds and start measurements. Press the POWER key again to turn the instrument off. All illuminated Automatic correction function ON/OFF 5.2. Automatic correction function When the instrument is switched on with the probe with the IC tag (BSM Series/BUM Series/SFM Series) connected, CAL flashes and the instrument turns on the Automatic correction function. -
Page 15: Hold Function
5.3. HOLD Function Press the HOLD key to maintain the indicated values during measurements. HOLD will illuminate on the screen while HOLD is on. To release the HOLD function, press the HOLD key again. Hold illuminated Notes: ∙ Use the functions below after releasing the HOLD function: Alarm function, P/V Hold function, and calibration function. -
Page 16: Resolution Change
5.5. Resolution Change Press the RESO key to switch the resolution. 0.01°C resolution indication: The range between - 104.99 and 199.99°C is displayed with the 0.01°C resolution. When the temperature goes out of this range, it will automatically be displayed with the 0.1°C resolution. ... -
Page 17: P/V Hold Function
5.6. P/V Hold Function Press the P/V-HOLD key to enter the P/V Hold function. The lowest and highest values will be displayed in the sub- screens. Press the P/V-HOLD again to return to normal measurements. Normal measurement P/V mode P/V-HOLD Max. -
Page 18: Time Setting
6. Time Setting This product is equipped with a clock function. At the time of purchase or resetting the clock, please follow the steps below: With the power of the instrument off, press the AUTO OFF and the POWER key at the same time to turn the instrument on. -
Page 19: Memory Function
7. Memory Function 7.1. Interval Setting When the SET key is pressed, INT will be displayed and flashing in the left-bottom sub-screen, and the interval will illuminate. Intervals will be switched in the order of 1 sec. → 5 sec. → 10 sec. → 30 sec. → 1 min. -
Page 20: Starting Memory Measurements
7.2. Starting Memory Measurements When the START key is pressed, INT will illuminate, and memory measurements will start at the displayed interval. To stop memory measurements, press the STOP key. When the STOP key is pressed, measured data will be saved as a data block. Saved data blocks can be transferred to PCs, creating a data file for each block. -
Page 21: Memory Play Back Function
● Manual measurements For manual measurements, every time the START key is pressed, the numerical value of the INT indication will increment, while that of the MEM indication will decrement. Measured temperature indications will be refreshed at an interval of about 200 ms, as is the case with normal measurements. -
Page 22: How To Clear The Data
Note: Pressing and holding the ˄ and ˅ keys will increase the refresh rate of the display to x10 and x100. Press the PLAY BACK key again to return to normal measurements (status before the PLAY BACK key was pressed.) 7.4. -
Page 23: Dedicated Software Ams-350
8. Dedicated Software AMS-350 The HRM-150 High accuracy handheld thermometer can communicate with PCs by using the AMS-350 dedicated software. Please install the AMS-350 software as instructed in the included user’s manual. This software requires the following operating environment: Supported OS : Microsoft Windows 10 Microsoft Windows 11 System types : 32 bit/64 bit PCs that have sufficient specifications to run the above OS. -
Page 24: How To Transfer Data In The Measuring Instrument
Note ∙ For details of communication connectors on the PC, please refer to the PC software instruction manual. ∙ When not communicating with a PC, always disconnect the instrument from the PC (by removing the communication cable.) ∙ If a different application is used while the instrument is connected, malfunctions and/or failures may occur. - Page 25 Every time AMS-350 starts, set the serial port. To find the COM value, please refer to the AMS-350 user’s manual. From the [Communication (C)] menu, select [Data input]. The “Do you want to start data input?” screen will be displayed. Select [Yes] to start data input.
-
Page 26: Retention Of Setup Data
Do not operate any keys of the instrument during communication. Abnormal termination or a malfunction may result. Note: After inputting data, the data on the instrument will be maintained. If any communication error occurs, please input the data again. When all the data input is completed, a newly created data file will be displayed. For further details, please refer to the user’s manual of dedicated software, AMS-350. -
Page 27: Checking The Remaining Battery
Function HOLD Released Automatic power OFF Retained P/V hold Released Resolution Released Backlight Released Time setting Retained Memory Retained Interval setting Retained Notes: Be sure to insert the battery to keep the time setting. Checking the Remaining Battery Remaining battery is displayed in the top right corner of the indication. The remaining battery shows the continuous time of use in the rate shown in the table below. -
Page 28: Error Messages
11. Error Messages 11.1. Indication of a Broken Wire of the Probe If the probe has a broken wire or is disconnected, the burnout (broken wire) indication is displayed. If this indication is displayed, replace the probe with a new one or connect the probe. 11.2. -
Page 29: Maintenance
Maintenance 12.1. Storage When storing this instrument, avoid the following places: - In direct sunlight - Subject to heavy vibrations - High humidity (85%RH or more) - High temperature atmosphere (50°C or higher) - Filled with dust, waste, corrosive gas and/or salt - High electromagnetic field To store the instrument for a long time, it is recommended to remove the batteries and store the unit in the original packaging at the time of delivery. -
Page 30: Troubleshooting: Before Contacting Support
Troubleshooting: Before Contacting Support If you find any abnormalities or become unable to operate the instrument, first check for the following items. If you still cannot solve the issue, please contact your retailer or our company. (1) The instrument does not operate when the power is turned on: - Is the orientation of the batteries in the correct manner? Reset the batteries. - Page 31 (5) If memory measurements cannot start - Is there a remaining memory block? Is the number of blocks exceeding 200? After exporting the necessary measured data, clear the data. Please refer to “7.4 How to Clear the Data”.
-
Page 32: Hrm-150E Specifications
14. HRM-150E Specifications ASP specifications Model (HRM-) Operation switches Membrane keyboard (with clicking function) ASP connector Input connector (thermocouple homogeneous metals) Input Thermocouple Type E No. of input Signal source resistance 1 kΩ or less 0.1°C resolution -104.9 to 204.9°C Measurement range 0.01°C resolution... - Page 33 Weight About 350 g (including batteries) Memory function See specifications (memory function) Power supply See Specifications (power supply)”. Accessories See Specifications (accessories)”. Frequency 13.56MHz Type of Modulation Number of channels RFID Maximum field strength 23.05dBμV/m (Peak) @30m Compliant standard Standard #: ARIB STD-T82 Type designation #: FC-20001 Standard #: CCAQ23LP0670T0 Standard #: ETSI EN 300 330...
-
Page 34: Specifications & Accessories
1minute,5minutes,10minutes,30minutes,60miinutes and manual memory Memory capacity 19999 data * Sampling period will be a user-selected time interval when time interval is specified at 10seconds or more. Specifications (power supply) Model (HRM-) Batteries 4 x Alkaline AA battery (LR6) Battery life (continuous operation time) About 450h AC adaptor (optional) support ●...
