Sharp R-520L Series Operation Manual

Hide thumbs Also See for R-520L Series:

Operation manual (24 pages)

Operation manual (25 pages)

Operation manual (26 pages)

page of 24

/ 24
Bookmarks

Quick Links

Download this manual

M I C R O W A V E

OPERATION MANUAL

R e a d a l l i n s t r u c t i o n s c a r e f u l l y b e f o r e u s i n g t h e o v e n .

O V E N

MODELS

R-520K / R-520L

F o l l o w e d b y l e t t e r i n d i c a t i n g c o l o r

K=black, W=white, S=stainless steel

C O N T E N T S

• For Customer Assistance

................. Inside Front Cover

• Precautions to Avoid Possible

Exposure to Excessive Microwave

Energy ............................... ........

• Consumer Limited Warranty .............................

• Product Information Card .................................

• Important Safety Instructions ...........................

• Unpacking and Installation Instructions .........

• Grounding Instructions .....................................

• Information You Need to Know ........................

• Part Names .........................................................

• Before Operating ...............................................

• Manual Operation ..............................................

• Special Features ................................................ 10-15

• Other Convenient Features............................... 16-17

• Cleaning and Care .............................................

• Service Call Check.............................................

• Cookbook Information ......................................

• Cookbook Order Form .....................................

• Speciﬁ cations ....................................................

• Guia Auto-Touch . .......................

• Auto-Touch Guide .......................................Back Cover

Inside Front Cover

4-6

7-8

Parte Interior de la

Cuberta Trasera

Need help?

Do you have a question about the R-520L Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sharp R-520L Series

Page 1 M I C R O W A V E O V E N OPERATION MANUAL MODELS R-520K / R-520L F o l l o w e d b y l e t t e r i n d i c a t i n g c o l o r K=black, W=white, S=stainless steel C O N T E N T S •...
Page 2 DATE OF PURCHASE ______________________ DEALER ___________________________ TELEPHONE ________________ SERVICER ___________________________ TELEPHONE ________________ TO PHONE: DIAL 1-800-BE-SHARP (237-4277) for: SERVICE (for your nearest Sharp Authorized Servicer) PARTS (for your authorized parts distributor) ADDITIONAL CUSTOMER INFORMATION ACCESSORIES and COOKBOOK TO WRITE: Sharp Electronics Corporation...
Page 3 Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer.
Page 4 15. See door surface cleaning instructions on page 18. 19. If the oven light fails, consult a SHARP AUTHO- 16. To reduce the risk of ﬁ re in the oven cavity: RIZED SERVICER.
Page 5 1. If you have any questions about the grounding or electrical instructions, consult a qualiﬁ ed electrician or service person. 2. Neither Sharp nor the dealer can accept any liability for damage to the oven or personal injury resulting from failure to observe the correct electrical connection procedures.
Page 6 See pages 19 and 20 for ordering the amount of moisture that condenses in the oven. Generally, covered foods will not cause as much con- the Sharp Carousel Microwave Cookbook. densation as uncovered ones. Vents on the oven back NEVER use the oven without the turntable and support must not be blocked.
Page 7 • metal twist-ties mining correct doneness and assure you that foods have been cooked to safe temperatures. Sharp is not Should you wish to check if a dish is safe for responsible for any damage to the oven when acces- microwaving, place the empty dish in the oven and sories are used.
Page 8 I N F O R M A T I O N Y O U N E E D T O K N O W ABOUT MICROWAVE COOKING • Arrange food carefully. Place thickest areas towards • Rearrange foods such as meatballs halfway outside of dish.
Page 9 P A R T N A M E S MICROWAVE OVEN PARTS 1 One touch door open button 8 Removable turntable Push to open door. Place the turntable on the turntable support 2 Oven door with see-through window securely. The turntable will rotate clockwise or counterclockwise.
Page 10 P A R T N A M E S CONTROL PANEL R - 5 2 0 K R - 5 2 0 L 10-11 10-11 14-15 14-15 Number next to the control panel illustration indicates pages on which there are feature descriptions and usage information.
Page 11 B E F O R E O P E R A T I N G M A N U A L O P E R A T I O N • Before operating your new microwave oven make TIME COOKING sure you read and understand this operation manual Your oven can be programmed for 99 minutes 99 seconds completely.
Page 12 S P E C I A L F E A T U R E S SENSOR COOK Sharp's Sensor is a semi-conductor device that detects 8. Check food for temperature or doneness after the vapor (moisture and humidity) emitted from the food cooking.
Page 13 S P E C I A L F E A T U R E S SENSOR COOK CHART (continued) F O O D A M O U N T P R O C E D U R E FRESH VEGETABLES: Soft Wash and place in casserole.
Page 14 S P E C I A L F E A T U R E S SENSOR COOK RECIPES Glazed Apple Slices Makes 6 to 8 servings 1/4 cup brown sugar 3/4 cup orange juice tablespoons margarine or butter tablespoon cornstarch tablespoons apricot preserves baking apples (about 1 1/2 pounds), peeled and 1/2 teaspoon ground nutmeg...
Page 15 S P E C I A L F E A T U R E S REHEAT NOTE: REHEAT allows you to heat many of your favorite 1. To increase quantity, touch chosen pad until foods. number in display is same as desired quantity to heat.
Page 16 S P E C I A L F E A T U R E S DEFROST MANUAL DEFROST If the food that you wish to defrost is not listed on DEFROST automatically defrosts all the foods shown the DEFROST CHART or is above or below the limits in the DEFROST CHART on page 15.
Page 17 S P E C I A L F E A T U R E S DEFROST CHART F O O D P R O C E D U R E A M O U N T GROUND .5 - 2.0 lb Remove any thawed pieces after each stage.
Page 18 O T H E R C O N V E N I E N T F E A T U R E S TIMER DEMONSTRATION MODE • Suppose you want to time a 3 minute long distance To demonstrate, touch TIMER/CLOCK, the number 0, then touch START/MINUTE PLUS and hold for 3 phone call.
Page 19 O T H E R C O N V E N I E N T F E A T U R E S CUSTOM HELP NOTE: Custom Help provides 4 features that make using 1. Auto Start can be used for manual cooking if clock your oven easy because specific instructions are is set.
Page 20 C L E A N I N G A N D C A R E Disconnect the power cord before cleaning or leave the door open to inactivate the oven during cleaning. Exterior Waveguide Cover The outside surface is painted. Clean the outside with The waveguide cover is made from mica so it requires mild soap and water.
Page 21 If “NO” is the answer to any of the above questions, please check electrical outlet, fuse and/or circuit breaker. If they are functioning properly, CONTACT YOUR NEAREST SHARP AUTHORIZED SERVICER. A microwave oven should never be serviced by a “do-it-yourself” repair person.
Page 22 $ _____________ Illinois sales tax, (if applicable) per book $.91 no. of books ______ $ _____________ TOTAL ORDER AMOUNT $ _____________ I have enclosed a check made payable to Sharp Electronics Corporation. Please bill my VISA MASTERCARD AMERICAN EXPRESS Acct. No _____________________________________ Expiration date ______ / ______ Signature ________________________________________________________________ (All credit card orders must be signed.)
Page 23 30 min. (Ej.: 15 min.) aumentar un minuto en el tiempo de MINUTE PLUS cocción manual. Continúe tocándolo si START 3 Toque el botón START/ necesita aumentar más minutos. MINUTE PLUS MINUTE PLUS. Carousel ® es una marca registrada de Sharp Corporation.
Page 24 100% power or to add a minute dur- START ing manual cooking. Continue to touch MINUTE PLUS for additional minutes. ® Carousel is a registered trademark of Sharp Corporation. SHARP ELECTRONICS CORPORATION Printed on recycled paper Sharp Plaza, Mahwah, New Jersey 07430-2135 PRINTED IN THAILAND TINSEB147WRRZ-D71...
