- Page 1 User Manual Rev. 2024-2 MB48LI82.GW MB48LI50.GW...
- Page 2 USER MANUAL The battery has a display on the right (7), two switches, a red one on the left (4) and a smaller one on the right side (8) and two RGB LEDs (2,3) that are used as a Human to Machine Interface (HMI). Figure 1: Battery front.
- Page 3 Table 2: LED’s behaviour. Display Meaning The battery is turned OFF and in a low-power mode Both OFF Blinking The battery is awake and ready to receive more commands Both OFF The battery is starting up Blinking (pre-charge of inverter capacitors) Yellow Battery is ON and there is...
- Page 4 Table 2: LED’s behaviour, continued. LEDs Display Meaning MtB Smart GateWay found; relevant battery is connecting to it Magenta - fast The battery is paired and connected to MtB Smart relevant GateWay Magenta - slow The red switch, on the left is used to control the battery, while pressed a sound signal will be emitted.
- Page 5 Turn ON procedure: To turn ON a battery, the battery should firstly be woken up by pressing and releasing the red switch, it will make a sound signaling when it is ready to receive more commands. The battery can then be turned ON by pressing and holding the red switch until one sound signal is emitted.
- Page 6 ERROR CODES • E01: There is a problem with the BMS, MeterBoost should be contacted. • E02: The battery is ON, but the system is not detecting voltage on the output terminals. Probably the internal fuse is blown, and the battery must be sent to MeterBoost to be serviced.
